Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0002 |
GEAR HEAD (1)
|
4931479580 |
35.00
|
|
|
0005 |
TURNING KNOB (1)
|
4931479581 |
9.50
|
|
|
0006 |
SPINDLE SLEEVE (1)
|
4931479582 |
91.50
|
|
|
0007 |
WASHER (1)
|
4931479583 |
2.50
|
|
|
0008 |
BEARING BRACKET (1)
|
4931479584 |
6.00
|
|
|
0009 |
STRIKER (1)
|
4931479585 |
22.50
|
|
|
0010 |
PISTON (1)
|
4931479586 |
17.00
|
|
|
0011 |
CRANK PIN (1)
|
4931479587 |
4.50
|
|
|
0012 |
WASHER (2)
|
4931479588 |
2.50
|
|
|
0015 |
GEAR CASE (1)
|
4931479589 |
20.00
|
|
|
0016 |
FELT (3)
|
4931436536 |
4.00
|
|
|
0017 |
BALL BEARING (1)
|
4931479590 |
3.00
|
|
|
0020 |
SCREW (1)
|
4931479591 |
2.50
|
|
|
0021 |
RETAINER (1)
|
4931479592 |
3.00
|
|
|
0022 |
SCREW (2)
|
4931466678 |
1.00
|
|
|
0023 |
COVER (1)
|
4931479593 |
26.00
|
|
|
0025 |
WOBBLE DRIVE (1)
|
4931494322 |
77.00
|
|
|
0027 |
ROTOR (1)
|
4931494323 |
70.50
|
|
|
0029 |
COVER (1)
|
4931479596 |
2.50
|
|
|
0031 |
AUXILIARY HANDLE (1)
|
4931479597 |
18.00
|
|
|
0032 |
DEPTH GAUGE (1)
|
4931479598 |
4.00
|
|
|
0050 |
RUBBER CAP (1)
|
561993001 |
2.50
|
|
|
0051 |
RING (2)
|
4931436764 |
2.50
|
|
|
0052 |
SLEEVE (1)
|
4931479599 |
5.50
|
|
|
0053 |
BALL (2)
|
4931453606 |
4.00
|
|
|
0054 |
PLATE (1)
|
4931436765 |
3.50
|
|
|
0055 |
SPRING (1)
|
4931453607 |
3.00
|
|
|
0056 |
LOCKING PLATE (1)
|
4931479600 |
6.50
|
|
|
0057 |
DRIVE GEAR (1)
|
4931479601 |
15.00
|
|
|
0058 |
SNAP RING (1)
|
4931479602 |
2.50
|
|
|
0059 |
WASHER (1)
|
633525001 |
2.50
|
|
|
0060 |
SPRING (1)
|
4931479603 |
2.50
|
|
|
0061 |
SLEEVE (1)
|
4931479604 |
4.00
|
|
|
0062 |
AXLE WOBBLE (1)
|
4931479605 |
22.00
|
|
|
0063 |
CLAMPING PIECE (1)
|
4931479606 |
2.50
|
|
|
0064 |
SCREW (2)
|
4931479607 |
4.50
|
|
|
0065 |
ELECTRONIC (1)
|
4931479608 |
147.00
|
|
|
0066 |
HOUSING (1)
|
4931479609 |
40.00
|
|
|
0067 |
SLIDER (1)
|
4931479610 |
2.50
|
|
|
0068 |
RATING PLATE (1)
|
4931494324 |
2.50
|
|
|
0069 |
SPRING PLATE (1)
|
4931479612 |
2.50
|
|
|
0095 |
STOP WASHER (1)
|
4931479613 |
6.50
|
|
|
0096 |
CHUCK (1)
|
4931479614 |
11.00
|
|
|
0702 |
INSERT (1)
|
4931479615 |
23.00
|
|
|
0703 |
HDBOX2FUEL HD BOX 2 FUEL XXX (1)
|
4932498753 |
49.90
|
|
|
0704 |
INSERT (1)
|
4931507267 |
18.00
|
|
|
1000 |
SCREW (1)
|
4931479616 |
8.50
|
|
|
1200 |
O-RING (1)
|
4931479617 |
10.50
|
|
|
1300 |
GEAR GREASE (1)
|
4931443288 |
33.00
|
|
|
0701 |
HD Box 3 - 1pc (1)
|
4932453386 |
55.20
|
|
