Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0004 |
CONNECTION CABLE (1)
|
4931623311 |
12.00
|
|
|
0005 |
PROTECTING COVER (1)
|
4931409552 |
3.50
|
|
|
0006 |
RATING PLATE (1)
|
4931487010 |
1.00
|
|
|
0008 |
STICKER (1)
|
4931442232 |
2.50
|
|
|
0100 |
MOTOR HOUSING (1)
|
4931432246 |
9.50
|
|
|
0101 |
COVER (2)
|
4931378566 |
3.50
|
|
|
0105 |
ELECTRIC FIELD (1)
|
4931463367 |
43.00
|
|
|
0106 |
ARMATURE (1)
|
4931442665 |
52.00
|
|
|
0116 |
AIR DEFLECTOR RING (1)
|
4931395204 |
3.50
|
|
|
0117 |
HOLDING-DOWN DEVICE (2)
|
4931409768 |
4.50
|
|
|
0120 |
BRUSH HOLDER (2)
|
4931382268 |
5.00
|
|
|
0122 |
CABLE COLLAR (1)
|
4931256500 |
3.50
|
|
|
0127 |
ELECTRONIC ELEMENT (1)
|
4931463356 |
56.00
|
|
|
0129 |
BEARING SLEEVE (1)
|
4931326953 |
4.50
|
|
|
0131 |
CARBON BRUSH SET (1)
|
4931381391 |
12.00
|
|
|
0133 |
HANDLE (1)
|
4931378762 |
5.50
|
|
|
0135 |
SWITCH (1)
|
4931378949 |
16.00
|
|
|
0140 |
SEAL (1)
|
4931407251 |
3.50
|
|
|
0200 |
GEAR BOX (1)
|
4931407067 |
34.00
|
|
|
0201 |
SLEEVE N874989 HKO 0810 (1)
|
4931912093 |
3.50
|
|
|
0203 |
WASHER (1)
|
4931362085 |
2.50
|
|
|
0204 |
GROOVED BALL BEAR. (1)
|
4931368037 |
5.00
|
|
|
0205 |
DISC (1)
|
4931622761 |
3.50
|
|
|
0206 |
LOCKING RING (1)
|
4931616614 |
3.50
|
|
|
0207 |
LOCKING BOLT (1)
|
4931326929 |
3.50
|
|
|
0208 |
PRESSURE SPRING (1)
|
4931326942 |
3.50
|
|
|
0209 |
PUSH-BUTTON (1)
|
4931326930 |
3.50
|
|
|
0210 |
WASHER (1)
|
4931624287 |
2.50
|
|
|
0211 |
COMPENSATING WASHER (1)
|
4931254894 |
2.50
|
|
|
0212 |
SPINDLE (1)
|
4931409809 |
7.50
|
|
|
0213 |
BEARING END PLATE (1)
|
4931407097 |
22.00
|
|
|
0230 |
SPRING PLATE (1)
|
4931426499 |
3.50
|
|
|
0231 |
LOCKING PIECE (1)
|
4931407605 |
17.00
|
|
|
0420 |
BEVEL GEAR PAIR (1)
|
4931369887 |
28.00
|
|
|
0425 |
DISC N874237 12,2X22X0,1 (1)
|
4931808473 |
3.50
|
|
|
0426 |
DISC N874237 12,2X22X0,2 (1)
|
4931925940 |
3.50
|
|
|
0427 |
DISC (1)
|
4931624256 |
3.50
|
|
|
0450 |
DRIVE GEAR (1)
|
4931409561 |
56.00
|
|
|
0600 |
GUARD CAP (1)
|
4931395292 |
7.50
|
|
|
0601 |
CUTTING GUARD (1)
|
4931487335 |
9.00
|
|
|
0610 |
PLATE (1)
|
4931395289 |
3.50
|
|
|
0701 |
AUXILIARY HANDLE (1)
|
4931432245 |
9.50
|
|
|
0702 |
Fixtec Nut M14 universal-1pc (1)
|
4932498607 |
24.90
|
|
|
0704 |
CLAMPING FLANGE WS115-230 (1)
|
4932449324 |
6.70
|
|
|
1000 |
CONNECTION SET (1)
|
4931432260 |
13.50
|
|
