Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
10001 |
GUIDE BOLT (1)
|
4931453396 |
21.00
|
|
|
10002 |
GUIDE BAR (1)
|
4931453397 |
17.50
|
|
|
10003 |
CHUCK SHROUD (1)
|
4931453092 |
65.50
|
|
|
10006 |
RETAINING RING (1)
|
4931453093 |
3.50
|
|
|
10007 |
BALL BEARING (1)
|
4931453094 |
5.50
|
|
|
10008 |
SCREW (4)
|
4931453398 |
2.50
|
|
|
10009 |
SCREW (1)
|
4931453100 |
2.50
|
|
|
10010 |
CABLE CLAMP (1)
|
4931453099 |
3.50
|
|
|
10011 |
CLAMPING LEVER (1)
|
4931456260 |
15.50
|
|
|
10014 |
RETAINING PLATE (1)
|
4931453097 |
2.50
|
|
|
10015 |
GUIDE BOLT (1)
|
4931453101 |
2.50
|
|
|
10016 |
HOLDING BRACKET (1)
|
4931453102 |
4.00
|
|
|
10017 |
SPRING (1)
|
4931453103 |
3.50
|
|
|
10018 |
HOLDING BRACKET (1)
|
4931453104 |
3.50
|
|
|
10019 |
GEAR BOX (1)
|
Item discontinued
(4931453399) |
|
|
|
10020 |
LOCKING ROD (1)
|
4931453098 |
11.00
|
|
|
10022 |
BALL BEARING (1)
|
4931453105 |
1.00
|
|
|
10023 |
SPRING (1)
|
4931453106 |
2.50
|
|
|
10024 |
BALL BEARING (1)
|
02040640 |
6.00
|
|
|
10027 |
NEEDLE BEARING (1)
|
02502400 |
3.50
|
|
|
10028 |
WORM GEAR WHEEL (1)
|
4931453400 |
22.50
|
|
|
10029 |
HUB (1)
|
4931453110 |
5.00
|
|
|
10030 |
COUPLING (1)
|
4931453109 |
5.00
|
|
|
10031 |
WORM GEAR WHEEL (1)
|
4931453401 |
17.50
|
|
|
10032 |
WASHER 24x17,8x0,8 (1)
|
680335077 |
2.50
|
|
|
10033 |
RETAINING RING (1)
|
4931453112 |
4.00
|
|
|
10034 |
NEEDLE BEARING (1)
|
4931453113 |
10.50
|
|
|
10035 |
SEAL (1)
|
Item discontinued
(4931453114) |
|
|
|
10036 |
BALL BEARING (1)
|
4931453402 |
3.50
|
|
|
10038 |
WORM GEAR WHEEL (1)
|
4931453403 |
7.00
|
|
|
10039 |
NEEDLE BEARING (1)
|
4931453404 |
1.00
|
|
|
10040 |
SEAL (1)
|
4931453115 |
4.00
|
|
|
10043 |
BALL BEARING (2)
|
681337001 |
6.00
|
|
|
10046 |
SCREW (4)
|
4931436769 |
2.50
|
|
|
10052 |
SCREW (4)
|
660024030 |
2.50
|
|
|
10056 |
MOTOR HOUSING (1)
|
4931453406 |
11.50
|
|
|
10059 |
CLAMP (2)
|
4931453407 |
2.50
|
|
|
10060 |
PIN (1)
|
4931453408 |
2.50
|
|
|
10061 |
ELECTRIC FIELD (1)
|
4931453409 |
58.50
|
|
|
10062 |
SCREW (2)
|
4931453410 |
2.50
|
|
|
10063 |
WASHER (1)
|
4931453411 |
2.50
|
|
|
10064 |
AIR DEFLECTOR RING (1)
|
4931453412 |
2.50
|
|
|
10066 |
BUSHING (1)
|
4931453192 |
3.50
|
|
|
10104 |
KEY HOLDER (1)
|
4931453193 |
2.50
|
|
|
10109 |
SAFETY STRAP (1)
|
4931453194 |
23.00
|
|
|
10111 |
CYLINDER PIN (1)
|
4931453172 |
3.50
|
|
|
10112 |
WASHER (1)
|
Item discontinued
(4931453424) |
|
|
|
10113 |
WASHER (1)
|
4931453425 |
2.50
|
|
|
10116 |
EJECTOR (1)
|
4931453191 |
4.00
|
|
|
10118 |
PINION (1)
|
4931453426 |
36.00
|
|
|
10119 |
PINION (1)
|
4931453427 |
39.00
|
|
|
10120 |
GEAR BOX COVER (1)
|
4931453428 |
39.50
|
|
|
10153 |
TURNING KNOB (1)
|
4931453184 |
5.00
|
|
|
10173 |
MOTOR ASSEMBLY (1)
|
4931453430 |
69.50
|
|
|
10174 |
GEAR KIT (1)
|
4931453431 |
56.00
|
|
|
10175 |
CHUCK W KEY AND ADAPT.-1PC (1)
|
49590020 |
47.70
|
|
|
10176 |
KIT (1)
|
4931453185 |
30.00
|
|
|
10177 |
OUTPUT SHAFT KIT (1)
|
4931453107 |
85.00
|
|
|
10178 |
MOTOR HOUSING (1)
|
4931453460 |
15.50
|
|
|
10182 |
SWITCH KIT (1)
|
4931453433 |
6.00
|
|
|
10183 |
CARBON BRUSH SET (1)
|
4931453434 |
20.00
|
|
|
10195 |
RATING PLATE (1)
|
4931453463 |
2.50
|
|
|
10200 |
WIRE (1)
|
4931453438 |
42.50
|
|
|
11000 |
GREASE (1)
|
Item discontinued
(49085270) |
|
|
|
20044 |
SCREW (3)
|
4931453405 |
2.50
|
|
|
20068 |
SCREW (4)
|
4931453127 |
2.50
|
|
|
20069 |
SCREW (8)
|
4931453124 |
2.50
|
|
|
20071 |
BIT GUIDE (1)
|
4931453129 |
13.00
|
|
|
20072 |
BUSHING (2)
|
4931453130 |
12.50
|
|
|
20073 |
COMPENSATION PLATE (1)
|
4931453131 |
7.00
|
|
|
20080 |
SCREW (2)
|
4931453413 |
2.50
|
|
|
20081 |
ELECTRONIC (1)
|
4931453452 |
137.50
|
|
|
20082 |
SCREW (2)
|
4931453132 |
2.50
|
|
|
20083 |
CONNECTOR (1)
|
4931453415 |
3.00
|
|
|
20084 |
HANDLE (1)
|
4931453133 |
13.00
|
|
|
20085 |
CONNECTION CABLE (1)
|
4931453417 |
44.00
|
|
|
20086 |
SPINDLE LOCK (1)
|
4931453136 |
14.50
|
|
|
20088 |
OPERATING HANDLE (3)
|
4931453137 |
15.00
|
|
|
20089 |
CABLE CLAMP (1)
|
4931453418 |
2.50
|
|
|
20090 |
SCREW (3)
|
Item discontinued
(4931435627) |
|
|
|
20091 |
SCREW (4)
|
4931453138 |
2.50
|
|
|
20092 |
SWITCH (1)
|
4931453155 |
18.00
|
|
|
20093 |
SWITCH (1)
|
4931453455 |
15.00
|
|
|
20094 |
ELECTRIC ELEMENT (1)
|
4931453456 |
9.00
|
|
|
20096 |
TOOTH RACK (1)
|
4931453140 |
19.00
|
|
|
20098 |
SCREW (3)
|
4931453141 |
2.50
|
|
|
20099 |
SCREW (6)
|
4931453167 |
2.50
|
|
|
20100 |
MAG BASE PLATE (1)
|
4931453457 |
293.50
|
|
|
20108 |
TANK (1)
|
4931453423 |
8.00
|
|
|
20114 |
SCREW (2)
|
4931453171 |
2.50
|
|
|
20115 |
SWITCH COVER (1)
|
Item discontinued
(4931453168) |
|
|
|
20121 |
HOLDING DEVICE (1)
|
4931453173 |
165.00
|
|
|
20122 |
GEAR BOX KIT (1)
|
4931453175 |
23.50
|
|
|
20123 |
FEED SPINDLE (1)
|
4931453177 |
35.00
|
|
|
20166 |
MAGNET (1)
|
4931453429 |
21.00
|
|
|
20190 |
HOUSING (1)
|
4931453462 |
17.50
|
|
|
20196 |
Adjust. washer set (1)
|
4931453196 |
13.50
|
|
|
20199 |
FOOT (1)
|
4931453437 |
108.50
|
|
|
20700 |
CARRYING CASE (1)
|
4931453465 |
85.00
|
|
