Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
MOTOR HOUSING (1)
|
4931435679 |
3.00
|
|
|
0002 |
CARBON BRUSH (2)
|
4931435680 |
7.00
|
|
|
0003 |
BRUSH HOLDER (2)
|
22220030 |
4.00
|
|
|
0004 |
WRENCH CHAIN (1)
|
Item discontinued
(49960345) |
|
|
|
0005 |
MOTOR HOUSING (1)
|
4931435681 |
9.50
|
|
|
0006 |
SPRING WASHER (1)
|
Item discontinued
(4931435682) |
|
|
|
0007 |
ELECTRIC FIELD (1)
|
4931440622 |
44.00
|
|
|
0008 |
RUBBER BUFFER (1)
|
4931435683 |
5.00
|
|
|
0009 |
ARMATURE (1)
|
4931435684 |
73.50
|
|
|
0010 |
SPINDLE LOCK (1)
|
4931435685 |
4.00
|
|
|
0011 |
SPINDLE LOCK (1)
|
4931435686 |
4.00
|
|
|
0012 |
O-RING (1)
|
34401375 |
2.50
|
|
|
0013 |
AIR DEFLECTOR RING (1)
|
4931435687 |
1.00
|
|
|
0014 |
SCREW (2)
|
Item discontinued
(660986001) |
|
|
|
0015 |
HANDLE (1)
|
4931435688 |
10.00
|
|
|
0016 |
SAFTY GUARD (1)
|
4931435689 |
3.50
|
|
|
0018 |
PROTECTING COVER (1)
|
Item discontinued
(4931435690) |
|
|
|
0019 |
LOCK (1)
|
4931435691 |
4.00
|
|
|
0020 |
FUSE (1)
|
4931435692 |
12.50
|
|
|
0021 |
SWITCH (1)
|
4931435693 |
21.00
|
|
|
0022 |
SCREW (4)
|
Item discontinued
(05780305) |
|
|
|
0023 |
SCREW (13)
|
06827270 |
2.50
|
|
|
0024 |
CABLE ENTRY SLEEVE (1)
|
44760210 |
2.50
|
|
|
0026 |
HANDLE (1)
|
4931435694 |
9.00
|
|
|
0027 |
GEAR BOX (1)
|
4931435695 |
52.00
|
|
|
0028 |
SCREW (1)
|
06755860 |
2.50
|
|
|
0029 |
NEEDLE BEARING (1)
|
4931435696 |
3.50
|
|
|
0030 |
GUARD (1)
|
42380222 |
2.50
|
|
|
0032 |
SCREW (1)
|
Item discontinued
(4931435697) |
|
|
|
0033 |
SPRING (1)
|
4931435698 |
2.50
|
|
|
0034 |
SCREW (1)
|
4931435699 |
1.00
|
|
|
0035 |
GUARD (1)
|
4931435700 |
3.00
|
|
|
0036 |
PUNCH GUIDE (1)
|
4931435701 |
3.00
|
|
|
0037 |
SCREW (3)
|
4931435702 |
2.50
|
|
|
0038 |
Lever for depth gauge (1)
|
4931435703 |
9.50
|
|
|
0041 |
BASE PLATE (1)
|
4931435704 |
19.00
|
|
|
0042 |
PIN (1)
|
44601180 |
4.00
|
|
|
0043 |
SCREW (4)
|
Item discontinued
(4931435705) |
|
|
|
0044 |
ECCENTRIC SHAFT (1)
|
4931435706 |
33.00
|
|
|
0045 |
PROTECTIVE SLEEVE (1)
|
4931435707 |
4.00
|
|
|
0046 |
SPRING (1)
|
40500045 |
2.50
|
|
|
0047 |
HOUSING (1)
|
4931435708 |
20.00
|
|
|
0048 |
THRUST COLLAR (1)
|
34600860 |
2.50
|
|
|
0049 |
GUARD (1)
|
4931435709 |
7.00
|
|
|
0050 |
FLANGE (1)
|
4931435710 |
5.00
|
|
|
0051 |
FLANGE (1)
|
4931435711 |
4.50
|
|
|
0052 |
SCREW (1)
|
660988001 |
2.50
|
|
|
0053 |
COVER (1)
|
Item discontinued
(4931435712) |
|
|
|
0054 |
SCREW TORX SCREW (16)
|
06825314 |
2.50
|
|
|
0055 |
STAMP (1)
|
4931435713 |
6.00
|
|
|
0056 |
SPRING (1)
|
4931435714 |
1.00
|
|
|
0057 |
CLAMPING BOLT (1)
|
4931435715 |
4.00
|
|
|
0058 |
GUARD (1)
|
Item discontinued
(4931435716) |
|
|
|
0059 |
COVER (1)
|
Item discontinued
(4931435717) |
|
|
|
0061 |
CONNECTION CABLE (1)
|
Item discontinued
(4931435718) |
|
|
|
0062 |
CABLE (1)
|
Item discontinued
(4931435719) |
|
|
|
0063 |
CAPACITOR (1)
|
4931435720 |
5.00
|
|
|
0070 |
RATING PLATE (1)
|
Item discontinued
(4931435721) |
|
|
|
0075 |
BALL BEARING (1)
|
4931435722 |
6.00
|
|
|
0076 |
BALL BEARING (1)
|
4931435723 |
6.00
|
|
|
0700 |
CARRYING CASE (1)
|
Item discontinued
(4931435724) |
|
|
