Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
RUBBER RING (1)
|
4931436476 |
2.50
|
|
|
0009 |
SLEEVE (1)
|
4931436477 |
5.00
|
|
|
0010 |
SPRING (1)
|
4931436478 |
1.00
|
|
|
0011 |
DISC (1)
|
4931436479 |
1.00
|
|
|
0012 |
HOLDING RING (1)
|
4931436480 |
1.00
|
|
|
0016 |
SCREW (1)
|
4931436481 |
3.00
|
|
|
0017 |
PROTECTION WASHER (1)
|
680866003 |
3.00
|
|
|
0018 |
RACKING LEVER (1)
|
4931436482 |
2.50
|
|
|
0019 |
PUSH-BUTTON (1)
|
4931436483 |
3.50
|
|
|
0051 |
PRESSURE SPRING (1)
|
4931408243 |
4.00
|
|
|
0053 |
SPRING PLATE (2)
|
4931452341 |
3.00
|
|
|
0054 |
SLIDING SWITCH (1)
|
4931436484 |
2.00
|
|
|
0055 |
SWITCH LEVER (1)
|
4931436485 |
3.00
|
|
|
0061 |
SCREW (2)
|
4931435990 |
2.50
|
|
|
0065 |
RATING PLATE (1)
|
4931453826 |
2.50
|
|
|
0067 |
GEAR BOX HOUSING (1)
|
4931436487 |
75.00
|
|
|
0069 |
ANVIL (1)
|
4931436488 |
29.50
|
|
|
0070 |
IMPACT BOLT (1)
|
4931436489 |
38.50
|
|
|
0071 |
PLANET GEAR (1)
|
4931436490 |
9.00
|
|
|
0072 |
MOTOR (1)
|
4931511223 |
38.00
|
|
|
0073 |
SWITCH (1)
|
4931436492 |
72.00
|
|
|
0074 |
HOUSING (1)
|
4931453827 |
11.50
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
