Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0002 |
FRAME (1)
|
Item discontinued
(692452001) |
|
|
|
0003 |
O-RING (1)
|
562464001 |
3.00
|
|
|
0004 |
COLLAR (1)
|
611045001 |
5.50
|
|
|
0005 |
SPRING (1)
|
692471001 |
3.00
|
|
|
0006 |
BOLT (1)
|
672320001 |
3.50
|
|
|
0007 |
FRICTION DISC (1)
|
611044001 |
5.00
|
|
|
0008 |
SPRING (1)
|
692472001 |
2.50
|
|
|
0009 |
SPINDLE (1)
|
Item discontinued
(692346001) |
|
|
|
0010 |
ROLLER (1)
|
692341001 |
4.00
|
|
|
0011 |
BOLT (1)
|
672341001 |
3.50
|
|
|
0012 |
GEAR BOX COVER (1)
|
303862001 |
15.00
|
|
|
0013 |
SCREW (2)
|
661113008 |
3.00
|
|
|
0014 |
BALL BEARING (1)
|
681326001 |
6.50
|
|
|
0015 |
ECCENTRIC STRAP (1)
|
303862002 |
17.50
|
|
|
0017 |
GEAR BOX (1)
|
Item discontinued
(201622011) |
|
|
|
0031 |
MOTOR SUPPORT (1)
|
Item discontinued
(4931441174) |
|
|
|
0032 |
FASTENING BOLT (2)
|
Item discontinued
(680334032) |
|
|
|
0034 |
MOTOR ASSEMBLY (1)
|
201622014 |
32.50
|
|
|
0040 |
SLIDER (1)
|
521360001 |
3.00
|
|
|
0042 |
SWITCH LEVER (1)
|
521359001 |
3.00
|
|
|
0043 |
SWITCH (1)
|
521358001 |
4.50
|
|
|
0045 |
SCREW (5)
|
660570005 |
3.00
|
|
|
0046 |
INDEXING SLEEVE (1)
|
633289001 |
4.00
|
|
|
0047 |
SPRING (1)
|
692505001 |
3.00
|
|
|
0048 |
HANDLE SET (1)
|
201488002 |
10.00
|
|
|
0049 |
SWITCH (1)
|
201622013 |
40.50
|
|
|
0050 |
JOINING PART (1)
|
631542001 |
3.50
|
|
|
0051 |
NAME PLATE (1)
|
Item discontinued
(940038174) |
|
|
|
0053 |
SCREW (1)
|
660230009 |
2.50
|
|
|
0054 |
SCREW (2)
|
661113001 |
2.50
|
|
|
0055 |
CLAMP (1)
|
632317002 |
7.50
|
|
|
0056 |
BALL BEARING (1)
|
Item discontinued
(681372001) |
|
|
|
0700 |
CARRYING CASE (1)
|
200230019 |
28.50
|
|
|
1000 |
GEARWHEEL SET (1)
|
4931448992 |
41.50
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
