Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
1001 |
GUARD CAP (8)
|
4931496643 |
4.00
|
|
|
1004 |
RUBBER FOOT (2)
|
4931496644 |
40.00
|
|
|
1018 |
GRIP PART (2)
|
4931496645 |
26.00
|
|
|
1040 |
WHEEL (2)
|
4931496646 |
161.00
|
|
|
1041 |
LOCK RELEASE KIT (1)
|
4931496647 |
174.00
|
|
|
1042 |
SHOCK ABSORBER (1)
|
4931496648 |
178.00
|
|
|
2032 |
BOLT (1)
|
4931496649 |
6.50
|
|
|
2033 |
Reamer Cone for MX 2IN Pipe Threader (1)
|
49165105 |
99.00
|
|
|
2036 |
CUTTER (1)
|
4931496650 |
112.00
|
|
|
2045 |
Pipe Cutter Wheel f. Stat. 2in Threader (1)
|
48361401 |
79.00
|
|
|
2047 |
BUSHING (2)
|
4931496651 |
13.00
|
|
|
2050 |
PIN (1)
|
4931496652 |
58.00
|
|
|
2055 |
HUB (1)
|
4931496653 |
83.00
|
|
|
2058 |
SCREW (2)
|
4931496654 |
5.00
|
|
|
2060 |
KNOB HANDLE (3)
|
4931496655 |
19.00
|
|
|
2080 |
BSPT Die Head for MX 2IN Pipe Threader (1)
|
49165103 |
629.00
|
|
|
2081 |
NPT Die Head for 2IN MX Pipe Threader (1)
|
49165100 |
629.00
|
|
|
2082 |
CUTTER (1)
|
4931496656 |
84.00
|
|
|
2083 |
HANDLE SET (1)
|
4931496657 |
128.00
|
|
|
2084 |
CONNECTOR (1)
|
4931496658 |
94.00
|
|
|
2085 |
PIN (2)
|
4931496659 |
38.00
|
|
|
2086 |
CARRIAGE (1)
|
4931496660 |
363.00
|
|
|
2087 |
PIN (1)
|
4931496661 |
36.00
|
|
|
2088 |
PINION (1)
|
4931496662 |
42.00
|
|
|
2089 |
WHEEL (1)
|
4931496663 |
37.00
|
|
|
2090 |
ROCKER ARM (1)
|
4931496664 |
93.00
|
|
|
3001 |
SEAL (1)
|
4931496665 |
38.00
|
|
|
3020 |
COARSE SMUT FILTER (1)
|
4931496666 |
48.00
|
|
|
3021 |
TANK (1)
|
4931506816 |
100.00
|
|
|
3022 |
SCREW (17)
|
4931506817 |
1.00
|
|
|
3025 |
ADAPTER (1)
|
4931496667 |
14.00
|
|
|
3031 |
INSERT (1)
|
4931496668 |
10.00
|
|
|
3050 |
OIL PUMP (1)
|
4931496669 |
192.00
|
|
|
3051 |
TUBE (1)
|
4931496670 |
53.00
|
|
|
3052 |
TUBE (1)
|
4931496671 |
49.00
|
|
|
3053 |
TUBE (1)
|
4931496672 |
43.00
|
|
|
3054 |
LID (1)
|
4931496673 |
31.00
|
|
|
3055 |
PLUG (1)
|
4931496674 |
66.00
|
|
|
3056 |
HOUSING (1)
|
4931506818 |
265.00
|
|
|
4031 |
SCREW (10)
|
4931496675 |
1.00
|
|
|
4042 |
BOLT (1)
|
4931496676 |
12.50
|
|
|
4047 |
GEAR BOX (1)
|
4931496677 |
745.00
|
|
|
4076 |
HANDLE (2)
|
4931496678 |
24.00
|
|
|
4086 |
SCREW (11)
|
4931496679 |
1.00
|
|
|
4090 |
WASHER (5)
|
4931496680 |
2.50
|
|
|
4096 |
SCREW (3)
|
4931496681 |
1.00
|
|
|
4109 |
PLATE (1)
|
4931496682 |
71.50
|
|
|
4110 |
WASHER (4)
|
4931494491 |
2.50
|
|
|
4112 |
LOCKING PART (1)
|
4931496683 |
2.50
|
|
|
4113 |
NUT (1)
|
4931496684 |
1.00
|
|
|
4131 |
TUBE (2)
|
4931496685 |
151.00
|
|
|
4132 |
HOUSING FOR BATTERY (1)
|
4931496686 |
135.00
|
|
|
4133 |
BRACKET (2)
|
4931496687 |
30.00
|
|
|
4134 |
HOUSING (1)
|
4931496688 |
602.50
|
|
|
4135 |
CLAMP (4)
|
4931496689 |
38.00
|
|
|
4136 |
HOUSING (1)
|
4931496690 |
84.00
|
|
|
4137 |
HANDLE LEFT (1)
|
4931496691 |
300.00
|
|
|
4138 |
RATING PLATE (1)
|
4931496692 |
39.00
|
|
|
4139 |
HANDLE RIGHT (1)
|
4931496693 |
209.00
|
|
|
4140 |
GUARD (1)
|
4931496694 |
73.00
|
|
|
4141 |
COVER (1)
|
4931496695 |
219.00
|
|
|
4142 |
PLATE (1)
|
4931496696 |
268.00
|
|
|
5036 |
BUSHING (2)
|
4931496697 |
1.00
|
|
|
5048 |
GUIDE TUBE (1)
|
4931496698 |
223.00
|
|
|
5053 |
BUSHING (2)
|
4931496699 |
77.00
|
|
|
5055 |
CLUTCH WHEEL (2)
|
4931496700 |
166.00
|
|
|
5058 |
JAW (2)
|
4931496701 |
84.00
|
|
|
5059 |
JAW (2)
|
4931496702 |
84.00
|
|
|
5060 |
JAW (2)
|
4931496703 |
84.00
|
|
|
5065 |
BUSHING (2)
|
4931496704 |
65.50
|
|
|
5150 |
GUIDE DISC (2)
|
4931496705 |
252.00
|
|
|
5151 |
CLAMPING SET (6)
|
4931496706 |
76.00
|
|
|
5152 |
WORM GEAR WHEEL (1)
|
4931496707 |
436.00
|
|
|
5153 |
HOLDING RING (1)
|
4931496708 |
166.00
|
|
|
5154 |
HOLDING RING (1)
|
4931496709 |
178.00
|
|
|
6001 |
HOUSING BOTTOM (1)
|
4931496710 |
876.00
|
|
|
6024 |
HOUSING FOR BATTERY (1)
|
4931496711 |
194.00
|
|
|
6097 |
COVER (1)
|
4931496712 |
3.00
|
|
|
6098 |
INSERT CARD (1)
|
4931496713 |
135.00
|
|
|
6099 |
NAME PLATE (1)
|
4931496714 |
1.00
|
|
|
6102 |
CONNECTOR (1)
|
4931496715 |
14.00
|
|
|
6105 |
CLAMP CLIP (3)
|
4931472938 |
1.00
|
|
|
6106 |
ELECTRONIC (1)
|
4931496716 |
10.00
|
|
|
6170 |
ELECTRONIC (1)
|
4931496717 |
98.00
|
|
|
6171 |
ELECTRONIC (1)
|
4931496718 |
68.00
|
|
|
6172 |
COVER (1)
|
4931496719 |
44.00
|
|
|
6173 |
COVER (1)
|
4931496720 |
28.00
|
|
|
6174 |
ELECTRONIC (1)
|
4931496721 |
38.50
|
|
|
6175 |
CABLE COLLAR (4)
|
4931496722 |
27.00
|
|
|
6176 |
SWITCH BOARD (1)
|
4931496723 |
47.00
|
|
|
6177 |
COVER ASSY (1)
|
4931496724 |
86.00
|
|
