Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
EJECTOR (1)
|
4931453091 |
25.50
|
|
|
0002 |
CHUCK SHROUD (1)
|
4931453092 |
65.50
|
|
|
0005 |
RETAINING RING (1)
|
4931453093 |
3.50
|
|
|
0006 |
BALL BEARING (1)
|
4931453094 |
5.50
|
|
|
0007 |
SCREW (4)
|
4931453095 |
2.50
|
|
|
0008 |
GEAR BOX ASSY (1)
|
Item discontinued
(4931453096) |
|
|
|
0010 |
RETAINING PLATE (1)
|
4931453097 |
2.50
|
|
|
0013 |
LOCKING ROD (1)
|
4931453098 |
11.00
|
|
|
0014 |
CABLE CLAMP (1)
|
4931453099 |
3.50
|
|
|
0015 |
SCREW (1)
|
4931453100 |
2.50
|
|
|
0016 |
CLAMPING LEVER (1)
|
4931456260 |
15.50
|
|
|
0017 |
GUIDE BOLT (1)
|
4931453101 |
2.50
|
|
|
0018 |
HOLDING BRACKET (1)
|
4931453102 |
4.00
|
|
|
0019 |
SPRING (1)
|
4931453103 |
3.50
|
|
|
0020 |
HOLDING BRACKET (1)
|
4931453104 |
3.50
|
|
|
0021 |
BALL BEARING (1)
|
4931453105 |
1.00
|
|
|
0022 |
SPRING (1)
|
4931453106 |
2.50
|
|
|
0023 |
OUTPUT SHAFT KIT (1)
|
4931453107 |
85.00
|
|
|
0024 |
GEAR (1)
|
4931453108 |
17.50
|
|
|
0025 |
COUPLING (1)
|
4931453109 |
5.00
|
|
|
0026 |
HUB (1)
|
4931453110 |
5.00
|
|
|
0027 |
GEAR (1)
|
4931453111 |
12.50
|
|
|
0028 |
WASHER 24x17,8x0,8 (1)
|
680335077 |
2.50
|
|
|
0029 |
RETAINING RING (1)
|
4931453112 |
4.00
|
|
|
0030 |
NEEDLE BEARING (1)
|
4931453113 |
10.50
|
|
|
0031 |
SEAL (1)
|
Item discontinued
(4931453114) |
|
|
|
0033 |
BALL BEARING (1)
|
02040640 |
6.00
|
|
|
0036 |
NEEDLE BEARING (1)
|
02502400 |
3.50
|
|
|
0037 |
SEAL (1)
|
4931453115 |
4.00
|
|
|
0038 |
FLAT GREASE NIPPLE (1)
|
4931454085 |
4.00
|
|
|
0040 |
BALL BEARING (1)
|
Item discontinued
(4931453116) |
|
|
|
0042 |
BALL BEARING (1)
|
4931453117 |
6.00
|
|
|
0044 |
GEAR (1)
|
Item discontinued
(4931453118) |
|
|
|
0045 |
NEEDLE BEARING (1)
|
4931453404 |
1.00
|
|
|
0048 |
SCREW (4)
|
Item discontinued
(4931453119) |
|
|
|
0049 |
CABLE CLAMP (2)
|
Item discontinued
(4931453120) |
|
|
|
0050 |
CABLE (1)
|
4931453121 |
34.00
|
|
|
0052 |
SCREW (4)
|
4931446540 |
2.50
|
|
|
0055 |
BALL BEARING (1)
|
4931436119 |
7.00
|
|
|
0056 |
WASHER (1)
|
4931453122 |
2.50
|
|
|
0057 |
ELECTRONIC (1)
|
4931453123 |
164.00
|
|
|
0059 |
SCREW (6)
|
660570005 |
2.50
|
|
|
0061 |
SCREW (4)
|
4931453124 |
2.50
|
|
|
0062 |
SWITCH COVER (1)
|
Item discontinued
(4931453125) |
|
|
|
0063 |
SPRING (1)
|
4931453126 |
4.00
|
|
|
0064 |
SCREW (4)
|
4931453127 |
2.50
|
|
|
0065 |
SCREW (7)
|
4931453124 |
2.50
|
|
|
0067 |
COVER PLATE (1)
|
4931466348 |
23.50
|
|
|
0068 |
BIT GUIDE (1)
|
4931453129 |
13.00
|
|
|
0069 |
BUSHING (2)
|
4931453130 |
12.50
|
|
|
0070 |
COMPENSATION PLATE (1)
|
4931453131 |
7.00
|
|
|
0076 |
SCREW (2)
|
4931453132 |
2.50
|
|
|
0077 |
HANDLE (1)
|
4931453133 |
13.00
|
|
|
0078 |
ELECTRIC ELEMENT (1)
|
4931453134 |
73.00
|
|
|
0079 |
SCREW (2)
|
Item discontinued
(4931453135) |
|
|
|
0080 |
SPINDLE LOCK (1)
|
4931453136 |
14.50
|
|
|
0081 |
OPERATING HANDLE (3)
|
4931453137 |
15.00
|
|
|
0083 |
SCREW (3)
|
Item discontinued
(4931435627) |
|
|
|
0084 |
SCREW (4)
|
4931453138 |
2.50
|
|
|
0086 |
ELECTRIC ELEMENT (1)
|
4931453139 |
17.00
|
|
|
0087 |
TOOTH RACK (1)
|
4931453140 |
19.00
|
|
|
0089 |
SCREW (3)
|
4931453141 |
2.50
|
|
|
0090 |
COVER (1)
|
4931453142 |
2.50
|
|
|
0092 |
MAGNETIC FOOT (1)
|
4931453143 |
164.00
|
|
|
0093 |
RIVET (1)
|
4931453144 |
3.50
|
|
|
0094 |
COVER (1)
|
Item discontinued
(4931453145) |
|
|
|
0095 |
SCREW (4)
|
Item discontinued
(661319001) |
|
|
|
0096 |
MAGNET (3)
|
Item discontinued
(4931453146) |
|
|
|
0097 |
THREADED SLEEVE (4)
|
Item discontinued
(4931453147) |
|
|
|
0099 |
SCREW (4)
|
4931453148 |
2.50
|
|
|
0100 |
CYLINDER PIN (1)
|
4931453149 |
4.00
|
|
|
0101 |
MAGNET (3)
|
Item discontinued
(4931453150) |
|
|
|
0102 |
LEDGE (1)
|
Item discontinued
(4931453151) |
|
|
|
0110 |
BUSHING (2)
|
4931453152 |
3.50
|
|
|
0111 |
SHAFT (1)
|
Item discontinued
(4931453153) |
|
|
|
0112 |
GEAR (1)
|
4931453154 |
4.00
|
|
|
0113 |
SWITCH (1)
|
4931453155 |
18.00
|
|
|
0114 |
MAGNET.DISC FASTEN. (1)
|
Item discontinued
(4931453156) |
|
|
|
0115 |
GEAR (1)
|
4931453157 |
8.00
|
|
|
0117 |
WASHER (1)
|
4931453158 |
2.50
|
|
|
0118 |
GEAR COVER (1)
|
4931453159 |
20.00
|
|
|
0119 |
BUSHING (1)
|
4931453160 |
3.50
|
|
|
0121 |
SCREW (2)
|
Item discontinued
(4931453161) |
|
|
|
0122 |
RUBBER RING (1)
|
4931453162 |
3.50
|
|
|
0123 |
SHAFT (1)
|
Item discontinued
(4931453163) |
|
|
|
0124 |
RETAINING RING (1)
|
4931453164 |
4.00
|
|
|
0125 |
FASTENING BOLT (2)
|
Item discontinued
(4931453165) |
|
|
|
0126 |
TURNING KNOB (1)
|
4931466349 |
3.50
|
|
|
0127 |
SCREW (6)
|
4931453167 |
2.50
|
|
|
0128 |
SWITCH COVER (1)
|
Item discontinued
(4931453168) |
|
|
|
0129 |
LEDGE (2)
|
Item discontinued
(4931453169) |
|
|
|
0131 |
PIN (2)
|
4931453170 |
2.50
|
|
|
0133 |
SCREW (2)
|
4931453171 |
2.50
|
|
|
0134 |
CYLINDER PIN (1)
|
4931453172 |
3.50
|
|
|
0150 |
HOLDING DEVICE (1)
|
4931453173 |
165.00
|
|
|
0151 |
MAGNETIC FOOT (1)
|
4931453174 |
119.00
|
|
|
0152 |
MAG. DRILL PIPE ADAPT.-1PC (1)
|
48100130 |
66.60
|
|
|
0153 |
GEAR BOX KIT (1)
|
4931453175 |
23.50
|
|
|
0155 |
KIT (1)
|
4931453176 |
513.00
|
|
|
0156 |
FEED SPINDLE (1)
|
4931453177 |
35.00
|
|
|
0163 |
HOUSING (1)
|
4931466350 |
42.00
|
|
|
0164 |
CYLINDER PIN (1)
|
Item discontinued
(4931453179) |
|
|
|
0170 |
REDUCTION GEAR (1)
|
4931453180 |
28.35
|
|
|
0171 |
REDUCTION GEAR (1)
|
4931453181 |
38.50
|
|
|
0172 |
KIT (1)
|
Item discontinued
(4931453182) |
|
|
|
0173 |
ARMATURE ASSEMBLY (1)
|
4931453183 |
71.50
|
|
|
0174 |
GEAR BOX ASSY (1)
|
4931453213 |
66.50
|
|
|
0175 |
TURNING KNOB (1)
|
4931453184 |
5.00
|
|
|
0176 |
KIT (1)
|
4931453185 |
30.00
|
|
|
0177 |
OIL CUP ASSEMBLY (1)
|
4931453186 |
27.50
|
|
|
0178 |
KIT (1)
|
4931453187 |
21.00
|
|
|
0179 |
VALVE (1)
|
4931453188 |
30.50
|
|
|
0182 |
HOUSING SET ASSY (1)
|
4931453189 |
24.50
|
|
|
0183 |
HOUSING (1)
|
4931453190 |
11.50
|
|
|
0184 |
EJECTOR (1)
|
4931453191 |
4.00
|
|
|
0186 |
BUSHING (1)
|
4931453192 |
3.50
|
|
|
0188 |
CHUCK W KEY AND ADAPT.-1PC (1)
|
49590020 |
47.70
|
|
|
0189 |
KEY HOLDER (1)
|
4931453193 |
2.50
|
|
|
0192 |
SAFETY STRAP (1)
|
4931453194 |
23.00
|
|
|
0195 |
RATING PLATE (1)
|
4931466351 |
1.00
|
|
|
0196 |
Adjust. washer set (1)
|
4931453196 |
13.50
|
|
|
0197 |
KIT (1)
|
4931453197 |
34.50
|
|
|
0700 |
CARRYING CASE (1)
|
4931466352 |
76.00
|
|
|
1000 |
GREASE (1)
|
Item discontinued
(49085270) |
|
|
