Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0002 |
CAP (1)
|
4931435133 |
2.50
|
|
|
0007 |
COLLAR (1)
|
4931435138 |
3.50
|
|
|
0008 |
INTERLOCK SLEAVE (1)
|
4931435139 |
13.50
|
|
|
0011 |
SPRING (1)
|
4931435140 |
2.50
|
|
|
0012 |
PLATE (1)
|
633152001 |
3.50
|
|
|
0015 |
O-RING (1)
|
4931435143 |
5.00
|
|
|
0018 |
SPINDLE SLEEVE (1)
|
4931435146 |
147.00
|
|
|
0019 |
SNAP DIE (1)
|
4931435147 |
28.50
|
|
|
0021 |
AUXILIARY HANDLE (1)
|
4931435149 |
21.00
|
|
|
0022 |
SCREW (1)
|
4931435150 |
3.00
|
|
|
0023 |
RETAINER (1)
|
4931435151 |
3.50
|
|
|
0024 |
GEAR KIT (1)
|
4931435928 |
67.00
|
|
|
0027 |
PLATE (1)
|
4931435930 |
3.50
|
|
|
0028 |
FORK (1)
|
4931440524 |
5.50
|
|
|
0030 |
HOUSING (1)
|
Item discontinued
(4931435931) |
|
|
|
0033 |
SCREW (1)
|
4931435162 |
1.00
|
|
|
0034 |
SLEEVE (1)
|
4931435164 |
6.00
|
|
|
0035 |
INTERLOCK PLATE (1)
|
4931435165 |
3.50
|
|
|
0036 |
PISTON AND CON ROD ASSY (1)
|
4931435166 |
14.50
|
|
|
0037 |
EXCENTER (1)
|
4931435167 |
39.00
|
|
|
0040 |
MOTOR ASSEMBLY (1)
|
4931435193 |
79.50
|
|
|
0042 |
GEAR BOX ASSY (1)
|
4931435933 |
5.00
|
|
|
0043 |
AIR DEFLECTOR RING (1)
|
4931435174 |
2.50
|
|
|
0044 |
SCREW (1)
|
660024018 |
2.50
|
|
|
0045 |
MOTOR COVER (1)
|
4931435175 |
4.20
|
|
|
0046 |
SCREW (1)
|
4931435176 |
2.50
|
|
|
0053 |
FIELD LEAD GROMMET (1)
|
4931435182 |
7.50
|
|
|
0054 |
MOTOR HOUSING (1)
|
Item discontinued
(4931435934) |
|
|
|
0056 |
SCREW (2)
|
Item discontinued
(4931435183) |
|
|
|
0057 |
SWITCH (1)
|
4931435935 |
20.00
|
|
|
0058 |
ELECTRIC COMPLETE (1)
|
4931435185 |
37.28
|
|
|
0061 |
CONNECTOR (1)
|
790009001 |
3.50
|
|
|
0062 |
CONNECTION CABLE (1)
|
4931435187 |
20.00
|
|
|
0063 |
CORD GRIP (1)
|
4931435190 |
3.50
|
|
|
0070 |
DRIVER (1)
|
4931435195 |
66.50
|
|
|
0075 |
RING (1)
|
4931435200 |
16.00
|
|
|
0077 |
SPINDLE SLEEVE (1)
|
4931435202 |
43.00
|
|
|
0079 |
CLAMP (1)
|
4931435204 |
5.00
|
|
|
0080 |
NUT (1)
|
4931435205 |
3.50
|
|
|
0081 |
HANDLE (1)
|
4931435206 |
5.00
|
|
|
0082 |
HANDLE (1)
|
4931435207 |
8.00
|
|
|
0083 |
PROTECTION WASHER (1)
|
4931435192 |
2.50
|
|
|
0084 |
RATING PLATE (1)
|
4931435937 |
2.50
|
|
|
0150 |
SERVICE SET (1)
|
4931494483 |
36.00
|
|
|
0160 |
CARBON BRUSH SET (1)
|
4931511237 |
7.00
|
|
|
0700 |
CARRYING CASE (1)
|
4931435211 |
45.00
|
|
|
1200 |
MAINTENANCE SET (1)
|
4931446720 |
159.50
|
|
|
1201 |
RUBBER CAP (1)
|
4931435353 |
4.00
|
|
|
1203 |
HOLDING RING (1)
|
4931435134 |
2.50
|
|
|
1204 |
BACKING FLANGE (1)
|
4931435135 |
4.00
|
|
|
1205 |
O-RING (1)
|
4931435354 |
4.00
|
|
|
1206 |
WASHER (1)
|
4931435137 |
2.50
|
|
|
1209 |
WASHER (1)
|
4931431199 |
2.50
|
|
|
1210 |
HOLDING PLATE (1)
|
4931466761 |
4.00
|
|
|
1213 |
PROTECTION WASHER (1)
|
4931435141 |
2.50
|
|
|
1214 |
BEARING END PLATE (1)
|
4931435142 |
16.50
|
|
|
1216 |
CAM (1)
|
4931435144 |
8.00
|
|
|
1217 |
PERCUSSION BODY (1)
|
4931435145 |
36.00
|
|
|
1220 |
DISC (1)
|
4931435148 |
2.50
|
|
|
1225 |
BEARING AND ROTARY SEAL ASSY (1)
|
4931435929 |
11.50
|
|
|
1226 |
SEAL (1)
|
4931435155 |
7.00
|
|
|
1229 |
SCREW (1)
|
4931435158 |
2.50
|
|
|
1231 |
SET COLLAR (1)
|
4931435932 |
4.00
|
|
|
1232 |
DAMPING RING (1)
|
Item discontinued
(4931435360) |
|
|
|
1238 |
NEEDLE BEARING (2)
|
4931435168 |
6.00
|
|
|
1239 |
WASHER (1)
|
4931435169 |
2.50
|
|
|
1241 |
BALL BEARING (1)
|
4931435170 |
6.00
|
|
|
1249 |
CARBON BRUSH (1)
|
4931435177 |
7.00
|
|
|
1250 |
CARBON BRUSH (1)
|
4931435179 |
5.00
|
|
|
1251 |
BRUSH HOLDER (2)
|
4931435181 |
4.50
|
|
|
1252 |
SCREW (2)
|
661189001 |
2.50
|
|
|
1271 |
STOP WASHER (1)
|
4931435196 |
9.00
|
|
|
1272 |
RING (1)
|
4931435197 |
4.00
|
|
|
1273 |
RING (1)
|
4931435198 |
4.00
|
|
|
1274 |
PIN (1)
|
4931435199 |
2.50
|
|
|
1276 |
DISC (1)
|
4931435201 |
2.50
|
|
|
1278 |
O-RING (2)
|
4931435203 |
4.00
|
|
