Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1008 |
FRAME (1)
|
4931494484 |
28.35
|
|
|
1015 |
SCREW (4)
|
4931494485 |
1.05
|
|
|
1017 |
SCREW (4)
|
4931494486 |
1.05
|
|
|
1018 |
COVER (5)
|
4931494487 |
1.05
|
|
|
1045 |
HANDLE LEFT (1)
|
4931494488 |
31.50
|
|
|
1063 |
RATING PLATE (1)
|
4931494489 |
53.55
|
|
|
1129 |
WASHER (4)
|
4931494490 |
1.05
|
|
|
1131 |
WASHER (16)
|
4931494491 |
1.05
|
|
|
2007 |
BALL BEARING (1)
|
4931494492 |
6.30
|
|
|
2016 |
SCREW (8)
|
4931494493 |
2.63
|
|
|
2022 |
COVER (1)
|
4931494494 |
3.15
|
|
|
2023 |
HOLDER (1)
|
4931494495 |
1.05
|
|
|
2029 |
COUPLING (1)
|
4931494496 |
1.05
|
|
|
2040 |
SCREW (11)
|
4931494497 |
2.63
|
|
|
2041 |
SCREW (3)
|
4931494498 |
2.63
|
|
|
2047 |
HOUSING (1)
|
4931494499 |
90.30
|
|
|
2090 |
RETAINING RING (1)
|
4931494500 |
1.05
|
|
|
2096 |
SCREW (4)
|
4931494501 |
1.05
|
|
|
2098 |
SCREW (2)
|
4931494502 |
1.05
|
|
|
2099 |
SCREW (2)
|
4931494503 |
2.63
|
|
|
2103 |
SCREW (4)
|
4931494504 |
1.05
|
|
|
2108 |
COUPLING (1)
|
4931494505 |
11.55
|
|
|
2109 |
MOTOR HOUSING (1)
|
4931494506 |
2.63
|
|
|
2110 |
SUPPORTING PLATE (1)
|
4931494507 |
2.63
|
|
|
2124 |
CONNECTOR (1)
|
4931494508 |
2.63
|
|
|
2202 |
SERVICE KIT (1)
|
4931494509 |
282.45
|
|
|
2204 |
COUPLING (1)
|
4931494510 |
263.55
|
|
|
2210 |
SERVICE-KIT (1)
|
4931494511 |
262.50
|
|
|
2211 |
ISOLATION (1)
|
4931494512 |
263.55
|
|
|
2213 |
MOTOR HOUSING (1)
|
4931494513 |
260.53
|
|
|
2215 |
STATOR (1)
|
4931494514 |
267.75
|
|
|
2217 |
SERVICE KIT (1)
|
4931494515 |
34.65
|
|
|
2218 |
SHAFT (1)
|
4931494516 |
346.50
|
|
|
2232 |
ROTOR (1)
|
4931494517 |
630.00
|
|
|
3001 |
CLAMP CLIP (1)
|
4931480035 |
2.63
|
|
|
3046 |
HOLDER (1)
|
4931494518 |
1.05
|
|
|
3072 |
ELECTRONIC (1)
|
4931480603 |
8.40
|
|
|
3087 |
SCREW (5)
|
4931480041 |
1.05
|
|
|
3095 |
SPACER (1)
|
4931494519 |
3.15
|
|
|
3102 |
SCREW (19)
|
4931494520 |
2.63
|
|
|
3118 |
SCREW (2)
|
4931480042 |
1.05
|
|
|
3119 |
SCREW (3)
|
4931480615 |
2.63
|
|
|
3120 |
SCREW (8)
|
4931494521 |
1.05
|
|
|
3132 |
COVER (1)
|
4931494522 |
2.63
|
|
|
3133 |
WRENCH (1)
|
4931494523 |
24.06
|
|
|
3205 |
SERVICE SET (1)
|
4931494524 |
735.00
|
|
|
3208 |
SERVICE KIT (1)
|
4931494525 |
945.00
|
|
|
3220 |
HOLDER (1)
|
4931494526 |
243.60
|
|
|
3221 |
LATCH (1)
|
4931494527 |
438.48
|
|
|
3240 |
COVER CAP (1)
|
4931494528 |
242.55
|
|
|
3241 |
HOUSING (1)
|
4931494529 |
420.00
|
|
|
4004 |
CLAMP (2)
|
4931494530 |
10.50
|
|
|
4024 |
CLAMPING PIECE (1)
|
4931494531 |
3.15
|
|
|
4031 |
COVER (1)
|
4931494532 |
5.25
|
|
|
4036 |
COVER (1)
|
4931494533 |
4.20
|
|
|
4055 |
LEVER (1)
|
4931494534 |
2.63
|
|
|
4094 |
RUBBER PLATE (1)
|
4931494535 |
2.63
|
|
|
4097 |
SCREW (4)
|
4931494536 |
2.63
|
|
|
4122 |
COVER (1)
|
4931494537 |
91.35
|
|
|
4125 |
SWITCH (1)
|
4931494538 |
19.95
|
|
|
4200 |
HANDLE SET (2)
|
4931494539 |
271.95
|
|
|
4201 |
HANDLE (1)
|
4931494540 |
328.71
|
|
|
4206 |
SERVICE-KIT (1)
|
4931494541 |
247.80
|
|
|
4207 |
SERVICE KIT (1)
|
4931494542 |
247.80
|
|
|
4212 |
SERVICE SET (1)
|
4931494543 |
250.95
|
|
|
4216 |
HOLDER (1)
|
4931494544 |
267.10
|
|
|
4233 |
SERVICE SET (1)
|
4931494545 |
412.65
|
|
|
1001 |
CONNECTOR (1)
|
4931599230 |
1363.32
|
|
