Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0005 |
HOOK (1)
|
4931506638 |
17.00
|
|
|
0007 |
TENSION LEVER (1)
|
4931506639 |
36.00
|
|
|
0011 |
TIRE CLEARING BRUSH KIT,038110/NEXT GEN (1)
|
4931436745 |
5.50
|
|
|
0013 |
SCREW (4)
|
4931506640 |
1.00
|
|
|
0014 |
GUIDE BLOCK (1)
|
4931506641 |
28.00
|
|
|
0015 |
GUIDE BLOCK (1)
|
4931506642 |
27.50
|
|
|
0016 |
GUIDE SHOE (1)
|
4931506643 |
29.00
|
|
|
0020 |
BRACKET (1)
|
4931506644 |
12.00
|
|
|
0021 |
GEAR KIT (1)
|
4931506645 |
63.00
|
|
|
0022 |
ELECTRONIC (1)
|
4931506646 |
131.50
|
|
|
0024 |
ARMATURE (1)
|
4931506647 |
45.00
|
|
|
0025 |
DIAL-MODUL ASSEMBLY (1)
|
4931506648 |
11.00
|
|
|
0026 |
TRIGGER (1)
|
4931506649 |
2.50
|
|
|
0027 |
BUTTON (1)
|
4931506650 |
2.50
|
|
|
0028 |
HINGE PIECE (1)
|
4931506651 |
11.50
|
|
|
0029 |
PIN (2)
|
4931506652 |
2.50
|
|
|
0030 |
COVER (1)
|
4931506653 |
21.00
|
|
|
0050 |
SCREW (1)
|
4931506654 |
1.00
|
|
|
0051 |
WASHER (1)
|
4931506655 |
3.00
|
|
|
0052 |
SPRING PLATE (3)
|
4931472749 |
1.00
|
|
|
0053 |
BELT (2)
|
4931436235 |
3.50
|
|
|
0054 |
PULLEY (1)
|
4931506656 |
13.00
|
|
|
0055 |
SCREW (4)
|
4931506657 |
1.00
|
|
|
0056 |
PLATE (1)
|
4931506658 |
2.50
|
|
|
0057 |
SHAFT (1)
|
4931506659 |
10.00
|
|
|
0058 |
GROOV. BALL BEARING (1)
|
4931506660 |
3.00
|
|
|
0059 |
RETAINING RING (1)
|
4931453112 |
4.00
|
|
|
0060 |
PROTECTION WASHER (1)
|
4931436231 |
2.50
|
|
|
0061 |
SPACER (2)
|
4931436232 |
2.50
|
|
|
0062 |
BUSH (1)
|
4931436240 |
2.00
|
|
|
0063 |
CAM SHAFT (1)
|
4931506661 |
7.50
|
|
|
0064 |
HANDLE COMPL. (1)
|
4931506662 |
43.00
|
|
|
0065 |
SCREW (7)
|
4931473265 |
1.00
|
|
|
0066 |
SCREW (6)
|
4931473361 |
2.50
|
|
|
0067 |
SCREW (3)
|
4931465543 |
2.50
|
|
|
0068 |
RATING PLATE (1)
|
4931506663 |
1.00
|
|
|
0069 |
SCREW TORX SCREW (10)
|
06825314 |
2.50
|
|
|
0070 |
MAIN SHROUD (1)
|
4931506664 |
39.50
|
|
|
0071 |
BEARING (1)
|
4931506665 |
27.00
|
|
|
0072 |
BODY (1)
|
4931506666 |
83.50
|
|
|
0073 |
LEVER (1)
|
4931506667 |
2.50
|
|
|
0074 |
SCREW (1)
|
4931452223 |
3.00
|
|
|
0075 |
HOUSING (1)
|
4931506668 |
7.50
|
|
|
0076 |
SCREW (2)
|
Item discontinued
(661414002) |
|
|
|
0077 |
SCREW (1)
|
4931465279 |
2.50
|
|
|
0078 |
MOTOR HOUSING (1)
|
4931506669 |
22.00
|
|
|
0079 |
SCREW (4)
|
660230017 |
2.50
|
|
|
0080 |
SCREW (4)
|
4931473740 |
2.50
|
|
|
0700 |
CARRYING CASE (1)
|
4931506670 |
90.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
