Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (15)
|
4931465326 |
1.58
|
|
|
0002 |
SCREW (1)
|
4931454800 |
1.58
|
|
|
0004 |
BALANCE WEIGHT (1)
|
4931479323 |
14.00
|
|
|
0005 |
TERMINAL PLUG (1)
|
4931479324 |
4.73
|
|
|
0006 |
CONNECTOR (1)
|
4931479325 |
1.05
|
|
|
0007 |
TRIGGER (1)
|
4931454802 |
3.15
|
|
|
0008 |
SPRING (1)
|
4931454803 |
1.58
|
|
|
0010 |
SPRING PLATE (1)
|
4931452341 |
1.58
|
|
|
0011 |
SWITCH LEVER (1)
|
4931479326 |
2.63
|
|
|
0012 |
SWITCH ASSEMBLY (1)
|
4931479327 |
28.35
|
|
|
0014 |
SPRING (1)
|
4931454808 |
1.58
|
|
|
0015 |
TRIGGER (1)
|
4931454801 |
3.68
|
|
|
0017 |
NUT (8)
|
4931479328 |
1.58
|
|
|
0019 |
SCREW (6)
|
4931465533 |
1.58
|
|
|
0020 |
NUT (2)
|
4931479029 |
1.58
|
|
|
0021 |
SCREW (2)
|
4931479329 |
1.58
|
|
|
0023 |
COUPLING (1)
|
4931479330 |
3.15
|
|
|
0024 |
COUPLING (1)
|
4931479331 |
3.15
|
|
|
0025 |
SCREW (2)
|
4931479332 |
1.58
|
|
|
0026 |
TUBE (1)
|
4931479333 |
16.00
|
|
|
0032 |
SCREW (4)
|
4931465543 |
1.50
|
|
|
0042 |
SCREW (4)
|
660570005 |
1.58
|
|
|
0052 |
BEARING END PLATE (1)
|
4931479334 |
3.15
|
|
|
0053 |
SCREW (5)
|
4931472832 |
1.58
|
|
|
0054 |
LOCKING PLATE (1)
|
4931479335 |
10.00
|
|
|
0070 |
SPINDLE GEAR (1)
|
4931479336 |
32.55
|
|
|
0071 |
ROTOR (1)
|
4931479337 |
30.00
|
|
|
0072 |
ELECTRONIC (1)
|
4931479338 |
91.83
|
|
|
0073 |
HANDLE SET (1)
|
4931479339 |
28.35
|
|
|
0080 |
HANDLE COMPL. (1)
|
4931479340 |
35.70
|
|
|
0081 |
RATING PLATE (1)
|
4931495487 |
1.00
|
|
|
0082 |
TUBE (1)
|
4931479342 |
26.00
|
|
|
0084 |
MOTOR HOUSING (1)
|
4931479343 |
27.30
|
|
|
0085 |
GUARD (1)
|
4931479344 |
34.65
|
|
|
0086 |
GEAR CASE (1)
|
4931479345 |
21.00
|
|
|
0087 |
HOLDING PIN (1)
|
4931454818 |
1.58
|
|
|
0088 |
KEY (1)
|
4931454817 |
1.58
|
|
|
0089 |
Easy Load Trimmer Head Gen II 1pc (1)
|
4932480180 |
44.00
|
|
|
0090 |
Trimmer Line 2mm x 45m - 1PC (1)
|
49162712 |
29.50
|
|
|
0091 |
Trimmer Line 2.4m x 76m - 1PC (1)
|
49162713 |
47.30
|
|
|
0092 |
FOAM (1)
|
4931479346 |
1.05
|
|
|
0093 |
FOAM (2)
|
4931479347 |
1.05
|
|
|
1000 |
GEAR GREASE (1)
|
4931443288 |
32.55
|
|
