Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (4)
|
4931453095 |
2.50
|
|
|
0004 |
SEAL RING (2)
|
4931495756 |
6.50
|
|
|
0005 |
BUSH (1)
|
4931495757 |
14.50
|
|
|
0007 |
OUTPUT SHAFT KIT (1)
|
4931495758 |
225.00
|
|
|
0030 |
PROTECTION WASHER (3)
|
Item discontinued
(4931453937) |
|
|
|
0031 |
GEAR (1)
|
4931495759 |
105.00
|
|
|
0062 |
SEAL (1)
|
4931495760 |
6.00
|
|
|
0068 |
SCREW (14)
|
4931472805 |
2.50
|
|
|
0078 |
SEAL RING (1)
|
4931495761 |
3.00
|
|
|
0098 |
SCREW (7)
|
4931465543 |
2.50
|
|
|
0109 |
ELECT.CIRCUIT BOARD (1)
|
4931495762 |
11.50
|
|
|
0110 |
SCREW (5)
|
4931472941 |
1.00
|
|
|
0111 |
CLAMP CLIP (2)
|
4931472938 |
1.00
|
|
|
0115 |
BUTTON (1)
|
4931495763 |
3.00
|
|
|
0116 |
BUTTON (1)
|
4931495764 |
2.50
|
|
|
0133 |
GEAR BOX HOUSING (1)
|
4931495765 |
20.00
|
|
|
0136 |
SWITCH (1)
|
4931495766 |
10.50
|
|
|
0144 |
TUBE (1)
|
4931495767 |
43.00
|
|
|
0155 |
RATING PLATE (1)
|
4931495768 |
2.50
|
|
|
0170 |
GUIDE RAIL SET (1)
|
4931495769 |
187.00
|
|
|
0171 |
ELECTRONIC (1)
|
4931495770 |
525.00
|
|
|
0172 |
HOUSING (1)
|
4931495771 |
150.00
|
|
|
0173 |
COVER (1)
|
4931495772 |
9.00
|
|
|
0174 |
LABEL (1)
|
4931495773 |
16.00
|
|
|
0175 |
BRACKET (1)
|
4931495774 |
99.00
|
|
|
0176 |
ROTOR (1)
|
4931495775 |
132.50
|
|
|
0177 |
MOTOR (1)
|
4931495776 |
101.00
|
|
|
0180 |
SEAL (1)
|
4931495777 |
13.00
|
|
|
0181 |
GEAR BOX HOUSING (1)
|
4931495778 |
120.00
|
|
|
0182 |
SHAFT (1)
|
4931495779 |
53.00
|
|
|
0183 |
KNOB (1)
|
4931495780 |
10.00
|
|
|
0184 |
SEAL (1)
|
4931495781 |
10.00
|
|
|
0185 |
FIXTURE (1)
|
4931495782 |
225.00
|
|
|
0186 |
CLUTCH SHAFT (1)
|
4931495783 |
240.00
|
|
|
0187 |
SHAFT (1)
|
4931495784 |
225.00
|
|
|
0188 |
INDICATOR LIGHT (1)
|
4931495785 |
19.00
|
|
|
0189 |
SHAFT (1)
|
4931495786 |
19.00
|
|
|
0190 |
DIAPHRAGM (1)
|
4931495787 |
113.00
|
|
