Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1003 |
SCREW (77)
|
4931506848 |
1.50
|
|
|
1004 |
SCREW (6)
|
4931465326 |
3.00
|
|
|
1005 |
WASHER (4)
|
4931454929 |
1.00
|
|
|
1006 |
SCREW (12)
|
4931494116 |
2.50
|
|
|
1009 |
SCREW (44)
|
4931435015 |
3.00
|
|
|
1010 |
SCREW (11)
|
4931465499 |
3.00
|
|
|
1011 |
TRIGGER (1)
|
4931506849 |
2.50
|
|
|
1012 |
PANEL BLANK (1)
|
4931506850 |
20.50
|
|
|
1013 |
GROUND PLATE (1)
|
4931506851 |
11.50
|
|
|
1014 |
PANEL BLANK (1)
|
4931506852 |
20.50
|
|
|
1015 |
TRIGGER (1)
|
4931506853 |
2.50
|
|
|
1016 |
SCREW (2)
|
4931495347 |
1.00
|
|
|
1093 |
SCREW (7)
|
4931479676 |
2.50
|
|
|
1101 |
COVER CAP (1)
|
4931506854 |
2.50
|
|
|
1116 |
HOUSING (1)
|
4931506855 |
24.00
|
|
|
1210 |
TRIGGER (1)
|
4931506856 |
102.00
|
|
|
1211 |
TRIGGER (1)
|
4931506857 |
102.00
|
|
|
1212 |
HOUSING (1)
|
4931506858 |
78.00
|
|
|
1213 |
HOUSING (1)
|
4931506859 |
45.00
|
|
|
1214 |
HANDLE SET (1)
|
4931506860 |
86.00
|
|
|
1215 |
POWER CORD GB1 (1)
|
4931507963 |
71.00
|
|
|
1216 |
POWER CORD GB2 (1)
|
4931507964 |
75.00
|
|
|
1217 |
POWER CORD IN2 (1)
|
4931507965 |
50.00
|
|
|
2037 |
LATCH (1)
|
4931506861 |
1.00
|
|
|
2038 |
SCREW (2)
|
4931466813 |
1.00
|
|
|
2039 |
HOUSING GUIDE (1)
|
4931506862 |
97.00
|
|
|
2040 |
HOUSING COVER (1)
|
4931506863 |
2.50
|
|
|
2041 |
FRAME (1)
|
4931506864 |
34.00
|
|
|
2042 |
PLATE (1)
|
4931506865 |
10.50
|
|
|
2188 |
CONNECTION CABLE (1)
|
4931506866 |
25.00
|
|
|
2196 |
GUIDE TUBE (1)
|
4931506867 |
4.00
|
|
|
2197 |
RATING PLATE (1)
|
4931506868 |
1.00
|
|
|
2220 |
LATCH (1)
|
4931506869 |
30.00
|
|
|
2221 |
LOCK (1)
|
4931506870 |
38.00
|
|
|
2222 |
LOCK (1)
|
4931506871 |
83.00
|
|
|
3056 |
SCREW (6)
|
4931466592 |
1.00
|
|
|
3057 |
BRACKET (1)
|
4931506872 |
3.00
|
|
|
3058 |
ELECTRONIC (1)
|
4931506873 |
73.00
|
|
|
3059 |
ELECTRONIC (1)
|
4931506874 |
67.00
|
|
|
3061 |
SCREW (2)
|
4931496273 |
1.50
|
|
|
3062 |
PLATE (1)
|
4931506875 |
2.50
|
|
|
3063 |
PLATE (1)
|
4931506876 |
2.50
|
|
|
3064 |
SWITCH BOARD (1)
|
4931506877 |
12.50
|
|
|
3065 |
SCREW (8)
|
4931495286 |
1.00
|
|
|
3073 |
ELECTRONIC (1)
|
4931506878 |
245.00
|
|
|
3074 |
SCREW (8)
|
4931431788 |
2.50
|
|
|
3075 |
COVER (1)
|
4931506879 |
9.50
|
|
|
3076 |
HMI PCBA ASSY (1)
|
4931506880 |
118.00
|
|
|
3077 |
SCREW (40)
|
4931506826 |
1.50
|
|
|
3230 |
GUIDE RAIL SET (1)
|
4931506881 |
109.00
|
|
|
3231 |
BOX (1)
|
4931506882 |
110.00
|
|
|
3234 |
HOUSING (1)
|
4931506883 |
84.00
|
|
|
3235 |
COVER (1)
|
4931506884 |
67.00
|
|
|
4240 |
LEVER (4)
|
4931506885 |
15.00
|
|
|
4241 |
GUIDE TUBE (1)
|
4931506886 |
270.00
|
|
|
4242 |
LED LIGHT (1)
|
4931506887 |
290.00
|
|
|
4247 |
THRUST COLLAR (1)
|
4931506888 |
56.00
|
|
|
4248 |
THRUST COLLAR (1)
|
4931506889 |
60.00
|
|
|
4249 |
THRUST COLLAR (1)
|
4931506890 |
59.00
|
|
|
4250 |
THRUST COLLAR (1)
|
4931506891 |
59.00
|
|
|
4251 |
THRUST COLLAR (1)
|
4931506892 |
58.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
