Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0005 |
RATING PLATE (1)
|
4931468813 |
2.50
|
|
|
0015 |
TYPE PLATE (1)
|
4931468814 |
1.00
|
|
|
0020 |
STICKER (1)
|
4931463581 |
2.50
|
|
|
0100 |
CAP (1)
|
4931463388 |
74.50
|
|
|
0105 |
CAP (1)
|
4931463404 |
80.50
|
|
|
0110 |
CAP (1)
|
4931463402 |
86.50
|
|
|
0115 |
CAP (1)
|
4931463403 |
76.50
|
|
|
0116 |
STOPPER (1)
|
4931468402 |
2.50
|
|
|
0120 |
ROCKER BAR (1)
|
4931463602 |
12.00
|
|
|
0125 |
ROCKER BAR (1)
|
4931463600 |
12.50
|
|
|
0130 |
AUXILIARY HANDLE (1)
|
4931463601 |
16.50
|
|
|
0135 |
CYLINDER (4)
|
4931463605 |
2.50
|
|
|
0140 |
COVER (1)
|
4931463640 |
7.50
|
|
|
0145 |
SWITCH LEVER (1)
|
4931463617 |
14.00
|
|
|
0150 |
PLATE SPRING (1)
|
4931463516 |
76.50
|
|
|
0155 |
SWITCH (1)
|
4931468826 |
49.00
|
|
|
0160 |
CYLINDER PIN (1)
|
4931463456 |
2.50
|
|
|
0165 |
RUBBER SLEEVE (1)
|
4931463656 |
12.00
|
|
|
0170 |
GRIP CLAMP (5)
|
4931463500 |
2.50
|
|
|
0175 |
SCREW (12)
|
4931463505 |
2.50
|
|
|
0180 |
SCREW (20)
|
4931468355 |
1.00
|
|
|
0185 |
WASHER (2)
|
4931463421 |
1.50
|
|
|
0190 |
CABLE (1)
|
4931463553 |
60.00
|
|
|
0195 |
SCREW (1)
|
4931463194 |
2.50
|
|
|
0200 |
WASHER (1)
|
4931463422 |
2.50
|
|
|
0205 |
SCREW (10)
|
4931463507 |
2.50
|
|
|
0210 |
SCREW (6)
|
4931463506 |
2.50
|
|
|
0215 |
SCREW (1)
|
4931463424 |
2.50
|
|
|
0220 |
PIN (1)
|
4931463425 |
1.00
|
|
|
0225 |
SCREW (1)
|
4931463427 |
2.50
|
|
|
0230 |
PARALLEL KEY (1)
|
4931463428 |
3.00
|
|
|
0235 |
WASHER (1)
|
4931468057 |
5.00
|
|
|
0240 |
GROOV. BALL BEARING (2)
|
4931463435 |
14.00
|
|
|
0245 |
COVER (1)
|
4931463562 |
29.00
|
|
|
0255 |
GROOV. BALL BEARING (1)
|
4931463543 |
8.50
|
|
|
0260 |
NEEDLE BEARING (1)
|
4931463444 |
35.50
|
|
|
0265 |
CRANKCASE (1)
|
4931468071 |
134.50
|
|
|
0270 |
GREASE NIPPLE (1)
|
4931463618 |
2.50
|
|
|
0275 |
SEAL (1)
|
4931463563 |
7.50
|
|
|
0280 |
SPACER (1)
|
4931468058 |
2.50
|
|
|
0285 |
STOP (1)
|
4931463552 |
13.00
|
|
|
0290 |
WASHER (1)
|
4931468060 |
2.50
|
|
|
0295 |
GEAR (1)
|
4931468061 |
38.00
|
|
|
0300 |
GEAR (1)
|
4931468062 |
78.00
|
|
|
0305 |
INSIDE RING (1)
|
4931463472 |
30.00
|
|
|
0310 |
NEEDLE BUSH (1)
|
4931463475 |
19.00
|
|
|
0315 |
O-RING (1)
|
4931463476 |
3.00
|
|
|
0320 |
COVER (1)
|
4931463595 |
9.00
|
|
|
0325 |
WASHER (1)
|
4931463477 |
2.50
|
|
|
0330 |
HAMMER CAS.MACHINED (1)
|
4931463710 |
227.00
|
|
|
0335 |
ARMATURE ASSEMBLY (1)
|
4931468815 |
177.50
|
|
|
0340 |
FIELD LEAD GROMMET (1)
|
4931468816 |
347.50
|
|
|
0345 |
WOBBLE DRIVE (1)
|
4931476018 |
61.00
|
|
|
0350 |
BEARING END PLATE (1)
|
4931468073 |
22.00
|
|
|
0355 |
BELLOWS (1)
|
4931463519 |
7.50
|
|
|
0360 |
RING (1)
|
4931463642 |
1.00
|
|
|
0365 |
RING (1)
|
4931463643 |
2.50
|
|
|
0370 |
RING (1)
|
4931463644 |
2.50
|
|
|
0375 |
RING (1)
|
4931463646 |
2.50
|
|
|
0380 |
RING (1)
|
4931463650 |
2.50
|
|
|
0385 |
O-RING (1)
|
4931463651 |
2.50
|
|
|
0390 |
RING (1)
|
4931463647 |
1.00
|
|
|
0395 |
GROOVED BALL BEAR. (1)
|
4931463654 |
17.50
|
|
|
0400 |
SCREW (4)
|
4931463546 |
5.50
|
|
|
0440 |
HOLDING RING (1)
|
4931463619 |
14.50
|
|
|
0505 |
COVER (1)
|
4931463631 |
10.00
|
|
|
0510 |
COVER (1)
|
4931463564 |
4.50
|
|
|
0515 |
AIR GUIDE (1)
|
4931463625 |
19.50
|
|
|
0520 |
ELECTRONIC (1)
|
4931487641 |
390.00
|
|
|
0525 |
SCREW (5)
|
4931468355 |
1.00
|
|
|
0530 |
SCREW (2)
|
4931463505 |
2.50
|
|
|
0600 |
CYLINDER (1)
|
4931468068 |
261.00
|
|
|
0605 |
BUSH (1)
|
4931468076 |
147.50
|
|
|
0610 |
CONNECTING ROD (1)
|
4931468811 |
78.00
|
|
|
0615 |
O-RING (2)
|
4931463545 |
4.50
|
|
|
0620 |
PERCUSSION BODY (1)
|
4931463142 |
129.00
|
|
|
0625 |
PISTON (1)
|
4931468070 |
208.50
|
|
|
0630 |
BOLT (1)
|
4931468065 |
6.00
|
|
|
0635 |
SPRING RING (1)
|
4931463538 |
2.50
|
|
|
0640 |
SCREW (2)
|
4931463035 |
24.50
|
|
|
0650 |
CYLINDER (1)
|
4931468818 |
407.00
|
|
|
0700 |
TOOL ACCEPTANCE (1)
|
4931463040 |
283.50
|
|
|
0701 |
TOOL ACCEPTANCE (1)
|
4931463039 |
228.50
|
|
|
0702 |
FLANGE (1)
|
4931463038 |
37.50
|
|
|
0703 |
RING (1)
|
4931463009 |
2.50
|
|
|
0704 |
RING (1)
|
4931463010 |
2.50
|
|
|
0705 |
TOOL ACCEPTANCE (1)
|
4931476039 |
135.00
|
|
|
0706 |
HOLDING BRACKET (1)
|
4931463172 |
67.50
|
|
|
0707 |
DAMPING RING (2)
|
4931463967 |
17.00
|
|
|
0708 |
LOCKING BOLT (1)
|
4931455903 |
14.50
|
|
|
0709 |
COLLAR (1)
|
4931463493 |
14.00
|
|
|
1100 |
CLAMPING SET (1)
|
4931476010 |
6.00
|
|
|
1200 |
CARTRIDGE (1)
|
4931468054 |
27.00
|
|
