Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (4)
|
06956290 |
2.50
|
|
|
0002 |
SCREW (4)
|
4931454047 |
2.50
|
|
|
0004 |
CONNECTION CABLE (1)
|
4931454048 |
27.50
|
|
|
0008 |
CAPACITOR (1)
|
22330550 |
5.00
|
|
|
0009 |
RUBBER SLEEVE (1)
|
42960015 |
2.50
|
|
|
0010 |
BALL BEARING (1)
|
4931448859 |
6.00
|
|
|
0011 |
ELECTRIC FIELD (1)
|
4931454049 |
21.00
|
|
|
0012 |
ARMATURE (1)
|
4931454050 |
54.00
|
|
|
0013 |
GASKET (1)
|
4931454051 |
4.00
|
|
|
0016 |
O-RING (1)
|
Item discontinued
(34400070) |
|
|
|
0017 |
WASHER (1)
|
45883250 |
2.50
|
|
|
0018 |
GEAR (1)
|
32650005 |
11.50
|
|
|
0019 |
BEARING (3)
|
02503250 |
9.00
|
|
|
0020 |
PLANET GEAR (3)
|
32620200 |
2.50
|
|
|
0021 |
GEAR (1)
|
32600150 |
2.50
|
|
|
0022 |
GEAR (1)
|
32600175 |
5.00
|
|
|
0023 |
PLANET GEAR (5)
|
32620215 |
2.50
|
|
|
0024 |
BEARING (1)
|
02400050 |
6.00
|
|
|
0027 |
BALL (2)
|
02020250 |
2.50
|
|
|
0028 |
SPRING (1)
|
40500241 |
5.00
|
|
|
0029 |
BEARING (1)
|
02800200 |
6.00
|
|
|
0036 |
BALL BEARING (1)
|
680658012 |
8.00
|
|
|
0037 |
WASHER (1)
|
45881575 |
2.50
|
|
|
0041 |
SCREW (4)
|
4931454053 |
2.50
|
|
|
0042 |
WASHER (3)
|
45880535 |
2.50
|
|
|
0043 |
RAM (1)
|
44820210 |
37.00
|
|
|
0051 |
O-RING (1)
|
34401210 |
2.50
|
|
|
0052 |
RING (1)
|
44904540 |
4.00
|
|
|
0053 |
WIRE (1)
|
Item discontinued
(23940275) |
|
|
|
0054 |
WIRE (1)
|
Item discontinued
(23940276) |
|
|
|
0057 |
CARBON BRUSH (2)
|
4931454054 |
6.00
|
|
|
0062 |
GEAR BOX ASSY (1)
|
4931454055 |
13.50
|
|
|
0063 |
SHAFT (1)
|
14730300 |
32.00
|
|
|
0068 |
GEAR HEAD (1)
|
4931454062 |
33.00
|
|
|
0069 |
ANVIL (1)
|
14730156 |
25.20
|
|
|
0070 |
RATING PLATE (1)
|
4931454063 |
2.50
|
|
|
0073 |
BRUSH HOLDER (2)
|
4931454059 |
4.00
|
|
|
0080 |
SWITCH KIT (1)
|
4931454060 |
73.00
|
|
|
0081 |
HOUSING (1)
|
4931454061 |
25.50
|
|
