Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1001 |
WASHER (1)
|
4931431103 |
2.50
|
|
|
1002 |
GUIDE BAR (1)
|
4931454194 |
5.00
|
|
|
1004 |
CAPACITOR (1)
|
4931454195 |
8.00
|
|
|
1005 |
POWER CORD (1)
|
4931454196 |
23.50
|
|
|
1006 |
PROTECTING COVER (1)
|
4931454198 |
4.00
|
|
|
1007 |
RETAINING PLATE (1)
|
4931454200 |
2.50
|
|
|
1008 |
SCREW (1)
|
Item discontinued
(4931454201) |
|
|
|
1010 |
TRIGGER (1)
|
Item discontinued
(4931454202) |
|
|
|
1012 |
CAP (1)
|
4931454203 |
2.50
|
|
|
1013 |
SCREW (13)
|
4931454205 |
2.50
|
|
|
1014 |
SCREW (1)
|
4931454205 |
2.50
|
|
|
1015 |
KNOB (1)
|
4931454207 |
4.00
|
|
|
1016 |
SCREW (5)
|
4931454208 |
2.50
|
|
|
1017 |
O-RING (1)
|
4931454209 |
2.50
|
|
|
1018 |
SOFT START (1)
|
4931454210 |
19.00
|
|
|
1022 |
SPRING (1)
|
4931454212 |
2.50
|
|
|
1027 |
SCREW (3)
|
4931454213 |
2.50
|
|
|
1028 |
SWING LEVER (1)
|
4931454214 |
2.50
|
|
|
1029 |
SAFTY GUARD (1)
|
4931454215 |
34.00
|
|
|
1030 |
CIRCLIP (1)
|
4931454216 |
2.50
|
|
|
1031 |
SPRING (1)
|
4931454217 |
2.50
|
|
|
1032 |
COVER (1)
|
4931454218 |
2.50
|
|
|
1034 |
SAFTY GUARD (1)
|
4931454219 |
20.00
|
|
|
1036 |
SCREW (2)
|
4931454220 |
2.50
|
|
|
1045 |
BALL BEARING (1)
|
4931454221 |
3.00
|
|
|
1046 |
RUBBER BUFFER (1)
|
4931454222 |
2.50
|
|
|
1047 |
COVER (1)
|
4931454223 |
2.50
|
|
|
1048 |
COVER PLATE (1)
|
Item discontinued
(4931454224) |
|
|
|
1049 |
HOLDING PIN (1)
|
4931454225 |
1.00
|
|
|
1050 |
DIRECT.DUST CHUTE (1)
|
4931454226 |
4.00
|
|
|
1051 |
FASTENING BOLT (1)
|
4931454227 |
2.50
|
|
|
1052 |
GEAR BOX ASSY (1)
|
4931454228 |
52.00
|
|
|
1053 |
SPRING (1)
|
4931454229 |
2.50
|
|
|
1054 |
BALL BEARING (1)
|
4931454230 |
6.00
|
|
|
1055 |
SPINDLE LOCK (1)
|
4931454231 |
4.00
|
|
|
1056 |
FAN HOUSING (1)
|
4931454232 |
4.00
|
|
|
1057 |
MOTOR ASSEMBLY (1)
|
4931454233 |
68.50
|
|
|
1058 |
BALL BEARING (1)
|
4931454235 |
7.00
|
|
|
1059 |
SCREW (2)
|
Item discontinued
(4931454236) |
|
|
|
1060 |
BEARING BUSH (1)
|
4931454237 |
2.50
|
|
|
1061 |
ELECTRIC FIELD (1)
|
4931454238 |
56.00
|
|
|
1062 |
HOUSING (1)
|
Item discontinued
(4931454240) |
|
|
|
1063 |
SCREW (3)
|
4931454241 |
2.50
|
|
|
1066 |
END COVER CAP (1)
|
4931454242 |
8.00
|
|
|
1067 |
BASE PLATE (1)
|
4931454243 |
53.50
|
|
|
1068 |
SCREW (1)
|
4931454244 |
2.50
|
|
|
1069 |
EXT. W. STOP GAUGE (1)
|
Item discontinued
(4931454245) |
|
|
|
1072 |
LOCK BOTTON (2)
|
Item discontinued
(4931454246) |
|
|
|
1073 |
WASHER (1)
|
4931454247 |
2.50
|
|
|
1075 |
SCREW (5)
|
4931454248 |
2.50
|
|
|
1076 |
GUIDE (1)
|
4931454249 |
6.00
|
|
|
1077 |
SCREW (1)
|
4931454250 |
2.50
|
|
|
1078 |
SPRING (1)
|
4931454251 |
2.50
|
|
|
1110 |
SWITCH (1)
|
4931454252 |
21.00
|
|
|
1111 |
FLANGE (1)
|
4931454253 |
10.00
|
|
|
1112 |
SPINDLE LOCK (1)
|
4931454254 |
27.50
|
|
|
1115 |
CARBON BRUSH (1)
|
4931454255 |
24.50
|
|
|
1116 |
AUXILIARY HANDLE (1)
|
Item discontinued
(4931454256) |
|
|
|
1118 |
PAIR HANDLE SHELLS (1)
|
4931454257 |
9.00
|
|
|
1119 |
RATING PLATE (1)
|
4931454258 |
2.50
|
|
