Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
BALL BEARING (1)
|
02040845 |
6.00
|
|
|
0002 |
BALL BEARING (1)
|
02041020 |
6.00
|
|
|
0003 |
BALL BEARING (1)
|
02041516 |
7.00
|
|
|
0005 |
NEEDLE BEARING (1)
|
02501640 |
6.00
|
|
|
0006 |
SCREW (4)
|
05888309 |
2.50
|
|
|
0007 |
ECCENTRIC SHAFT (1)
|
06080017 |
3.00
|
|
|
0008 |
PIN (2)
|
4931473774 |
2.50
|
|
|
0010 |
BALANCE WEIGHT (1)
|
4931436025 |
2.50
|
|
|
0013 |
SCREW TORX SCREW (4)
|
06825314 |
2.50
|
|
|
0014 |
SCREW (5)
|
4931435228 |
2.50
|
|
|
0015 |
SCREW (6)
|
06827270 |
2.50
|
|
|
0016 |
SCREW (2)
|
4931436250 |
2.50
|
|
|
0017 |
SCREW (2)
|
4931506347 |
1.00
|
|
|
0018 |
SCREW (6)
|
4931453200 |
2.50
|
|
|
0021 |
RATING PLATE (1)
|
4931506348 |
1.00
|
|
|
0023 |
ARMATURE (1)
|
16340305 |
81.00
|
|
|
0025 |
ELECTRIC FIELD (1)
|
18320300 |
47.00
|
|
|
0028 |
CARBON HOLDER (2)
|
22200055 |
7.00
|
|
|
0029 |
CABLE (1)
|
22644523 |
28.00
|
|
|
0038 |
GEAR BOX HOUSING (1)
|
28140045 |
16.00
|
|
|
0039 |
GEAR BOX HOUSING (1)
|
28140046 |
13.50
|
|
|
0040 |
AIR FLOW PLATE (1)
|
31050195 |
3.50
|
|
|
0044 |
MOTOR HOUSING (1)
|
31500290 |
12.50
|
|
|
0045 |
BEVEL GEAR PAIR (1)
|
4931506349 |
34.00
|
|
|
0046 |
LOCKING RING (1)
|
34600810 |
4.00
|
|
|
0048 |
SPINDLE KIT (1)
|
38500076 |
10.00
|
|
|
0052 |
DISTANCE HOLDER (1)
|
4931436034 |
2.50
|
|
|
0053 |
ROLL (1)
|
4931436024 |
2.50
|
|
|
0056 |
ECCENTRIC WHEEL (1)
|
14090190 |
39.50
|
|
|
0058 |
PLATE (1)
|
4931436030 |
4.00
|
|
|
0060 |
STAMP (1)
|
4931436028 |
4.00
|
|
|
0062 |
INTERLOCK ELEMENT (1)
|
4931461444 |
22.50
|
|
|
0064 |
PLATE (1)
|
4931436036 |
2.50
|
|
|
0065 |
BEARING END PLATE (1)
|
44661070 |
4.00
|
|
|
0067 |
CABLE ENTRY SLEEVE (1)
|
44760210 |
2.50
|
|
|
0068 |
SLIDE BEARING (1)
|
14860105 |
26.50
|
|
|
0071 |
SEAL (1)
|
4931436021 |
2.50
|
|
|
0073 |
INSULATOR (1)
|
45122056 |
14.50
|
|
|
0076 |
STOP (1)
|
45160030 |
10.00
|
|
|
0079 |
GEAR BOX HOUSING (1)
|
14300145 |
40.50
|
|
|
0080 |
GEAR BOX HOUSING (1)
|
14300146 |
34.00
|
|
|
0082 |
TERMINAL (1)
|
22560451 |
3.00
|
|
|
0083 |
CARRYING CASE (1)
|
42552055 |
35.00
|
|
|
0100 |
SWITCH ASSEMBLY (1)
|
4931447859 |
32.50
|
|
|
0101 |
HANDLE SET (1)
|
4931506350 |
27.00
|
|
|
0110 |
CARBON BRUSH SET (1)
|
4931511231 |
15.00
|
|
