Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
COVER (2)
|
4931508548 |
3.00
|
|
|
0002 |
COVER (1)
|
4931508698 |
18.00
|
|
|
0003 |
HOUSING (1)
|
4931508699 |
21.00
|
|
|
0004 |
COVER (1)
|
4931508700 |
2.50
|
|
|
0009 |
TANK (1)
|
4931508701 |
76.00
|
|
|
0010 |
WHEEL PAIR (1)
|
4931508702 |
13.00
|
|
|
0016 |
COVER (1)
|
4931508703 |
15.00
|
|
|
0017 |
BRACKET (2)
|
4931508704 |
3.00
|
|
|
0018 |
SOLENOID ASSEMBLY (2)
|
4931508705 |
39.00
|
|
|
0019 |
HOUSING (1)
|
4931508706 |
3.00
|
|
|
0020 |
PIN (4)
|
4931508573 |
3.00
|
|
|
0021 |
HOUSING (1)
|
4931508707 |
20.00
|
|
|
0022 |
LATCH (1)
|
4931508708 |
3.00
|
|
|
0023 |
SPRING (1)
|
4931508709 |
3.00
|
|
|
0024 |
LATCH (1)
|
4931508710 |
4.00
|
|
|
0025 |
PLUNGER (2)
|
4931508711 |
4.00
|
|
|
0026 |
PLUNGER (2)
|
4931508712 |
5.00
|
|
|
0027 |
BRACKET (2)
|
4931508713 |
2.50
|
|
|
0028 |
ELECTRONIC (1)
|
4931508714 |
208.00
|
|
|
0029 |
ELECTRIC FIELD (1)
|
4931508715 |
127.00
|
|
|
0030 |
HOUSING (1)
|
4931508716 |
14.00
|
|
|
0031 |
COVER (1)
|
4931508717 |
4.00
|
|
|
0032 |
BRACKET (1)
|
4931508718 |
3.00
|
|
|
0033 |
SEAL (1)
|
4931508719 |
5.00
|
|
|
0034 |
SEAL (1)
|
4931508567 |
6.00
|
|
|
0035 |
MOTOR (1)
|
4931508720 |
84.50
|
|
|
0037 |
MOTOR (1)
|
4931508568 |
80.00
|
|
|
0038 |
SEAL (1)
|
4931508569 |
5.00
|
|
|
0039 |
ISOLATION (1)
|
4931508721 |
5.00
|
|
|
0040 |
GAUGE (2)
|
4931508722 |
3.00
|
|
|
0041 |
HOUSING (1)
|
4931508723 |
67.00
|
|
|
0042 |
STRIP-BAND (1)
|
4931508724 |
3.00
|
|
|
0043 |
SEAL (1)
|
4931508725 |
9.00
|
|
|
0044 |
SEAL (1)
|
4931508726 |
12.00
|
|
|
0045 |
RIVET (2)
|
4931508727 |
3.00
|
|
|
0046 |
COVER (2)
|
4931508728 |
4.00
|
|
|
0047 |
FRAME (1)
|
4931508729 |
14.00
|
|
|
0048 |
HANDLE (1)
|
4931508544 |
5.00
|
|
|
0049 |
COVER (1)
|
4931508730 |
17.00
|
|
|
0050 |
COVER (1)
|
4931508731 |
6.00
|
|
|
0051 |
BUTTON (1)
|
4931508732 |
14.00
|
|
|
0052 |
ELECT.CIRCUIT BOARD (1)
|
4931508733 |
55.00
|
|
|
0053 |
HOUSING (1)
|
4931508734 |
82.00
|
|
|
0054 |
BRACKET (1)
|
4931508735 |
3.00
|
|
|
0055 |
HOLDER (1)
|
4931508736 |
3.00
|
|
|
0056 |
ROD (2)
|
4931508737 |
3.00
|
|
|
0057 |
PIN (2)
|
4931508738 |
3.00
|
|
|
0058 |
LATCH (2)
|
4931508739 |
4.00
|
|
|
0059 |
PIN (1)
|
4931508740 |
10.00
|
|
|
0060 |
HOUSING (1)
|
4931508741 |
3.00
|
|
|
0061 |
LATCH (4)
|
4931508742 |
4.00
|
|
|
0063 |
SCREW (8)
|
4931496478 |
1.50
|
|
|
0064 |
SCREW (4)
|
4931508743 |
1.50
|
|
|
0065 |
SCREW (9)
|
4931466659 |
1.50
|
|
|
0066 |
SCREW (43)
|
4931508744 |
2.50
|
|
|
0067 |
SCREW (13)
|
4931508745 |
2.50
|
|
|
0068 |
SCREW (2)
|
4931436757 |
3.00
|
|
|
0069 |
SCREW (15)
|
4931506826 |
1.50
|
|
|
0070 |
SCREW (6)
|
4931466151 |
3.00
|
|
|
0071 |
SCREW (1)
|
4931496273 |
1.50
|
|
|
0072 |
SCREW (16)
|
4931508746 |
2.50
|
|
|
0073 |
SEAL (1)
|
4931508747 |
6.00
|
|
|
0074 |
Filter cleaning kit - ONEF2VC34M (2)
|
4932498662 |
49.99
|
|
|
0077 |
COIN CELL PCBA (1)
|
4931508748 |
14.00
|
|
|
0080 |
FERRITE CORE (1)
|
4931508749 |
4.00
|
|
|
0082 |
TUBE (1)
|
4931508750 |
3.00
|
|
|
0094 |
ADAPTOR (1)
|
4931508751 |
8.00
|
|
|
0095 |
ADAPTOR (1)
|
4931508752 |
9.00
|
|
|
0097 |
Fleece dust bag- ONEF2VC34M (1)
|
4932498663 |
15.90
|
|
|
0098 |
REMOTE TSC CONTROL (1)
|
4931503508 |
59.00
|
|
|
0099 |
SCREW (10)
|
4931436054 |
3.00
|
|
|
0102 |
PIN (2)
|
4931508754 |
2.50
|
|
|
0103 |
PIN (2)
|
4931508755 |
4.00
|
|
|
0105 |
SWITCH ON-OFF (1)
|
4931508756 |
49.00
|
|
|
0106 |
ELECTRONIC (1)
|
4931508757 |
37.00
|
|
|
0107 |
SCREW (17)
|
4931508758 |
2.50
|
|
|
0109 |
RATING PLATE (1)
|
4931510723 |
3.00
|
|
|
0110 |
LABEL (1)
|
4931508759 |
2.50
|
|
|
0111 |
LABEL (1)
|
4931508760 |
2.50
|
|
|
0112 |
COVER (1)
|
4931508761 |
3.00
|
|
|
0130 |
SUPPORT BRACKET (1)
|
4931508762 |
16.00
|
|
|
0131 |
WHEEL SET (1)
|
4931508763 |
87.00
|
|
|
0132 |
POWER CORD (1)
|
4931508767 |
77.00
|
|
|
0133 |
HOSE (1)
|
4931508765 |
48.00
|
|
|
0134 |
HOUSING (1)
|
4931508766 |
23.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
