Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (23)
|
4931435474 |
2.50
|
|
|
0002 |
CAP (2)
|
4931495718 |
4.50
|
|
|
0003 |
SCREW (8)
|
4931472785 |
5.00
|
|
|
0004 |
PIN (1)
|
4931495719 |
11.50
|
|
|
0005 |
BODY (1)
|
4931495720 |
192.00
|
|
|
0006 |
THREADED SLEEVE (1)
|
4931495721 |
13.00
|
|
|
0007 |
LOCK PIN (1)
|
4931495722 |
39.00
|
|
|
0008 |
BUSH (1)
|
4931495723 |
17.00
|
|
|
0010 |
LOCK RELEASE KIT (1)
|
4931495724 |
48.00
|
|
|
0011 |
PINION SHAFT (1)
|
4931495725 |
112.00
|
|
|
0012 |
INTERLOCK ELEMENT (1)
|
4931495726 |
55.00
|
|
|
0016 |
HANDLE (1)
|
4931495727 |
19.00
|
|
|
0017 |
POINTER (1)
|
4931495728 |
9.00
|
|
|
0018 |
CAP (1)
|
4931495729 |
3.50
|
|
|
0020 |
PLATE (1)
|
4931472804 |
2.50
|
|
|
0021 |
SCREW (2)
|
4931472805 |
2.50
|
|
|
0022 |
ROD CHOKE (1)
|
4931495730 |
139.50
|
|
|
0023 |
PLATE (1)
|
4931472808 |
2.50
|
|
|
0024 |
PIN (3)
|
4931495731 |
2.50
|
|
|
0025 |
STOPPER (1)
|
4931495732 |
15.00
|
|
|
0026 |
DEPTH GAUGE (1)
|
4931495733 |
8.00
|
|
|
0027 |
KNOB (1)
|
4931495734 |
11.00
|
|
|
0030 |
HOLDER (1)
|
4931472809 |
4.00
|
|
|
0031 |
SCREW (2)
|
4931472810 |
2.50
|
|
|
0032 |
WASHER (1)
|
4931472812 |
2.50
|
|
|
0033 |
BOLT (1)
|
4931495735 |
6.00
|
|
|
0034 |
SLEEVE (1)
|
4931495736 |
12.50
|
|
|
0035 |
BOLT (1)
|
4931495737 |
31.00
|
|
|
0036 |
CLAMP (1)
|
4931495738 |
6.00
|
|
|
0037 |
BUSHING (1)
|
4931472819 |
2.50
|
|
|
0038 |
YOKE (1)
|
4931472818 |
5.00
|
|
|
0039 |
CAP (1)
|
4931472813 |
2.50
|
|
|
0040 |
NUT (1)
|
4931472817 |
7.00
|
|
|
0041 |
SLEEVE (1)
|
Item discontinued
(4931436401) |
|
|
|
0042 |
BRACKET (1)
|
4931495739 |
134.00
|
|
|
0043 |
NUT (1)
|
4931472815 |
5.00
|
|
|
0044 |
WASHER (1)
|
4931453039 |
2.50
|
|
|
0045 |
SCREW (1)
|
4931472816 |
2.50
|
|
|
0046 |
SNAP RING (2)
|
4931472833 |
1.00
|
|
|
0047 |
PIN (1)
|
4931495740 |
9.50
|
|
|
0048 |
BOLT (4)
|
4931495707 |
8.00
|
|
|
0049 |
SCREW (4)
|
4931472825 |
2.50
|
|
|
0050 |
PLATE (1)
|
4931472826 |
8.00
|
|
|
0052 |
DISTANCE PIECE (4)
|
4931495708 |
9.00
|
|
|
0053 |
RETAINING RING (1)
|
4931495741 |
2.50
|
|
|
0054 |
SCREW (1)
|
4931495706 |
8.00
|
|
|
0055 |
BUSH (4)
|
4931472829 |
4.00
|
|
|
0056 |
WASHER (4)
|
4931453043 |
2.50
|
|
|
0057 |
SCREW (4)
|
4931472710 |
1.00
|
|
|
0058 |
SPRING (1)
|
4931495742 |
4.00
|
|
|
0059 |
WASHER (2)
|
4931495743 |
2.50
|
|
|
0060 |
AXLE (1)
|
4931495744 |
238.00
|
|
|
0061 |
TURNING KNOB (1)
|
4931495745 |
17.00
|
|
|
0062 |
WHEEL (2)
|
4931495746 |
50.00
|
|
|
0063 |
WASHER (2)
|
4931495747 |
2.50
|
|
|
0064 |
SCREW (2)
|
4931461511 |
2.50
|
|
|
0080 |
KIT (4)
|
4931495748 |
51.00
|
|
|
0081 |
KIT (4)
|
4931495749 |
41.00
|
|
|
0082 |
SET SCREW (1)
|
4931495750 |
30.00
|
|
|
0083 |
KIT (1)
|
4931495751 |
8.00
|
|
|
0084 |
RATING PLATE (1)
|
4931495752 |
2.50
|
|
|
0085 |
KNOB HANDLE (3)
|
4931495753 |
36.00
|
|
|
0086 |
SHAFT (3)
|
4931495754 |
9.50
|
|
|
0087 |
HUB (1)
|
4931495755 |
24.00
|
|
|
0088 |
SPINDLE LOCK (1)
|
4931453136 |
14.50
|
|
