Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0007 |
PIN (5)
|
4931465451 |
3.00
|
|
|
0010 |
RETAINING RING (1)
|
4931465452 |
2.50
|
|
|
0011 |
WASHER (1)
|
4931465453 |
2.50
|
|
|
0022 |
CABLE (1)
|
4931465454 |
28.50
|
|
|
0042 |
10mm x 15.2m Inner Core Coupling End (1)
|
48532773 |
152.90
|
|
|
0043 |
13mm x 15.2m Inner Core Coupling End (1)
|
48532774 |
188.50
|
|
|
0044 |
16mm x 15.2 Open Wind Coupling End (1)
|
48532775 |
200.30
|
|
|
0046 |
Medium Spade Bit for 10 13 16mm Cables (1)
|
48532788 |
26.70
|
|
|
0047 |
Medium Funnel Auger 10 13 16mm Cables (1)
|
48532786 |
26.70
|
|
|
0048 |
Medium C Cutter for 10 13 16mm Cables (1)
|
48532789 |
26.70
|
|
|
0049 |
Medium Drop Head for 10 13 16mm Cables (1)
|
48532787 |
23.50
|
|
|
0050 |
TOOL (1)
|
4931465455 |
3.50
|
|
|
0055 |
BEARING HOUSING (1)
|
4931465456 |
7.50
|
|
|
0056 |
HOUSING COVER (1)
|
4931465457 |
57.00
|
|
|
0057 |
BEARING HOUSING (1)
|
4931465458 |
7.50
|
|
|
0058 |
FEEDER ROLLER (1)
|
4931465459 |
10.00
|
|
|
0059 |
MOULDED PART (1)
|
Item discontinued
(4931465460) |
|
|
|
0060 |
GUIDE PIECE (1)
|
4931465461 |
6.50
|
|
|
0061 |
ROD (2)
|
4931465462 |
6.50
|
|
|
0062 |
LATCH (3)
|
4931465463 |
7.50
|
|
|
0063 |
HOUSING BOTTOM (1)
|
4931465464 |
83.50
|
|
|
0070 |
RATING PLATE (1)
|
4931465465 |
2.50
|
|
|
0071 |
SCREW (4)
|
4931465466 |
3.00
|
|
|
0072 |
SCREW (43)
|
4931454853 |
2.50
|
|
|
0073 |
BELT (1)
|
4931465467 |
56.00
|
|
|
0074 |
PLATE (1)
|
4931465468 |
101.00
|
|
|
0075 |
SCREW (8)
|
4931436390 |
1.00
|
|
|
0076 |
STRAP (1)
|
4931465469 |
4.00
|
|
|
0077 |
PIN (1)
|
4931465470 |
2.50
|
|
|
0078 |
SCREW (15)
|
4931465471 |
2.50
|
|
|
0079 |
BELT GUARD (1)
|
4931465472 |
5.50
|
|
|
0080 |
RETAINER (1)
|
4931465473 |
9.50
|
|
|
0081 |
SWITCH MOUNTING (1)
|
4931465474 |
3.00
|
|
|
0082 |
HOUSING (1)
|
4931465475 |
41.50
|
|
|
0083 |
SWITCH BOARD (1)
|
4931465476 |
3.50
|
|
|
0084 |
SLIDING SWITCH (1)
|
4931465477 |
3.00
|
|
|
0085 |
LABEL (1)
|
4931465478 |
5.00
|
|
|
0086 |
BALL BEARING (1)
|
4931436014 |
4.00
|
|
|
0087 |
SCREW (8)
|
4931465479 |
2.50
|
|
|
0088 |
BUSHING (2)
|
4931465480 |
4.00
|
|
|
0089 |
HOLDER (1)
|
4931465481 |
6.00
|
|
|
0090 |
HOLDER (1)
|
4931465482 |
5.50
|
|
|
0091 |
STRAP (1)
|
4931465483 |
31.50
|
|
|
0092 |
HOUSING (1)
|
4931465484 |
50.00
|
|
|
0093 |
TERMINAL STRIP (1)
|
4931465485 |
17.50
|
|
|
0094 |
FEEDER ROLLER (2)
|
4931465486 |
12.50
|
|
|
0095 |
TENSIONING DEVICE (1)
|
4931465487 |
31.50
|
|
|
0096 |
FEEDER ROLLER (1)
|
4931465488 |
10.00
|
|
|
0097 |
MOTOR ASSEMBLY (1)
|
4931465489 |
44.00
|
|
|
0098 |
MOTOR HOUSING (1)
|
4931465490 |
9.00
|
|
|
0099 |
ELECTRONIC (1)
|
4931465491 |
187.00
|
|
|
0100 |
BASIC SOCKET (1)
|
4931465492 |
45.00
|
|
|
0102 |
HOUSING BOTTOM (1)
|
4931465493 |
34.00
|
|
|
0103 |
SLIDER (1)
|
4931465494 |
15.50
|
|
|
0104 |
GEAR CASE (1)
|
4931465495 |
54.00
|
|
|
0105 |
FOOT PEDAL (1)
|
4931465496 |
82.00
|
|
|
0106 |
PLUG (1)
|
4931466591 |
7.50
|
|
