Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1005 |
CLUTCH (1)
|
4931508768 |
32.00
|
|
|
1011 |
CRANKSHAFT (1)
|
4931508769 |
5.00
|
|
|
1012 |
COVER (1)
|
4931508770 |
4.00
|
|
|
1021 |
SCREW (2)
|
4931508771 |
7.00
|
|
|
1050 |
SCREW (1)
|
4931508772 |
13.00
|
|
|
1051 |
SCREW (1)
|
4931508773 |
15.00
|
|
|
1058 |
SCREW (3)
|
4931479984 |
3.00
|
|
|
1078 |
RING (2)
|
4931508774 |
1.00
|
|
|
1083 |
RETAINING RING (1)
|
4931508775 |
1.00
|
|
|
1093 |
SCREW (1)
|
4931508776 |
8.00
|
|
|
1094 |
SCREW (7)
|
4931508777 |
3.00
|
|
|
1095 |
SCREW (4)
|
4931508778 |
3.00
|
|
|
1097 |
SCREW (8)
|
4931508779 |
12.00
|
|
|
1101 |
SEAL (1)
|
4931508780 |
51.00
|
|
|
1128 |
WASHER (1)
|
4931508781 |
6.00
|
|
|
1130 |
WASHER (1)
|
4931508782 |
8.00
|
|
|
1131 |
WASHER (1)
|
4931508783 |
3.00
|
|
|
1146 |
WASHER (3)
|
4931506705 |
15.00
|
|
|
1203 |
CLUTCH (1)
|
4931508784 |
197.00
|
|
|
1207 |
STATOR (1)
|
4931508785 |
25.00
|
|
|
1209 |
SHAFT (1)
|
4931508786 |
224.00
|
|
|
1212 |
GEAR UNIT (1)
|
4931508787 |
189.00
|
|
|
1213 |
SHAFT (1)
|
4931508788 |
130.00
|
|
|
1225 |
COVER (1)
|
4931508789 |
217.00
|
|
|
1229 |
ROTOR (1)
|
4931508790 |
144.00
|
|
|
2003 |
RUBBER BUMPER (2)
|
4931508791 |
2.50
|
|
|
2017 |
BEARING NEEDLE (1)
|
4931508792 |
18.00
|
|
|
2019 |
SCREW (4)
|
4931508793 |
9.00
|
|
|
2020 |
SCREW (4)
|
4931508794 |
7.00
|
|
|
2033 |
CRANK ASSEMBLY (1)
|
4931508795 |
99.00
|
|
|
2047 |
RING (1)
|
4931508796 |
3.00
|
|
|
2056 |
BRACKET (2)
|
4931508797 |
31.00
|
|
|
2063 |
RING (1)
|
4931508798 |
10.00
|
|
|
2064 |
FOAM (1)
|
4931508799 |
4.00
|
|
|
2084 |
SPACER (2)
|
4931508800 |
4.00
|
|
|
2090 |
SCREW (3)
|
4931508801 |
10.00
|
|
|
2091 |
SCREW (8)
|
4931494501 |
2.50
|
|
|
2096 |
SCREW (8)
|
4931508802 |
5.00
|
|
|
2098 |
SCREW (16)
|
4931508803 |
4.00
|
|
|
2099 |
SCREW (4)
|
4931508804 |
4.00
|
|
|
2100 |
SEAL (1)
|
4931508805 |
51.00
|
|
|
2127 |
BRACKET (2)
|
4931508806 |
26.00
|
|
|
2129 |
WASHER (8)
|
4931494491 |
2.50
|
|
|
2150 |
SEAL (1)
|
4931508807 |
41.00
|
|
|
2155 |
SCREW (2)
|
4931508808 |
6.00
|
|
|
2204 |
HOLDER (1)
|
4931508809 |
18.00
|
|
|
2205 |
SWITCH BOARD (1)
|
4931508810 |
76.00
|
|
|
2208 |
CRANKCASE (1)
|
4931508811 |
252.00
|
|
|
2210 |
CONNECTING ROD (1)
|
4931508812 |
106.00
|
|
|
2218 |
PIVOT (1)
|
4931508813 |
223.00
|
|
|
2219 |
BUSHING (1)
|
4931508814 |
17.00
|
|
|
2220 |
HOUSING (1)
|
4931508815 |
178.00
|
|
|
2228 |
COVER (1)
|
4931508816 |
136.00
|
|
|
3002 |
BUTTON (1)
|
4931480607 |
2.50
|
|
|
3022 |
CABLE CLIP (2)
|
4931508817 |
2.50
|
|
|
3052 |
HOUSING (2)
|
4931508818 |
3.00
|
|
|
3072 |
CABLE CLAMP (1)
|
4931508819 |
1.00
|
|
|
3107 |
SCREW (12)
|
4931508820 |
1.00
|
|
|
3110 |
SCREW (11)
|
4931480574 |
2.50
|
|
|
3116 |
SWITCH ON-OFF (1)
|
4931508821 |
11.00
|
|
|
3117 |
SWITCH ASSEMBLY (1)
|
4931508822 |
9.00
|
|
|
3118 |
SUPPORT (1)
|
4931508823 |
2.50
|
|
|
3125 |
SUPPORT (1)
|
4931508824 |
11.00
|
|
|
3135 |
WIRE (1)
|
4931508825 |
100.00
|
|
|
3137 |
CABLE (1)
|
4931508826 |
76.00
|
|
|
3139 |
LABEL (1)
|
4931508827 |
2.50
|
|
|
3154 |
SCREW (12)
|
4931508364 |
1.00
|
|
|
3159 |
LABEL (1)
|
4931508828 |
2.50
|
|
|
3216 |
COVER (1)
|
4931508829 |
172.00
|
|
|
3221 |
ISOLATION (1)
|
4931508830 |
178.00
|
|
|
3222 |
RUBBER BUMPER (1)
|
4931508831 |
26.00
|
|
|
3223 |
HANDLE SET (1)
|
4931508832 |
31.00
|
|
|
3400 |
HANDLE (1)
|
4931508833 |
101.00
|
|
|
3401 |
T-HANDLE (1)
|
4931508834 |
31.00
|
|
|
4001 |
COVER (1)
|
4931508835 |
5.00
|
|
|
4039 |
FAN (1)
|
4931508836 |
17.00
|
|
|
4044 |
RUBBER BUMPER (1)
|
4931508837 |
3.00
|
|
|
4046 |
HOUSING (2)
|
4931508838 |
31.00
|
|
|
4059 |
BRACKET (1)
|
4931508839 |
3.00
|
|
|
4062 |
PRINTED CIRC. BOARD (1)
|
4931508840 |
9.00
|
|
|
4067 |
ROD (1)
|
4931508841 |
24.00
|
|
|
4073 |
SCREW (5)
|
4931508842 |
2.50
|
|
|
4079 |
HOUSING (1)
|
4931508843 |
2.50
|
|
|
4092 |
SCREW (10)
|
4931494503 |
3.00
|
|
|
4120 |
ROD (1)
|
4931508844 |
15.00
|
|
|
4121 |
ROD (1)
|
4931508845 |
19.00
|
|
|
4133 |
COVER (1)
|
4931508846 |
4.00
|
|
|
4138 |
RATING PLATE (1)
|
4931508847 |
6.00
|
|
|
4147 |
CLAMP CLIP (1)
|
4931480035 |
3.00
|
|
|
4157 |
COVER (1)
|
4931508848 |
1.00
|
|
|
4158 |
HOLDER (1)
|
4931508849 |
2.50
|
|
|
4206 |
ELECTRONIC (1)
|
4931508850 |
540.00
|
|
|
4217 |
HOUSING (1)
|
4931508851 |
166.00
|
|
|
5028 |
COVER (1)
|
4931508852 |
3.00
|
|
|
5057 |
SCREW (2)
|
4931508853 |
1.00
|
|
|
5066 |
ELECTRONIC (1)
|
4931480603 |
8.50
|
|
|
5108 |
SCREW (3)
|
4931508854 |
1.00
|
|
|
5109 |
SCREW (8)
|
4931494521 |
2.50
|
|
|
5111 |
SCREW (2)
|
4931480042 |
2.50
|
|
|
5145 |
SCREW (1)
|
4931508855 |
1.00
|
|
|
5200 |
GUIDE RAIL (1)
|
4931508856 |
211.00
|
|
|
5201 |
LATCH (1)
|
4931494527 |
438.50
|
|
|
5202 |
HOLDER (1)
|
4931494526 |
244.00
|
|
|
6143 |
SEAL (2)
|
4931508857 |
1.00
|
|
|
6144 |
DRAIN COCK (2)
|
4931508858 |
13.00
|
|
|
6211 |
SPRING (1)
|
4931508859 |
238.00
|
|
|
6215 |
INDICATOR (1)
|
4931508860 |
7.00
|
|
|
6224 |
FOOT (1)
|
4931508861 |
297.00
|
|
|
6226 |
BELLOWS (1)
|
4931508862 |
285.00
|
|
|
6227 |
PIN (1)
|
4931508863 |
16.00
|
|
|
6301 |
SCREW (2)
|
4931508864 |
8.00
|
|
|
6302 |
SCREW (2)
|
4931508865 |
8.00
|
|
|
6303 |
SCREW (7)
|
4931508866 |
12.00
|
|
|
6304 |
PLATE (1)
|
4931508867 |
85.00
|
|
|
6306 |
WASHER (7)
|
4931508868 |
2.50
|
|
|
6307 |
SPRING (15)
|
4931508869 |
1.50
|
|
|
6308 |
NUT (7)
|
4931508870 |
2.50
|
|
|
6310 |
SPRING (4)
|
4931508871 |
1.00
|
|
|
6311 |
NUT (4)
|
4931508872 |
3.00
|
|
|
6312 |
SCREW (4)
|
4931508873 |
8.00
|
|
|
6313 |
SCREW (4)
|
4931508874 |
9.00
|
|
|
6314 |
PLATE (1)
|
4931508994 |
138.00
|
|
|
6315 |
RING (1)
|
4931508875 |
5.00
|
|
|
6316 |
NUT (1)
|
4931508876 |
4.00
|
|
|
6317 |
COVER (1)
|
4931508877 |
42.00
|
|
|
6319 |
ROD (1)
|
4931508878 |
17.00
|
|
|
6320 |
CYLINDER (1)
|
4931508879 |
270.00
|
|
|
6321 |
RING (1)
|
4931508880 |
3.00
|
|
|
6325 |
SLEEVE (1)
|
4931508881 |
201.00
|
|
|
6327 |
CLAMP (2)
|
4931508882 |
75.00
|
|
|
6328 |
CAP (1)
|
4931508883 |
91.00
|
|
|
6329 |
PISTON (1)
|
4931508884 |
189.00
|
|
|
6332 |
RING (2)
|
4931508885 |
9.00
|
|
|
6333 |
CYLINDER (1)
|
4931508886 |
258.00
|
|
|
6335 |
HANDLE (1)
|
4931508887 |
48.00
|
|
|
6402 |
LOCTITE 277 THREAD LOCK FLUID (1)
|
4931453843 |
111.50
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
