Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
BALL BEARING (1)
|
02040845 |
6.00
|
|
|
0002 |
BALL BEARING (1)
|
02040915 |
7.00
|
|
|
0003 |
BALL BEARING (1)
|
02041511 |
8.00
|
|
|
0004 |
NEEDLE BEARING (1)
|
02502150 |
6.00
|
|
|
0005 |
SCREW (4)
|
05880302 |
2.50
|
|
|
0006 |
NUT (1)
|
06553790 |
2.50
|
|
|
0007 |
DOWEL PIN (2)
|
06650045 |
3.50
|
|
|
0008 |
BOLT (1)
|
43360125 |
10.00
|
|
|
0009 |
BOLT (2)
|
06650505 |
3.50
|
|
|
0010 |
SCREW (3)
|
06827253 |
2.50
|
|
|
0011 |
SCREW (3)
|
06827255 |
2.50
|
|
|
0012 |
SCREW (6)
|
06827270 |
2.50
|
|
|
0013 |
SCREW (2)
|
06827326 |
2.50
|
|
|
0014 |
SCREW 8-16X2-1/4 PAN PLAS (2)
|
06827453 |
2.50
|
|
|
0015 |
SCREW (4)
|
06828870 |
2.50
|
|
|
0016 |
SCREW (1)
|
06830115 |
3.50
|
|
|
0017 |
CLAMP (1)
|
31170260 |
4.00
|
|
|
0018 |
CLAMP (1)
|
31170265 |
4.00
|
|
|
0019 |
RATING PLATE (1)
|
4931446869 |
2.50
|
|
|
0020 |
CLAMP (1)
|
22560625 |
4.00
|
|
|
0022 |
ECCENTRIC DISC (1)
|
14670126 |
46.00
|
|
|
0023 |
ECCENTRIC DISC (1)
|
Item discontinued
(14670136) |
|
|
|
0024 |
ARMATURE (1)
|
16340510 |
79.00
|
|
|
0025 |
ELECTRIC FIELD (1)
|
18341510 |
53.00
|
|
|
0026 |
CARBON BRUSH SET (2)
|
22200520 |
8.00
|
|
|
0027 |
CAPACITOR (1)
|
22330035 |
6.50
|
|
|
0028 |
CABLE ENTRY SLEEVE (1)
|
44760210 |
2.50
|
|
|
0029 |
WRENCH 3/16 (1)
|
49960080 |
3.50
|
|
|
0030 |
CLAMP (1)
|
42680685 |
19.00
|
|
|
0032 |
Wood Drill Selfeed Allen Key 5/32-1pc (1)
|
49960070 |
1.10
|
|
|
0033 |
SCREW SCREW-BLADE CLAMP (1)
|
06832976 |
3.50
|
|
|
0035 |
BEARING BUSH HALF (2)
|
14300080 |
9.00
|
|
|
0036 |
GEAR BOX HOUSING (1)
|
28142600 |
20.50
|
|
|
0037 |
PLATE (1)
|
28282600 |
10.00
|
|
|
0038 |
STOP DISC (1)
|
31050155 |
4.00
|
|
|
0039 |
PLATE (1)
|
31110130 |
5.00
|
|
|
0043 |
RIGHT HANDLE HALF (1)
|
31442090 |
7.00
|
|
|
0044 |
LEFT HANDLE HALF (1)
|
31442095 |
7.00
|
|
|
0047 |
MOTOR HOUSING (1)
|
4931454359 |
26.50
|
|
|
0049 |
LEVER (1)
|
31520045 |
5.00
|
|
|
0050 |
SHOE REL.LEVER KIT (1)
|
31520090 |
4.00
|
|
|
0051 |
GEAR (1)
|
32402050 |
8.50
|
|
|
0052 |
O-RING (2)
|
34400040 |
2.50
|
|
|
0054 |
RING (2)
|
34601315 |
2.50
|
|
|
0056 |
SHAFT (1)
|
36920701 |
34.00
|
|
|
0057 |
SPINDLE (1)
|
38506400 |
75.00
|
|
|
0059 |
DISC SPRING (1)
|
40508850 |
3.50
|
|
|
0060 |
REDUCT. GEAR SHAFT (1)
|
42120190 |
5.00
|
|
|
0061 |
ADAPTER SLEEVE (1)
|
42240066 |
8.00
|
|
|
0062 |
BEARING BUSH (1)
|
42240525 |
6.00
|
|
|
0063 |
RUBBER BUFFER (1)
|
42380055 |
4.00
|
|
|
0066 |
BEARING COVER (1)
|
42520380 |
2.50
|
|
|
0067 |
CLAMPING PIECE (1)
|
49225016 |
39.00
|
|
|
0068 |
BALANCE WEIGHT (1)
|
42870180 |
11.00
|
|
|
0069 |
PLATE (1)
|
43060676 |
2.50
|
|
|
0070 |
DISC PLATE (2)
|
43060685 |
4.00
|
|
|
0071 |
RETAINING RING (1)
|
34600125 |
2.50
|
|
|
0072 |
ECCENTRIC DISC (1)
|
43560620 |
4.00
|
|
|
0073 |
BUSH (1)
|
43780577 |
20.00
|
|
|
0075 |
PIN (1)
|
44601635 |
4.00
|
|
|
0077 |
HOLDER (1)
|
44660880 |
3.50
|
|
|
0079 |
PROTECTIVE CAP (1)
|
44860035 |
5.00
|
|
|
0080 |
BEARING CAGE (1)
|
44860655 |
4.00
|
|
|
0081 |
SEAL (1)
|
45060110 |
5.00
|
|
|
0082 |
SEAL RING (1)
|
45060475 |
3.50
|
|
|
0083 |
FELT PACKING (1)
|
45060501 |
2.50
|
|
|
0084 |
INSULATOR (1)
|
45120700 |
18.50
|
|
|
0086 |
DISTANCE HOLDER (1)
|
45160645 |
6.00
|
|
|
0088 |
SEAL RING (1)
|
45280555 |
4.00
|
|
|
0089 |
SPACER (1)
|
45361445 |
2.50
|
|
|
0090 |
WASHER (1)
|
Item discontinued
(45881555) |
|
|
|
0091 |
WASHER (1)
|
45888577 |
2.50
|
|
|
0092 |
COUPLING (1)
|
14080075 |
41.50
|
|
|
0093 |
CABLE (1)
|
22644523 |
28.00
|
|
|
0099 |
INTERLOCK ELEMENT (1)
|
4931461444 |
22.50
|
|
|
0100 |
SWITCH (1)
|
Item discontinued
(4931454350) |
|
|
|
0700 |
CARRYING CASE (1)
|
42552055 |
35.00
|
|
