Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1030 |
WASHER (6)
|
4931506685 |
1.00
|
|
|
1054 |
BASE PLATE (1)
|
4931506686 |
1200.00
|
|
|
1057 |
SCREW (12)
|
4931506687 |
2.50
|
|
|
1060 |
SCREW (5)
|
4931506688 |
2.50
|
|
|
1068 |
BASE PLATE (1)
|
4931506689 |
391.00
|
|
|
1214 |
GUARD (1)
|
4931506690 |
77.00
|
|
|
1215 |
BELT (1)
|
4931506691 |
195.00
|
|
|
1216 |
HANDLE SET (4)
|
4931506692 |
66.00
|
|
|
1217 |
RUBBER BUMPER (1)
|
4931506693 |
72.00
|
|
|
2007 |
BEARING (2)
|
4931506694 |
3.00
|
|
|
2039 |
GROMMET (1)
|
4931506695 |
1.00
|
|
|
2048 |
FOOT (1)
|
4931506696 |
112.00
|
|
|
2053 |
CLAMP (1)
|
4931506697 |
1.00
|
|
|
2064 |
NUT (2)
|
4931506698 |
2.50
|
|
|
2065 |
SCREW (2)
|
4931506699 |
11.00
|
|
|
2073 |
WIRE (1)
|
4931506700 |
48.00
|
|
|
2093 |
FOOT (1)
|
4931506701 |
112.00
|
|
|
2099 |
SCREW (1)
|
4931506702 |
14.00
|
|
|
2103 |
SCREW (1)
|
4931506703 |
13.00
|
|
|
2120 |
WASHER (2)
|
4931506704 |
3.00
|
|
|
2132 |
WASHER (1)
|
4931506705 |
15.00
|
|
|
2218 |
ISOLATION (2)
|
4931506706 |
139.00
|
|
|
2219 |
KNOB (2)
|
4931506707 |
60.50
|
|
|
2227 |
SUPPORT (1)
|
4931506708 |
45.00
|
|
|
2228 |
SERVICE KIT (1)
|
4931506709 |
69.00
|
|
|
2229 |
ELECTRONIC (1)
|
4931506710 |
80.00
|
|
|
2230 |
CABLE CLAMP (1)
|
4931506711 |
27.00
|
|
|
2231 |
HANDLE SET (1)
|
4931506712 |
397.00
|
|
|
3032 |
FRAME (1)
|
4931506713 |
102.00
|
|
|
3033 |
FRAME (1)
|
4931506714 |
102.00
|
|
|
3034 |
LABEL (1)
|
4931506715 |
57.00
|
|
|
3056 |
SCREW (4)
|
4931506716 |
2.50
|
|
|
3143 |
RATING PLATE (1)
|
4931506717 |
39.00
|
|
|
3200 |
RUBBER BUMPER (1)
|
4931506718 |
41.00
|
|
|
3201 |
PLATE (1)
|
4931506719 |
248.00
|
|
|
3203 |
TUBE (1)
|
4931506720 |
11.00
|
|
|
4011 |
WASHER (2)
|
4931506721 |
2.50
|
|
|
4024 |
HOUSING (1)
|
4931506722 |
106.00
|
|
|
4025 |
SHAFT (1)
|
4931506723 |
794.00
|
|
|
4026 |
SCREW (9)
|
4931506724 |
5.00
|
|
|
4045 |
RETAINING RING (2)
|
4931506725 |
7.00
|
|
|
4079 |
O-RING (2)
|
4931506726 |
12.00
|
|
|
4128 |
BELT (1)
|
4931506727 |
81.00
|
|
|
4205 |
COVER (1)
|
4931506728 |
294.00
|
|
|
4206 |
COVER (1)
|
4931506729 |
234.00
|
|
|
4207 |
LOCKING SCREW SET (1)
|
4931506730 |
108.00
|
|
|
4208 |
PULLEY (1)
|
4931506731 |
103.00
|
|
|
4210 |
MOTOR (1)
|
4931506732 |
520.00
|
|
|
4211 |
GUARD (1)
|
4931506733 |
104.00
|
|
|
4213 |
PULLEY (1)
|
4931506734 |
133.00
|
|
|
5083 |
INSERT CARD (1)
|
4931496713 |
135.00
|
|
|
5220 |
HOUSING (1)
|
4931506735 |
116.00
|
|
|
5222 |
HOUSING COVER (1)
|
4931506736 |
253.00
|
|
|
5223 |
ELECTRONIC (1)
|
4931506737 |
570.00
|
|
|
5224 |
POWER MODULE (1)
|
4931506738 |
91.00
|
|
|
5225 |
GUIDE RAIL (1)
|
4931506739 |
284.00
|
|
