Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (6)
|
4931435015 |
2.50
|
|
|
0003 |
SCREW (11)
|
4931494423 |
1.00
|
|
|
0008 |
SCREW (36)
|
4931479948 |
2.50
|
|
|
0026 |
GUIDE TUBE (1)
|
4931496474 |
10.00
|
|
|
0027 |
COVER (1)
|
4931496475 |
40.00
|
|
|
0030 |
COVER (1)
|
4931496476 |
2.50
|
|
|
0032 |
SCREW (4)
|
4931436686 |
2.50
|
|
|
0033 |
CLAMP (1)
|
4931495949 |
1.00
|
|
|
0036 |
STRAINING SCREW (1)
|
4931496477 |
2.50
|
|
|
0038 |
SCREW (4)
|
4931496478 |
1.00
|
|
|
0039 |
SCREW (2)
|
4931496479 |
1.00
|
|
|
0040 |
CLIP (1)
|
4931496480 |
3.50
|
|
|
0041 |
HARNESS (1)
|
4931496481 |
75.00
|
|
|
0042 |
SCREW (8)
|
4931496270 |
1.00
|
|
|
0043 |
ELECTRONIC (1)
|
4931496482 |
270.00
|
|
|
0044 |
SCREW (2)
|
4931473267 |
1.00
|
|
|
0045 |
RING (1)
|
4931496483 |
2.50
|
|
|
0046 |
CLAMP (1)
|
4931496484 |
3.00
|
|
|
0049 |
CLAMP (1)
|
4931496485 |
3.00
|
|
|
0050 |
INSIDE RING (1)
|
4931496486 |
3.00
|
|
|
0051 |
TUBE (1)
|
4931496487 |
10.50
|
|
|
0052 |
LOCK (1)
|
4931496488 |
2.50
|
|
|
0054 |
PIN (1)
|
4931496489 |
3.50
|
|
|
0055 |
WIRE (1)
|
4931496490 |
1.00
|
|
|
0056 |
BRACKET (1)
|
4931496491 |
2.50
|
|
|
0057 |
LEVER (1)
|
4931496492 |
2.50
|
|
|
0059 |
O-RING (1)
|
4931496493 |
1.00
|
|
|
0060 |
PUSH-BUTTON (1)
|
4931496494 |
2.50
|
|
|
0061 |
CAM (1)
|
4931496495 |
2.50
|
|
|
0062 |
O-RING (1)
|
4931496496 |
1.00
|
|
|
0063 |
SCREW (1)
|
4931496497 |
1.00
|
|
|
0066 |
SCREW (1)
|
4931461935 |
2.50
|
|
|
0067 |
ADAPTER (1)
|
4931496498 |
8.00
|
|
|
0068 |
COUPLING (1)
|
4931496499 |
13.00
|
|
|
0069 |
TUBE (1)
|
4931496500 |
16.50
|
|
|
0075 |
BELT CLIP (1)
|
4931496501 |
33.00
|
|
|
0082 |
RATING PLATE (1)
|
4931496502 |
1.00
|
|
|
0085 |
ALLEN KEY (1)
|
4931496238 |
3.50
|
|
|
0090 |
HOLDING PLATE (1)
|
4931496503 |
69.00
|
|
|
0091 |
BATTERY BOX (1)
|
4931496504 |
37.00
|
|
|
0092 |
MOTOR ASSEMBLY (1)
|
4931496953 |
121.00
|
|
|
0095 |
ELECTRONIC (1)
|
4931496508 |
60.00
|
|
|
0096 |
HANDLE SET (1)
|
4931496509 |
27.00
|
|
|
0097 |
NOZZLE (1)
|
Item discontinued
(4931494439) |
|
|
|
0098 |
NOZZLE (1)
|
Item discontinued
(4931494440) |
|
|
|
0099 |
COVER ASSY (1)
|
4931496510 |
53.00
|
|
|
0100 |
HOLDING BRACKET (1)
|
4931496511 |
38.00
|
|
