Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0003 |
RATING PLATE (1)
|
4931468126 |
2.50
|
|
|
0004 |
CONNECTION CABLE (1)
|
4931250832 |
12.50
|
|
|
0005 |
PROTECTING COVER (1)
|
4931392174 |
3.50
|
|
|
0007 |
GROOVED DOWEL PIN (1)
|
4931623456 |
3.50
|
|
|
0008 |
WASHER (2)
|
4931623094 |
2.50
|
|
|
0009 |
WASHER (1)
|
4931621834 |
2.50
|
|
|
0010 |
GEAR BOX COVER (1)
|
4931360377 |
3.50
|
|
|
0102 |
PROTECTIVE CAP (1)
|
4931360518 |
3.00
|
|
|
0105 |
ELECTRIC FIELD (1)
|
4931442735 |
21.00
|
|
|
0116 |
AIR DEFLECTOR RING (1)
|
4931353230 |
4.00
|
|
|
0117 |
HOLDING-DOWN DEVICE (4)
|
4931405705 |
3.00
|
|
|
0120 |
BRUSH HOLDER (2)
|
4931382268 |
5.00
|
|
|
0122 |
SCREW (4)
|
4931624518 |
2.50
|
|
|
0123 |
CENTERING LEDGE (2)
|
4931342808 |
3.50
|
|
|
0125 |
CABLE COLLAR (1)
|
4931256500 |
3.50
|
|
|
0126 |
SCREW (1)
|
4931624516 |
2.50
|
|
|
0127 |
SCREW N874101-1 SHR H-K4X18 T15 (7)
|
4931624515 |
2.50
|
|
|
0128 |
WIRE (1)
|
4931623541 |
6.00
|
|
|
0129 |
SCREW (1)
|
4931622153 |
2.50
|
|
|
0130 |
BEARING COVER (1)
|
4931356869 |
3.50
|
|
|
0135 |
SWITCH BOARD (1)
|
4931384292 |
32.50
|
|
|
0140 |
CAPACITOR (1)
|
4931624270 |
4.00
|
|
|
0141 |
WIRE (1)
|
4931624269 |
3.50
|
|
|
0200 |
GEAR BOX (1)
|
4931384312 |
65.50
|
|
|
0206 |
GEAR BOX (1)
|
4931382948 |
81.50
|
|
|
0208 |
WASHER (1)
|
4931623637 |
2.50
|
|
|
0209 |
O-RING N874701 5X1 (1)
|
4931941082 |
2.50
|
|
|
0210 |
THRUST BEARING (1)
|
4931360041 |
5.50
|
|
|
0211 |
REDUCT. GEAR SHAFT (1)
|
4931384313 |
41.00
|
|
|
0212 |
REDUCT. GEAR SHAFT (1)
|
4931417725 |
20.00
|
|
|
0218 |
WOBBLE DRIVE (1)
|
4931384560 |
41.50
|
|
|
0219 |
REDUCTION GEAR (1)
|
4931426240 |
10.50
|
|
|
0222 |
PERCUSSION BODY (1)
|
4931455432 |
33.00
|
|
|
0223 |
CYLINDER (1)
|
4931384279 |
14.00
|
|
|
0224 |
CYLINDRICAL BOLT (1)
|
4931331623 |
3.50
|
|
|
0225 |
WASHER (2)
|
4931400589 |
2.50
|
|
|
0226 |
LOCKING PIECE (1)
|
4931384316 |
4.00
|
|
|
0227 |
PRESSURE SPRING (1)
|
4931384293 |
3.50
|
|
|
0228 |
PIN (1)
|
4931623081 |
3.50
|
|
|
0229 |
LATCH PLATE (1)
|
4931331787 |
4.00
|
|
|
0232 |
SPINDLE (1)
|
4931392170 |
73.50
|
|
|
0234 |
ADAPTER (1)
|
4931409762 |
22.00
|
|
|
0239 |
STOP WASHER (1)
|
4931409839 |
7.50
|
|
|
0241 |
CORE LIFTER RING (1)
|
4931409775 |
5.50
|
|
|
0243 |
SNAP DIE (1)
|
4931384284 |
10.50
|
|
|
0244 |
STOP WASHER (1)
|
4931384283 |
8.50
|
|
|
0251 |
NEEDLE BEARING (2)
|
4931219424 |
3.00
|
|
|
0252 |
SPACER (1)
|
4931409776 |
6.50
|
|
|
0253 |
HOLDING RING (1)
|
4931426165 |
5.50
|
|
|
0254 |
BALL (6)
|
4931805437 |
2.50
|
|
|
0255 |
SET SLEEVE (1)
|
4931384299 |
30.00
|
|
|
0257 |
JUMPER RING (1)
|
4931417929 |
19.00
|
|
|
0258 |
BALL (1)
|
4931805413 |
2.50
|
|
|
0259 |
WASHER (1)
|
4931623199 |
2.50
|
|
|
0261 |
SWITCH HANDLE (1)
|
4931392506 |
4.00
|
|
|
0262 |
LATCH PLATE (1)
|
4931379108 |
4.50
|
|
|
0264 |
BALL (1)
|
4931805413 |
2.50
|
|
|
0265 |
DISC (1)
|
4931624280 |
3.50
|
|
|
0267 |
BOLT (1)
|
4931392501 |
8.00
|
|
|
0268 |
DISC N874237 (1)
|
4931624096 |
3.50
|
|
|
0269 |
SPACER (1)
|
4931379420 |
3.50
|
|
|
0270 |
SUPPORTING PLATE (1)
|
4931409756 |
3.50
|
|
|
0271 |
DISC N874237 (1)
|
4931624098 |
3.50
|
|
|
0272 |
DISC N874237 (1)
|
4931624097 |
3.50
|
|
|
0273 |
DISC N874237 (1)
|
4931624096 |
3.50
|
|
|
0275 |
SCREW (2)
|
4931624282 |
2.50
|
|
|
0401 |
MOTOR COVER (1)
|
4931360732 |
7.00
|
|
|
0405 |
MOTOR HOUSING (1)
|
4931384337 |
11.50
|
|
|
0406 |
ARMATURE (1)
|
4931449969 |
74.50
|
|
|
0407 |
FAN (1)
|
4931342793 |
3.50
|
|
|
0408 |
GROOVED BALL BEAR. (1)
|
4931341740 |
4.00
|
|
|
0409 |
BALL BEARING (1)
|
4931624101 |
6.50
|
|
|
0410 |
INSULATING DISC (1)
|
4931353260 |
3.50
|
|
|
0413 |
SEAL RING (1)
|
4931442301 |
10.00
|
|
|
0414 |
SPACER (1)
|
4931353238 |
4.00
|
|
|
0415 |
BUSHING (1)
|
4931384557 |
17.00
|
|
|
0420 |
PINION SHAFT (1)
|
4931432300 |
42.00
|
|
|
0426 |
LOCKING RING (1)
|
4931616614 |
3.50
|
|
|
0427 |
DISC N874237 A16,1X26X1 (1)
|
4931622564 |
3.50
|
|
|
0700 |
CARRYING CASE (1)
|
4931415335 |
31.00
|
|
|
0705 |
AUXILIARY HANDLE (1)
|
4931417907 |
14.00
|
|
|
1100 |
HANDLE COMPL. (1)
|
4931384324 |
16.00
|
|
|
1200 |
MAINTENANCE SET (1)
|
4931384311 |
64.00
|
|
|
1201 |
CARBON BRUSH SET (1)
|
4931369477 |
10.00
|
|
|
1204 |
O-RING (1)
|
4931623124 |
2.50
|
|
|
1205 |
RUBBER SLEEVE (1)
|
4931360781 |
5.00
|
|
|
1207 |
SEAL (1)
|
4931392504 |
4.00
|
|
|
1209 |
SEAL RING (1)
|
4931379705 |
3.50
|
|
|
1210 |
SEAL RING (1)
|
4931624492 |
3.50
|
|
|
1211 |
SEAL RING (1)
|
4931624226 |
3.50
|
|
|
1212 |
SPRING (1)
|
4931321064 |
3.50
|
|
|
1213 |
SEAL RING N874701 12X1,5 (1)
|
4931624322 |
3.00
|
|
|
1214 |
SEAL RING (1)
|
4931624227 |
3.50
|
|
|
1215 |
DAMPING ELEMENT (1)
|
4931392502 |
4.00
|
|
|
1216 |
HOLDING-DOWN DEVICE (1)
|
4931331549 |
3.50
|
|
|
1218 |
RING (1)
|
4931623636 |
4.50
|
|
|
1219 |
SPRING RING (2)
|
4931945764 |
3.50
|
|
|
1220 |
SCREW (4)
|
4931623521 |
2.50
|
|
|
1221 |
SCREW (4)
|
4931623520 |
2.50
|
|
|
1222 |
SCREW (2)
|
4931623519 |
2.50
|
|
|
1223 |
SCREW (2)
|
4931379109 |
2.50
|
|
|
1224 |
O-RING (1)
|
4931623293 |
2.50
|
|
|
1225 |
SPRING RING (1)
|
4931622874 |
3.50
|
|
|
1226 |
SEAL RING (1)
|
4931624493 |
8.00
|
|
|
1227 |
RUBBER CAP (1)
|
4931384925 |
5.50
|
|
|
1228 |
SEAL RING N874701 12X1,5 (1)
|
4931624225 |
4.00
|
|
|
1229 |
GREASE RETAIN.PLUG (1)
|
Item discontinued
(4931392505) |
|
|
|
1230 |
SET SLEEVE (1)
|
4931384295 |
7.00
|
|
|
1231 |
HOLDING DISC (1)
|
4931392528 |
4.00
|
|
|
1232 |
HOLDING-DOWN DEVICE (1)
|
4931307423 |
3.50
|
|
|
1233 |
BALL (2)
|
4931624303 |
2.50
|
|
