Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
GEAR (1)
|
4931479159 |
188.00
|
|
|
0002 |
SPRING (2)
|
4931479160 |
2.50
|
|
|
0003 |
INSERT (2)
|
4931479161 |
14.00
|
|
|
0006 |
DISC (1)
|
4931479162 |
7.00
|
|
|
0007 |
RETAINING PLATE (1)
|
4931479163 |
15.00
|
|
|
0008 |
SCREW (6)
|
4931479164 |
2.50
|
|
|
0009 |
SCREW (8)
|
4931479165 |
1.50
|
|
|
0010 |
SCREW (1)
|
4931466683 |
1.00
|
|
|
0039 |
GUIDE BOLT (2)
|
4931453101 |
2.50
|
|
|
0040 |
BRACKET (1)
|
4931479166 |
4.50
|
|
|
0041 |
SPRING (1)
|
4931479167 |
2.50
|
|
|
0042 |
BRACKET (1)
|
4931479168 |
5.00
|
|
|
0044 |
NUT (1)
|
671686001 |
3.50
|
|
|
0045 |
PINION (1)
|
4931479169 |
9.50
|
|
|
0047 |
BEARING CAGE (1)
|
672569001 |
2.50
|
|
|
0048 |
SCREW (2)
|
4931465856 |
2.00
|
|
|
0049 |
RETAINING PLATE (1)
|
4931479170 |
2.50
|
|
|
0053 |
WASHER (1)
|
Item discontinued
(632876001) |
|
|
|
0054 |
ROTOR (1)
|
4931479171 |
78.00
|
|
|
0062 |
SLIDER (1)
|
4931479172 |
2.50
|
|
|
0063 |
LENS (1)
|
4931479173 |
3.00
|
|
|
0065 |
SCREW (4)
|
4931479174 |
3.50
|
|
|
0066 |
SCREW (9)
|
06827261 |
2.50
|
|
|
0072 |
RATING PLATE (1)
|
4931479175 |
2.50
|
|
|
0081 |
SPRING PLATE (2)
|
4931452341 |
2.50
|
|
|
0090 |
RUBBER BUMPER (2)
|
4931479176 |
4.50
|
|
|
0091 |
WASHER (1)
|
4931479177 |
34.00
|
|
|
0092 |
GEAR CASE (1)
|
4931479178 |
79.00
|
|
|
0093 |
RUBBER DISC (1)
|
4931479179 |
23.50
|
|
|
0094 |
DRIVING SHAFT (1)
|
4931479180 |
85.50
|
|
|
0095 |
DRIVING SHAFT (1)
|
4931479181 |
106.50
|
|
|
0096 |
DRIVING SHAFT (1)
|
4931479182 |
118.00
|
|
|
0097 |
DRIVING SHAFT (1)
|
4931479183 |
84.00
|
|
|
0098 |
DRIVING SHAFT (1)
|
4931479184 |
38.00
|
|
|
0099 |
CLAMP (1)
|
4931479185 |
143.00
|
|
|
0100 |
GEAR BOX COVER (1)
|
4931479186 |
144.00
|
|
|
0101 |
TURNING KNOB (1)
|
4931479187 |
9.00
|
|
|
0102 |
ELECTRONIC (1)
|
4931479188 |
371.50
|
|
|
0103 |
CAP (1)
|
4931479189 |
3.50
|
|
|
0104 |
HOUSING (1)
|
4931479190 |
65.00
|
|
|
0700 |
CARRYING CASE (1)
|
4931479191 |
107.00
|
|
|
1000 |
GREASE (1)
|
Item discontinued
(49085270) |
|
|
