Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SNAP RING (1)
|
4931494044 |
2.50
|
|
|
0002 |
WASHER (1)
|
4931466862 |
2.50
|
|
|
0003 |
SPRING (1)
|
4931440467 |
2.50
|
|
|
0004 |
SLEEVE (1)
|
4931454722 |
5.00
|
|
|
0005 |
BALL (1)
|
4931494045 |
2.50
|
|
|
0006 |
SPRING (1)
|
4931466863 |
1.00
|
|
|
0007 |
HOLDING RING (1)
|
4931454723 |
2.50
|
|
|
0008 |
RETAINING RING (1)
|
4931494046 |
2.50
|
|
|
0009 |
GEAR CASE (1)
|
4931494047 |
20.00
|
|
|
0010 |
ANVIL (1)
|
4931494048 |
17.00
|
|
|
0035 |
SLIDER (1)
|
4931494049 |
2.50
|
|
|
0037 |
CONNECTOR (1)
|
4931436292 |
2.50
|
|
|
0040 |
SCREW (9)
|
4931465499 |
2.50
|
|
|
0049 |
RATING PLATE (1)
|
4931494050 |
2.50
|
|
|
0051 |
GEAR BOX ASSY (1)
|
4931494051 |
51.50
|
|
|
0052 |
RAM SET (1)
|
4931494052 |
54.00
|
|
|
0053 |
BEARING END PLATE (1)
|
4931494053 |
14.00
|
|
|
0054 |
ELECTRONIC (1)
|
4931508587 |
90.00
|
|
|
0055 |
ROTOR (1)
|
4931494054 |
37.00
|
|
|
0056 |
HOUSING (1)
|
4931494055 |
20.00
|
|
|
0057 |
BELT CLIP (1)
|
4931494056 |
7.50
|
|
|
0060 |
BITHOLDER (1)
|
4931494057 |
7.50
|
|
|
0701 |
HD Box 1 - 1pc (1)
|
4932453385 |
47.30
|
|
|
0702 |
INSERT (1)
|
4931494059 |
11.00
|
|
