Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
STRAP (1)
|
4931473596 |
73.00
|
|
|
0002 |
SCREW (12)
|
4931473597 |
2.50
|
|
|
0003 |
SCREW (4)
|
4931473598 |
15.00
|
|
|
0018 |
SCREW (4)
|
4931473600 |
2.50
|
|
|
0038 |
SCREW (1)
|
4931473601 |
13.00
|
|
|
0051 |
SCREW (4)
|
4931473602 |
1.50
|
|
|
0054 |
SEALING WASHER (4)
|
4931473603 |
2.50
|
|
|
0055 |
LOOKED WASHER (4)
|
4931473604 |
2.50
|
|
|
0057 |
SCREW (12)
|
4931473605 |
2.50
|
|
|
0058 |
LOOKED WASHER (12)
|
4931473606 |
2.50
|
|
|
0059 |
SEALING WASHER (12)
|
4931473607 |
2.50
|
|
|
0087 |
SCREW (1)
|
4931473608 |
2.50
|
|
|
0090 |
CABLE (1)
|
4931495438 |
999.00
|
|
|
0095 |
CABLE JOINT (3)
|
4931473610 |
3.00
|
|
|
0096 |
WRENCH (1)
|
4931473611 |
14.00
|
|
|
0109 |
RATING PLATE (1)
|
4931496324 |
3.00
|
|
|
0110 |
O-RING (1)
|
4931473613 |
1.00
|
|
|
0116 |
STRAP (1)
|
4931479039 |
20.00
|
|
|
0200 |
HANDLE SET (1)
|
4931473614 |
354.00
|
|
|
0202 |
HOLDING DEVICE (1)
|
4931495439 |
246.00
|
|
|
0203 |
RUBBER FOOT (1)
|
4931495440 |
57.00
|
|
|
0204 |
GUIDE SLEEVE (1)
|
4931495441 |
41.00
|
|
|
0205 |
CLAMPING SET (1)
|
4931495442 |
811.00
|
|
|
0206 |
HOUSING (1)
|
4931495443 |
95.00
|
|
|
0207 |
MOULDED PART (1)
|
4931495444 |
99.00
|
|
|
0208 |
TURNING KNOB (1)
|
4931473620 |
60.00
|
|
|
0209 |
TURNING KNOB (1)
|
4931473621 |
17.00
|
|
|
0210 |
CABLE (1)
|
4931495445 |
1049.00
|
|
|
0211 |
INSPECTION CAMERA (1)
|
4931481926 |
1049.00
|
|
|
0212 |
CABLE SET (1)
|
4931473526 |
133.00
|
|
|
0214 |
WAISTBELT (1)
|
4931473624 |
238.00
|
|
|
0215 |
SERVICE-KIT (1)
|
4931495446 |
81.00
|
|
|
0216 |
CABLE (1)
|
4931495447 |
187.00
|
|
|
0217 |
SPRING (1)
|
4931495448 |
329.00
|
|
