Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
BEARING BOLT (1)
|
4931461974 |
12.50
|
|
|
0002 |
SPRING (1)
|
4931454651 |
3.50
|
|
|
0006 |
ALLEN KEY (1)
|
4931461976 |
4.00
|
|
|
0007 |
FELT WASHER (1)
|
4931461977 |
5.50
|
|
|
0008 |
THRUST BEARING (1)
|
4931461978 |
33.00
|
|
|
0009 |
SCALE (1)
|
4931461979 |
14.50
|
|
|
0010 |
SCREW (4)
|
4931461980 |
4.00
|
|
|
0011 |
GUIDE KIT (1)
|
4931461981 |
81.50
|
|
|
0012 |
SCREW (4)
|
4931461982 |
4.00
|
|
|
0013 |
T-SCREW (2)
|
4931461983 |
5.00
|
|
|
0017 |
CLAMPING SCREW (1)
|
4931461984 |
4.00
|
|
|
0018 |
NUT (2)
|
4931461985 |
2.50
|
|
|
0019 |
SCREW (2)
|
4931461986 |
2.50
|
|
|
0020 |
SCREW (1)
|
4931461987 |
2.50
|
|
|
0021 |
SCREW (5)
|
4931461988 |
2.50
|
|
|
0022 |
POINTER (1)
|
4931461989 |
1.00
|
|
|
0023 |
SCREW (6)
|
4931461990 |
2.50
|
|
|
0025 |
SPRING (1)
|
4931454659 |
2.50
|
|
|
0031 |
ROD (1)
|
4931461991 |
5.00
|
|
|
0034 |
TABLE INSERT (1)
|
4931461992 |
5.00
|
|
|
0035 |
SCREW (6)
|
4931461993 |
2.50
|
|
|
0036 |
CLAMPING LEVER (1)
|
4931461994 |
4.00
|
|
|
0037 |
AXLE (1)
|
4931461995 |
3.50
|
|
|
0039 |
SCREW (4)
|
4931461996 |
2.50
|
|
|
0042 |
THREADED BOLT (1)
|
4931461997 |
5.50
|
|
|
0044 |
SCREW (2)
|
4931461998 |
2.50
|
|
|
0048 |
SET SCREW (1)
|
4931454626 |
2.50
|
|
|
0049 |
SCREW (10)
|
4931461999 |
2.50
|
|
|
0050 |
SUCTION SLEEVE (1)
|
4931465000 |
6.00
|
|
|
0055 |
CABLE CLAMP (1)
|
4931465001 |
2.50
|
|
|
0056 |
SPRING (1)
|
4931465002 |
2.50
|
|
|
0057 |
SCREW (2)
|
4931465003 |
3.50
|
|
|
0058 |
WASHER (2)
|
4931465004 |
2.50
|
|
|
0059 |
RUBBER STOP (2)
|
4931465005 |
3.50
|
|
|
0061 |
INDICATOR SET (1)
|
4931465006 |
2.50
|
|
|
0062 |
KNOB (1)
|
4931454649 |
5.50
|
|
|
0072 |
STOP (1)
|
4931454638 |
3.50
|
|
|
0073 |
SPINDLE LOCK (1)
|
4931454637 |
4.00
|
|
|
0074 |
O-RING (1)
|
4931454636 |
2.50
|
|
|
0077 |
WASHER (1)
|
4931465009 |
1.00
|
|
|
0078 |
T-NUT (1)
|
4931465010 |
5.50
|
|
|
0079 |
BOLT (1)
|
4931465011 |
4.00
|
|
|
0080 |
WASHER (2)
|
4931465012 |
1.00
|
|
|
0081 |
NUT (1)
|
4931465013 |
3.00
|
|
|
0083 |
SIDE SPRING (1)
|
4931465014 |
2.50
|
|
|
0084 |
LOCK COMPLETE (1)
|
4931465015 |
3.50
|
|
|
0085 |
TENSION SPRING (1)
|
4931465016 |
2.50
|
|
|
0087 |
SCREW (1)
|
4931465017 |
2.50
|
|
|
0090 |
LOOKED WASHER (1)
|
4931465018 |
2.50
|
|
|
0095 |
SCREW (1)
|
4931465019 |
2.50
|
|
|
0096 |
PLATE (1)
|
4931465020 |
2.50
|
|
|
0203 |
HOLDING PLATE (2)
|
4931465021 |
5.00
|
|
|
0217 |
DUST EXTRACTION (1)
|
4931465022 |
4.00
|
|
|
0225 |
BALL BEARING (1)
|
4931465023 |
5.00
|
|
|
0235 |
SCREW (6)
|
4931465024 |
2.50
|
|
|
0236 |
SCREW (11)
|
4931465025 |
3.50
|
|
|
0240 |
SWITCH (1)
|
4931465026 |
47.00
|
|
|
0243 |
SCREW (2)
|
4931465027 |
2.50
|
|
|
0245 |
SCREW (4)
|
4931465028 |
2.50
|
|
|
0253 |
SCREW (1)
|
4931465029 |
2.50
|
|
|
0601 |
SAW PROTECTION (1)
|
4931465030 |
44.00
|
|
|
0602 |
MOTOR SUPPORT (1)
|
4931465031 |
118.50
|
|
|
0603 |
INDICATOR SET (1)
|
4931465032 |
27.50
|
|
|
0604 |
ARMATURE (1)
|
4931465033 |
160.00
|
|
|
0606 |
SPINDLE KIT (1)
|
4931465034 |
76.50
|
|
|
0611 |
ELECTRIC FIELD (1)
|
4931507952 |
|
|
|
0613 |
GUIDE BAR (1)
|
4931465036 |
97.00
|
|
|
0614 |
COVER (1)
|
4931465037 |
15.50
|
|
|
0615 |
SAWING TABLE (1)
|
4931465038 |
164.00
|
|
|
0616 |
BASE PLATE (1)
|
4931465039 |
174.50
|
|
|
0617 |
DUST EXTRACTION (1)
|
4931465040 |
11.50
|
|
|
0618 |
LOCK COMPLETE (1)
|
4931465041 |
3.00
|
|
|
0619 |
COVER (1)
|
4931465042 |
39.50
|
|
|
0620 |
COVER (1)
|
4931465043 |
37.50
|
|
|
0621 |
CLAMPING PIECE (1)
|
4931465044 |
33.00
|
|
|
0622 |
GUIDE PIECE (1)
|
4931465045 |
117.50
|
|
|
0624 |
INDICATOR SET (1)
|
Item discontinued
(4931465046) |
|
|
|
0627 |
TRIGGER (1)
|
4931465047 |
6.00
|
|
|
0700 |
GUIDE SHAFT (1)
|
4931465048 |
20.00
|
|
|
0701 |
LOCKING PIECE (1)
|
4931465049 |
6.00
|
|
|
0702 |
GUIDE PIECE (1)
|
4931465050 |
7.00
|
|
|
0703 |
RETAINING SPRING (1)
|
4931465051 |
5.00
|
|
|
0704 |
RATING PLATE (1)
|
4931465052 |
3.00
|
|
|
0705 |
HOLDING GRIP (1)
|
4931465053 |
9.00
|
|
|
0706 |
HOUSING SET ASSY (1)
|
4931465054 |
9.00
|
|
|
0707 |
DUST BAG (1)
|
4931465055 |
19.00
|
|
|
0708 |
CLAMPING FLANGE (1)
|
4931465056 |
9.00
|
|
|
0709 |
HANDLE SET (1)
|
Item discontinued
(4931465057) |
|
|
|
0710 |
HOUSING (1)
|
4931465058 |
21.00
|
|
|
0711 |
YOKE (1)
|
4931465059 |
7.00
|
|
|
0712 |
ELECTRIC FIELD (1)
|
4931495467 |
300.00
|
|
|
0713 |
HANDLE SET (1)
|
4931506258 |
21.00
|
|
|
0714 |
ELECTRONIC (1)
|
4931511006 |
|
|
