Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SAFTY GUARD (1)
|
4931494769 |
11.00
|
|
|
0002 |
SAW CHAIN TOP HANDLE 325LP X 356 X 1.1 (1)
|
4932480178 |
36.70
|
|
|
0003 |
GUIDE BAR 14IN/35CM M18 FTHCHS35 (1)
|
4932480173 |
52.90
|
|
|
0004 |
SCREW (2)
|
4931453127 |
1.58
|
|
|
0005 |
HANDLE (1)
|
4931494739 |
8.00
|
|
|
0006 |
OPERATING HANDLE (1)
|
4931494740 |
10.50
|
|
|
0007 |
SCREW (1)
|
4931465908 |
1.58
|
|
|
0008 |
SCREW (8)
|
4931465909 |
1.58
|
|
|
0011 |
SCREW (2)
|
4931436686 |
1.58
|
|
|
0013 |
GASKET (1)
|
4931494741 |
1.05
|
|
|
0016 |
SCREW (1)
|
4931465913 |
1.58
|
|
|
0017 |
O-RING (1)
|
4931465914 |
1.58
|
|
|
0018 |
CONNECTOR (1)
|
4931465915 |
3.15
|
|
|
0019 |
SWITCH (1)
|
4931465916 |
2.63
|
|
|
0020 |
HOLDING RING (1)
|
4931465917 |
1.58
|
|
|
0021 |
SCREW (8)
|
660024030 |
1.58
|
|
|
0025 |
SCREW (4)
|
4931435150 |
1.58
|
|
|
0029 |
SCREW (2)
|
4931435474 |
1.58
|
|
|
0031 |
WASHER (1)
|
4931494742 |
1.05
|
|
|
0032 |
PINION (1)
|
4931494743 |
12.00
|
|
|
0033 |
NUT (1)
|
4931494744 |
2.63
|
|
|
0037 |
CORE LIFTER RING (1)
|
4931465928 |
2.63
|
|
|
0038 |
SCREW (3)
|
4931465929 |
1.58
|
|
|
0041 |
SCREW (1)
|
4931494745 |
1.05
|
|
|
0042 |
TUBE (1)
|
4931494746 |
2.63
|
|
|
0045 |
NUT (1)
|
4931465951 |
1.58
|
|
|
0048 |
PAD (1)
|
4931494747 |
1.05
|
|
|
0049 |
SNAP RING (1)
|
4931472833 |
1.58
|
|
|
0050 |
WRENCH (1)
|
4931465931 |
6.00
|
|
|
0051 |
RETAINING PLATE (1)
|
4931465940 |
1.58
|
|
|
0052 |
SPRING (1)
|
4931465941 |
1.58
|
|
|
0054 |
BUSH (1)
|
4931465943 |
2.63
|
|
|
0055 |
BOLT (1)
|
4931465944 |
4.73
|
|
|
0056 |
CLUTCH DISC (1)
|
4931494748 |
13.00
|
|
|
0057 |
WASHER (1)
|
4931494749 |
1.05
|
|
|
0058 |
CROSS BRACKET (1)
|
4931494750 |
7.00
|
|
|
0059 |
SCREW (1)
|
4931465949 |
8.00
|
|
|
0060 |
CROSS BRACKET (1)
|
4931494751 |
9.00
|
|
|
0061 |
LEVER (1)
|
4931494752 |
1.05
|
|
|
0062 |
SPRING (1)
|
4931494753 |
1.05
|
|
|
0067 |
RATING PLATE (1)
|
4931494770 |
1.05
|
|
|
0080 |
HOUSING (1)
|
4931494755 |
55.65
|
|
|
0081 |
STATOR (1)
|
4931507240 |
207.00
|
|
|
0082 |
COVER CAP (1)
|
4931473747 |
9.00
|
|
|
0083 |
TANK (1)
|
4931494757 |
18.90
|
|
|
0084 |
ROTOR (1)
|
4931494758 |
72.45
|
|
|
0085 |
OIL PUMP (1)
|
4931494759 |
27.30
|
|
|
0086 |
GEAR CASE (1)
|
4931494760 |
36.00
|
|
|
0087 |
SPIKE (1)
|
4931494761 |
6.00
|
|
|
0088 |
HOOK (1)
|
4931494762 |
7.00
|
|
|
0089 |
COVER ASSY (1)
|
4931494763 |
48.30
|
|
|
0090 |
GUIDE KIT (1)
|
4931494764 |
16.80
|
|
|
0091 |
BRAKE DISC (1)
|
4931494765 |
21.00
|
|
|
0092 |
COVER (1)
|
4931494766 |
12.60
|
|
|
0093 |
GUARD CAP SET (1)
|
4931494767 |
10.00
|
|
|
0094 |
MOTOR COVER (1)
|
4931494768 |
8.00
|
|
|
0100 |
HANDLE HOUSING KIT (1)
|
4931507687 |
60.00
|
|
