Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0003 |
SCREW (4)
|
4931624616 |
2.50
|
|
|
0004 |
CONNECTION CABLE (1)
|
4931623857 |
14.00
|
|
|
0005 |
PROTECTING COVER (1)
|
4931393422 |
3.50
|
|
|
0006 |
SCREW (2)
|
4931624581 |
2.50
|
|
|
0008 |
RATING PLATE (1)
|
4931455681 |
2.50
|
|
|
0100 |
MOTOR HOUSING (1)
|
4931396317 |
12.50
|
|
|
0105 |
ELECTRIC FIELD (1)
|
4931442731 |
21.00
|
|
|
0106 |
ARMATURE (1)
|
4931442664 |
51.50
|
|
|
0107 |
slinger sleeve (1)
|
Item discontinued
(4931396544) |
|
|
|
0108 |
GROOV. BALL BEARING (1)
|
4931396556 |
5.50
|
|
|
0109 |
BEARING COVER (1)
|
4931396325 |
3.00
|
|
|
0110 |
FAN (1)
|
4931342793 |
3.50
|
|
|
0111 |
INSULATING DISC (1)
|
4931396442 |
3.00
|
|
|
0112 |
BALL BEARING (1)
|
4931902888 |
5.50
|
|
|
0113 |
AIR DEFLECTOR RING (1)
|
4931396534 |
3.00
|
|
|
0117 |
SET COLLAR (1)
|
4931396546 |
22.00
|
|
|
0123 |
CENTERING LEDGE (2)
|
4931342808 |
3.50
|
|
|
0127 |
SCREW N874101-1 SHR H-K4X18 T15 (6)
|
4931624515 |
2.50
|
|
|
0135 |
SCREW (2)
|
4931621772 |
1.00
|
|
|
0136 |
SPEED GOVERNOR (1)
|
4931487441 |
67.00
|
|
|
0137 |
SLIDER (1)
|
4931396368 |
4.00
|
|
|
0141 |
CABLE COLLAR (1)
|
4931256500 |
3.50
|
|
|
0143 |
SCREW (2)
|
4931624538 |
2.50
|
|
|
0150 |
HANDLE SET (1)
|
4931396450 |
13.50
|
|
|
0200 |
GEAR BOX (1)
|
4931396375 |
30.50
|
|
|
0201 |
GEAR BOX (1)
|
4931396305 |
7.00
|
|
|
0202 |
NEEDLE BUSH (1)
|
4931331760 |
10.00
|
|
|
0203 |
BEARING (1)
|
4931396373 |
5.50
|
|
|
0204 |
NEEDLE BEARING N874989 HK 0709 (1)
|
4931933756 |
3.00
|
|
|
0205 |
PRESSURE SPRING (1)
|
4931396432 |
3.50
|
|
|
0206 |
LOCKING PLATE (1)
|
4931396385 |
3.50
|
|
|
0207 |
SCREW (1)
|
4931396462 |
2.50
|
|
|
0208 |
BEARING END PLATE (1)
|
4931396314 |
41.00
|
|
|
0209 |
WASHER (2)
|
4931365112 |
2.50
|
|
|
0210 |
CYLINDRICAL BOLT (1)
|
4931396336 |
3.50
|
|
|
0211 |
CYLINDER (1)
|
4931396541 |
11.00
|
|
|
0212 |
PERCUSSION BODY (1)
|
4931455431 |
25.00
|
|
|
0213 |
THRUST COLLAR (1)
|
4931396548 |
3.50
|
|
|
0214 |
SLEEVE (1)
|
4931409779 |
8.50
|
|
|
0215 |
SNAP DIE (1)
|
4931396428 |
7.50
|
|
|
0216 |
STOP WASHER (1)
|
4931396427 |
4.16
|
|
|
0225 |
RING STOP (1)
|
4931409754 |
3.50
|
|
|
0226 |
PRESSURE SPRING (1)
|
692737001 |
4.00
|
|
|
0227 |
WASHER (1)
|
4931624257 |
2.50
|
|
|
0228 |
BALL (6)
|
4931805437 |
2.50
|
|
|
0230 |
SPINDLE SLEEVE (1)
|
4931417458 |
33.00
|
|
|
0234 |
WASHER (1)
|
4931624457 |
2.50
|
|
|
0237 |
CLUTCH DISC (1)
|
4931396339 |
4.00
|
|
|
0239 |
WASHER (1)
|
4931624639 |
2.50
|
|
|
0330 |
ADAPTER (1)
|
4931384684 |
30.00
|
|
|
0331 |
ADAPTER (1)
|
4931409763 |
8.50
|
|
|
0333 |
SPRING RING (1)
|
4931622874 |
3.50
|
|
|
0334 |
SET SLEEVE (1)
|
4931384681 |
3.00
|
|
|
0335 |
SPRING (1)
|
4931321064 |
3.50
|
|
|
0336 |
BALL (1)
|
4931911572 |
2.50
|
|
|
0337 |
JUMPER RING (1)
|
4931343034 |
3.00
|
|
|
0338 |
SPACER (1)
|
4931343057 |
3.50
|
|
|
0339 |
BALL (2)
|
4931805413 |
2.50
|
|
|
0340 |
REDUCT. GEAR SHAFT (1)
|
4931396444 |
65.00
|
|
|
0341 |
SPROCKET (1)
|
4931375873 |
3.50
|
|
|
0343 |
REDUCT. GEAR SHAFT (1)
|
4931417721 |
10.50
|
|
|
0344 |
INTERN.GEARED WHEEL (1)
|
4931375874 |
3.00
|
|
|
0346 |
PRESSURE SPRING (1)
|
4931396545 |
2.50
|
|
|
0347 |
COUPLING SLEEVE (1)
|
4931396329 |
9.50
|
|
|
0348 |
WOBBLE DRIVE (1)
|
4931396522 |
28.00
|
|
|
0349 |
REDUCTION GEAR (1)
|
4931426238 |
9.00
|
|
|
0350 |
DISTANCE SLEEVE (1)
|
4931396369 |
3.00
|
|
|
0351 |
SCREW (2)
|
4931624678 |
2.50
|
|
|
0352 |
CYLINDER PIN (1)
|
4931624471 |
3.50
|
|
|
0353 |
SLIDING SWITCH (1)
|
4931396384 |
4.00
|
|
|
0354 |
SWITCH HANDLE (1)
|
4931396347 |
9.50
|
|
|
0370 |
HOLDING-DOWN DEVICE (3)
|
4931396400 |
3.50
|
|
|
0444 |
SPINDLE SLEEVE (1)
|
4931407935 |
69.00
|
|
|
0602 |
RING SPRING (1)
|
4931302074 |
2.50
|
|
|
0604 |
CHUCK ADAPTER (1)
|
4931392452 |
12.50
|
|
|
0605 |
DEPTH GAUGE (1)
|
4931384434 |
3.50
|
|
|
0700 |
CARRYING CASE (1)
|
4931415325 |
35.00
|
|
|
0705 |
HANDLE (1)
|
4931392747 |
21.00
|
|
|
1200 |
MAINTENANCE SET (1)
|
4931396419 |
50.50
|
|
|
1201 |
CARBON BRUSH SET (1)
|
4931396547 |
8.50
|
|
|
1202 |
RUBBER SLEEVE (1)
|
4931396532 |
2.50
|
|
|
1203 |
SLEEVE (1)
|
4931396445 |
3.50
|
|
|
1204 |
SPRING RING (2)
|
4931945764 |
3.50
|
|
|
1206 |
SEAL RING D 3760 AS 22X35X7 (1)
|
4931624259 |
4.00
|
|
|
1207 |
SEAL RING (1)
|
4931623961 |
3.50
|
|
|
1208 |
SEAL (1)
|
4931396374 |
3.50
|
|
|
1210 |
SEAL RING (1)
|
4931396461 |
3.50
|
|
|
1212 |
RING (1)
|
4931623636 |
4.50
|
|
|
1213 |
O-RING (1)
|
562597001 |
3.68
|
|
|
1214 |
SEAL RING (1)
|
4931396459 |
3.50
|
|
|
1215 |
SPRING RING (1)
|
4931384919 |
3.50
|
|
|
1217 |
SEAL RING (1)
|
4931624476 |
3.50
|
|
|
1219 |
SEAL RING (2)
|
4931624493 |
8.00
|
|
|
1220 |
HOLDING-DOWN DEVICE (1)
|
562578001 |
4.00
|
|
|
1222 |
SPRING RING (1)
|
4931624260 |
3.50
|
|
|
1226 |
FELT (1)
|
4931387563 |
3.50
|
|
|
1228 |
HOLDING-DOWN DEVICE (4)
|
4931332524 |
3.50
|
|
|
1230 |
O-RING N874701 25X2 (1)
|
4931624381 |
2.50
|
|
|
1300 |
REPAIR KIT (1)
|
4931432150 |
15.50
|
|
