Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1001 |
MXFWBT90 900mm Trowel Blades 4 pcs Set (1)
|
4932498920 |
109.00
|
|
|
1002 |
SCREW (4)
|
4931507397 |
7.00
|
|
|
1003 |
SCREW (4)
|
4931507398 |
8.00
|
|
|
1005 |
PULLEY (1)
|
4931507399 |
86.00
|
|
|
1011 |
WASHER (4)
|
4931507276 |
1.00
|
|
|
1012 |
BOLT (5)
|
4931507277 |
3.00
|
|
|
1016 |
RING (1)
|
4931507400 |
525.00
|
|
|
1033 |
GUARD (1)
|
4931507401 |
69.00
|
|
|
1041 |
WASHER (4)
|
4931507278 |
2.50
|
|
|
1042 |
WASHER (4)
|
4931507279 |
1.00
|
|
|
1043 |
NUT (4)
|
4931507280 |
2.50
|
|
|
1044 |
WASHER (4)
|
4931507402 |
1.00
|
|
|
1045 |
WASHER (4)
|
4931507403 |
1.00
|
|
|
1046 |
SCREW (4)
|
4931507404 |
5.00
|
|
|
1050 |
WASHER (4)
|
4931507281 |
1.00
|
|
|
1054 |
NUT (8)
|
4931507282 |
1.00
|
|
|
1056 |
SPACER (1)
|
4931507283 |
11.00
|
|
|
1071 |
BELT (1)
|
4931507405 |
26.50
|
|
|
1072 |
WASHER (5)
|
4931494491 |
2.50
|
|
|
1073 |
SPACER (1)
|
4931507406 |
9.00
|
|
|
1075 |
PULLEY (1)
|
4931507275 |
75.00
|
|
|
1076 |
KEY (1)
|
4931507289 |
15.00
|
|
|
1077 |
SPACER (1)
|
4931507407 |
6.00
|
|
|
1078 |
SCREW (1)
|
4931507284 |
2.50
|
|
|
1512 |
GUARD (1)
|
4931507290 |
120.00
|
|
|
2005 |
SCREW (4)
|
4931507291 |
2.50
|
|
|
2006 |
MOUNTING BRACKET (1)
|
4931507292 |
69.00
|
|
|
2013 |
SCREW (4)
|
4931507293 |
1.00
|
|
|
2014 |
HOLDER (1)
|
4931507294 |
9.00
|
|
|
2015 |
COVER (1)
|
4931507295 |
1.00
|
|
|
2016 |
SCREW (2)
|
4931507296 |
1.00
|
|
|
2018 |
SCREW (4)
|
4931507297 |
1.00
|
|
|
2020 |
SUPPORT BRACKET (1)
|
4931507298 |
1.00
|
|
|
2021 |
COVER (1)
|
4931507299 |
22.50
|
|
|
2022 |
COVER (1)
|
4931507300 |
22.50
|
|
|
2026 |
INSERT CARD (1)
|
4931496713 |
135.00
|
|
|
2030 |
SCREW (3)
|
4931507301 |
1.00
|
|
|
2508 |
MOTOR (1)
|
4931507302 |
920.00
|
|
|
2513 |
ELECTRONIC (1)
|
4931507303 |
660.00
|
|
|
2514 |
INSERT CARD (1)
|
4931507304 |
56.00
|
|
|
2515 |
BATTERY BOX (1)
|
4931507305 |
17.50
|
|
|
2516 |
HOUSING (1)
|
4931507306 |
72.00
|
|
|
2517 |
GUIDE RAIL (1)
|
4931507307 |
284.00
|
|
|
2518 |
CONTROL PANEL KIT (1)
|
4931507308 |
134.00
|
|
|
2519 |
HOUSING (1)
|
4931507309 |
82.00
|
|
|
2520 |
COVER (1)
|
4931507310 |
14.00
|
|
|
3002 |
CABLE JOINT (2)
|
4931507311 |
1.00
|
|
|
3008 |
WIRE (1)
|
4931507312 |
134.00
|
|
|
3028 |
CROSS BRACKET (1)
|
4931507313 |
35.00
|
|
|
3047 |
NUT (2)
|
4931507408 |
1.00
|
|
|
3048 |
SCREW (2)
|
4931507314 |
2.50
|
|
|
3053 |
HANDLE BAR (1)
|
4931507315 |
360.00
|
|
|
3079 |
KNOB (1)
|
4931507316 |
28.00
|
|
|
3081 |
WIRE (2)
|
4931507317 |
6.00
|
|
|
3082 |
CLIP (2)
|
4931507318 |
2.50
|
|
|
3085 |
SWITCH LEVER (1)
|
4931507319 |
2.50
|
|
|
3094 |
SCREW (2)
|
4931507320 |
9.00
|
|
|
3096 |
NUT (2)
|
4931507321 |
3.00
|
|
|
3500 |
SERVICE-KIT (1)
|
4931507322 |
220.00
|
|
|
3501 |
HANDLE SET (2)
|
Item discontinued
(4931494539) |
|
|
|
3502 |
LEVER (1)
|
4931507323 |
101.00
|
|
|
3600 |
SWITCH (1)
|
4931507324 |
92.00
|
|
|
3601 |
SWITCH KIT (1)
|
4931507325 |
50.00
|
|
|
4002 |
SCREW (3)
|
4931507326 |
1.00
|
|
|
4004 |
SCREW (1)
|
4931507327 |
3.00
|
|
|
4005 |
BUSHING (1)
|
4931507409 |
132.00
|
|
|
4006 |
PIN (1)
|
4931507329 |
13.00
|
|
|
4007 |
SPRING (1)
|
4931507410 |
198.00
|
|
|
4014 |
PULLEY (1)
|
4931507411 |
173.00
|
|
|
4018 |
BRACKET (1)
|
4931507412 |
12.00
|
|
|
4019 |
CROSS BRACKET (1)
|
4931507413 |
23.00
|
|
|
4020 |
NUT (9)
|
4931507335 |
2.50
|
|
|
4022 |
WASHER (1)
|
4931507334 |
1.00
|
|
|
4509 |
KNOB (1)
|
4931507414 |
308.00
|
|
|
4523 |
TUBE (1)
|
4931507415 |
1260.00
|
|
|
5001 |
INTERMEDIATE LEVER (1)
|
4931507416 |
390.00
|
|
|
5002 |
PIN (1)
|
4931507417 |
25.00
|
|
|
5003 |
RETAINING RING (2)
|
4931507418 |
4.00
|
|
|
5005 |
GEAR BOX KIT (1)
|
4931507419 |
2475.00
|
|
|
5006 |
SCREW (1)
|
4931507420 |
18.00
|
|
|
5008 |
PLATE (1)
|
4931507421 |
28.00
|
|
|
5009 |
STUD (4)
|
4931507422 |
20.00
|
|
|
5010 |
KEY (1)
|
4931507423 |
7.00
|
|
|
5013 |
GUIDE RAIL (1)
|
4931507424 |
205.00
|
|
|
5014 |
GUIDE RAIL (1)
|
4931507425 |
234.00
|
|
|
5015 |
SCREW (4)
|
4931507426 |
9.00
|
|
|
5016 |
STUD (4)
|
4931507427 |
9.00
|
|
|
5017 |
INTERMEDIATE LEVER (4)
|
4931507428 |
152.00
|
|
|
5018 |
PLATE (1)
|
4931507429 |
482.00
|
|
|
5019 |
SCREW (4)
|
4931507430 |
30.00
|
|
|
5020 |
LEVER (4)
|
4931507431 |
101.00
|
|
|
5022 |
SCREW (4)
|
4931507432 |
44.00
|
|
|
5023 |
SCREW (4)
|
4931507433 |
32.00
|
|
|
5024 |
WASHER (4)
|
4931507434 |
4.00
|
|
|
5025 |
HOLDING BRACKET (4)
|
4931507435 |
7.00
|
|
|
5026 |
CAP (4)
|
4931507436 |
2.50
|
|
|
5027 |
SCREW (4)
|
4931507437 |
7.00
|
|
|
5028 |
O-RING (6)
|
4931507438 |
10.00
|
|
|
5510 |
PLATE (1)
|
4931507439 |
535.50
|
|
|
6002 |
SHAFT (1)
|
4931507440 |
290.00
|
|
|
6003 |
GEAR (1)
|
4931507441 |
848.50
|
|
|
6004 |
SCREW (1)
|
4931507442 |
64.00
|
|
|
6005 |
SHAFT (2)
|
4931507360 |
202.00
|
|
|
6007 |
KEY (1)
|
4931507443 |
28.00
|
|
|
6008 |
WASHER (1)
|
4931507444 |
23.00
|
|
|
6009 |
SHAFT (1)
|
4931507445 |
437.00
|
|
|
6010 |
GEAR BOX HOUSING (1)
|
4931507446 |
429.00
|
|
|
6011 |
CAP (1)
|
4931507447 |
198.00
|
|
|
6012 |
FLANGE (1)
|
4931507448 |
200.00
|
|
|
6014 |
SCREW (16)
|
4931507449 |
2.50
|
|
|
6015 |
SEAL (2)
|
4931507450 |
55.00
|
|
|
6017 |
BEARING (1)
|
4931507451 |
317.00
|
|
|
6019 |
VALVE (1)
|
4931507452 |
37.00
|
|
|
6020 |
PLUG (1)
|
4931507453 |
128.00
|
|
|
6022 |
PLUG (2)
|
4931507454 |
20.00
|
|
|
6023 |
GASKET (2)
|
4931507455 |
23.00
|
|
|
6024 |
GASKET (2)
|
4931507456 |
26.00
|
|
|
6025 |
GASKET (1)
|
4931507457 |
21.00
|
|
|
6026 |
GASKET (1)
|
4931507458 |
22.00
|
|
|
7005 |
SPRING (1)
|
4931507384 |
5.00
|
|
|
7038 |
SPACER (1)
|
4931507385 |
14.00
|
|
|
7049 |
SCREW (2)
|
4931507386 |
1.00
|
|
|
7051 |
WASHER (1)
|
4931507387 |
1.00
|
|
|
7055 |
NUT (1)
|
4931507388 |
1.00
|
|
|
7058 |
PLATE (1)
|
4931507389 |
7.00
|
|
|
7064 |
SHAFT (1)
|
4931507390 |
11.00
|
|
|
7080 |
WASHER (1)
|
4931507391 |
1.00
|
|
|
7088 |
SCREW (1)
|
4931507392 |
7.00
|
|
|
7097 |
RATING PLATE (1)
|
4931507393 |
65.00
|
|
|
7511 |
PULLEY (1)
|
4931507394 |
36.00
|
|
|
7521 |
FRAME (1)
|
4931507459 |
167.00
|
|
|
7522 |
GUARD (1)
|
4931507460 |
73.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
