Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
|
PART NOT DEATAILED (1)
|
1000063920 |
|
|
|
1008 |
SPACER (1)
|
4931507274 |
7.00
|
|
|
1009 |
PULLEY (1)
|
4931507275 |
75.00
|
|
|
1010 |
WASHER (4)
|
4931507276 |
1.00
|
|
|
1011 |
BOLT (5)
|
4931507277 |
3.00
|
|
|
1038 |
WASHER (4)
|
4931507278 |
2.50
|
|
|
1039 |
WASHER (4)
|
4931507279 |
1.00
|
|
|
1040 |
NUT (4)
|
4931507280 |
2.50
|
|
|
1044 |
WASHER (4)
|
4931507281 |
1.00
|
|
|
1048 |
NUT (8)
|
4931507282 |
1.00
|
|
|
1050 |
SPACER (1)
|
4931507283 |
11.00
|
|
|
1057 |
SCREW (1)
|
4931507284 |
2.50
|
|
|
1066 |
BELT (1)
|
4931507285 |
28.50
|
|
|
1067 |
WASHER (6)
|
4931494491 |
2.50
|
|
|
1073 |
PULLEY (2)
|
4931507286 |
136.00
|
|
|
1074 |
KEY (1)
|
4931507287 |
3.00
|
|
|
1075 |
SPACER (1)
|
4931507288 |
7.00
|
|
|
1079 |
KEY (1)
|
4931507289 |
15.00
|
|
|
1512 |
GUARD (1)
|
4931507290 |
120.00
|
|
|
2005 |
SCREW (4)
|
4931507291 |
2.50
|
|
|
2006 |
MOUNTING BRACKET (1)
|
4931507292 |
69.00
|
|
|
2013 |
SCREW (4)
|
4931507293 |
1.00
|
|
|
2014 |
HOLDER (1)
|
4931507294 |
9.00
|
|
|
2015 |
COVER (1)
|
4931507295 |
1.00
|
|
|
2016 |
SCREW (2)
|
4931507296 |
1.00
|
|
|
2018 |
SCREW (4)
|
4931507297 |
1.00
|
|
|
2020 |
SUPPORT BRACKET (1)
|
4931507298 |
1.00
|
|
|
2021 |
COVER (1)
|
4931507299 |
22.50
|
|
|
2022 |
COVER (1)
|
4931507300 |
22.50
|
|
|
2026 |
INSERT CARD (1)
|
4931496713 |
135.00
|
|
|
2030 |
SCREW (3)
|
4931507301 |
1.00
|
|
|
2508 |
MOTOR (1)
|
4931507302 |
920.00
|
|
|
2513 |
ELECTRONIC (1)
|
4931507303 |
660.00
|
|
|
2514 |
INSERT CARD (1)
|
4931507304 |
56.00
|
|
|
2515 |
BATTERY BOX (1)
|
4931507305 |
17.50
|
|
|
2516 |
HOUSING (1)
|
4931507306 |
72.00
|
|
|
2517 |
GUIDE RAIL (1)
|
4931507307 |
284.00
|
|
|
2518 |
CONTROL PANEL KIT (1)
|
4931507308 |
134.00
|
|
|
2519 |
HOUSING (1)
|
4931507309 |
82.00
|
|
|
2520 |
COVER (1)
|
4931507310 |
14.00
|
|
|
3002 |
CABLE JOINT (2)
|
4931507311 |
1.00
|
|
|
3005 |
WIRE (1)
|
4931507312 |
134.00
|
|
|
3025 |
CROSS BRACKET (1)
|
4931507313 |
35.00
|
|
|
3042 |
SCREW (2)
|
4931507314 |
2.50
|
|
|
3047 |
HANDLE BAR (1)
|
4931507315 |
360.00
|
|
|
3070 |
KNOB (1)
|
4931507316 |
28.00
|
|
|
3076 |
WIRE (2)
|
4931507317 |
6.00
|
|
|
3077 |
CLIP (2)
|
4931507318 |
2.50
|
|
|
3085 |
SWITCH LEVER (1)
|
4931507319 |
2.50
|
|
|
3092 |
SCREW (2)
|
4931507320 |
9.00
|
|
|
3094 |
NUT (2)
|
4931507321 |
3.00
|
|
|
3500 |
SERVICE-KIT (1)
|
4931507322 |
220.00
|
|
|
3501 |
HANDLE SET (2)
|
Item discontinued
(4931494539) |
|
|
|
3502 |
LEVER (1)
|
4931507323 |
101.00
|
|
|
3600 |
SWITCH (1)
|
4931507324 |
92.00
|
|
|
3601 |
SWITCH KIT (1)
|
4931507325 |
50.00
|
|
|
4002 |
SCREW (3)
|
4931507326 |
1.00
|
|
|
4004 |
SCREW (1)
|
4931507327 |
3.00
|
|
|
4005 |
BUSHING (1)
|
4931507328 |
106.00
|
|
|
4006 |
PIN (1)
|
4931507329 |
13.00
|
|
|
4007 |
CABLE (1)
|
4931507330 |
156.00
|
|
|
4014 |
PULLEY (1)
|
4931507331 |
173.00
|
|
|
4020 |
BRACKET (1)
|
4931507332 |
10.00
|
|
|
4021 |
CROSS BRACKET (1)
|
4931507333 |
19.00
|
|
|
4024 |
WASHER (1)
|
4931507334 |
1.00
|
|
|
4026 |
NUT (1)
|
4931507335 |
2.50
|
|
|
4509 |
KNOB HANDLE (1)
|
4931507336 |
300.00
|
|
|
4513 |
HANDLE (1)
|
4931507337 |
1125.00
|
|
|
4523 |
YOKE (1)
|
4931507338 |
81.00
|
|
|
5001 |
SCREW (4)
|
4931507339 |
5.00
|
|
|
5002 |
PLATE (1)
|
4931507340 |
283.00
|
|
|
5005 |
SCREW (4)
|
4931507341 |
15.00
|
|
|
5006 |
GEAR BOX KIT (1)
|
4931507342 |
2580.00
|
|
|
5007 |
WASHER (2)
|
4931507343 |
3.00
|
|
|
5008 |
SCREW (2)
|
4931507344 |
5.00
|
|
|
5009 |
RETAINING RING (4)
|
4931507345 |
2.50
|
|
|
5011 |
SWITCH LEVER (1)
|
4931507346 |
133.00
|
|
|
5012 |
PIN (1)
|
4931507347 |
23.00
|
|
|
5013 |
SUPPORT (2)
|
4931507348 |
105.00
|
|
|
5015 |
CAP (1)
|
4931507349 |
134.00
|
|
|
5016 |
RING (1)
|
4931507350 |
164.00
|
|
|
5017 |
WASHER (1)
|
4931507351 |
125.00
|
|
|
5018 |
SCREW (2)
|
4931507352 |
3.00
|
|
|
5019 |
WASHER (1)
|
4931507353 |
106.00
|
|
|
5020 |
RING (1)
|
4931507354 |
1350.00
|
|
|
5060 |
SEAL (1)
|
4931507355 |
164.00
|
|
|
5061 |
SCREW (14)
|
4931507356 |
9.00
|
|
|
5062 |
COVER (1)
|
4931507357 |
158.00
|
|
|
5063 |
COVER (1)
|
4931507358 |
133.00
|
|
|
5064 |
BEARING (2)
|
4931507359 |
306.00
|
|
|
5066 |
SHAFT (1)
|
4931507360 |
202.00
|
|
|
5067 |
COVER (1)
|
4931507361 |
30.00
|
|
|
5068 |
COVER (1)
|
4931507362 |
108.00
|
|
|
5069 |
SEAL (1)
|
4931507363 |
119.00
|
|
|
5070 |
CAP (1)
|
4931507364 |
75.00
|
|
|
5071 |
CLIP (1)
|
4931507365 |
32.00
|
|
|
5072 |
SHAFT (1)
|
4931507366 |
240.00
|
|
|
6023 |
KEY (1)
|
4931507367 |
59.00
|
|
|
6024 |
PLATE (1)
|
4931507368 |
375.00
|
|
|
6026 |
PIN (4)
|
4931507369 |
4.00
|
|
|
6027 |
PLATE (1)
|
4931507370 |
29.00
|
|
|
6028 |
PIN (1)
|
4931507371 |
4.00
|
|
|
6029 |
RING (1)
|
4931507372 |
272.00
|
|
|
6030 |
MXFWBT60CB 600mm Trowel Blades 4pc Set (1)
|
4932498918 |
79.00
|
|
|
6031 |
MXFWBT60P 600mm WB Edging Trowel Pan (1)
|
4932498919 |
129.00
|
|
|
6032 |
BEARING (1)
|
4931507373 |
219.00
|
|
|
6034 |
BEARING (1)
|
4931507374 |
350.00
|
|
|
6050 |
PLATE (1)
|
4931507375 |
412.00
|
|
|
6051 |
LEVER (4)
|
4931507376 |
72.00
|
|
|
6052 |
HAND LEVER (4)
|
4931507377 |
231.00
|
|
|
6053 |
RING (4)
|
4931507378 |
47.00
|
|
|
6054 |
SCREW (4)
|
4931507379 |
17.00
|
|
|
6055 |
NUT (12)
|
4931507380 |
2.50
|
|
|
6056 |
SCREW (8)
|
4931507381 |
20.00
|
|
|
6057 |
SCREW (8)
|
4931507382 |
7.00
|
|
|
6058 |
WASHER (8)
|
4931507383 |
2.50
|
|
|
7005 |
SPRING (1)
|
4931507384 |
5.00
|
|
|
7038 |
SPACER (1)
|
4931507385 |
14.00
|
|
|
7049 |
SCREW (2)
|
4931507386 |
1.00
|
|
|
7051 |
WASHER (1)
|
4931507387 |
1.00
|
|
|
7055 |
NUT (1)
|
4931507388 |
1.00
|
|
|
7058 |
PLATE (1)
|
4931507389 |
7.00
|
|
|
7064 |
SHAFT (1)
|
4931507390 |
11.00
|
|
|
7080 |
WASHER (1)
|
4931507391 |
1.00
|
|
|
7088 |
SCREW (1)
|
4931507392 |
7.00
|
|
|
7097 |
RATING PLATE (1)
|
4931507393 |
65.00
|
|
|
7511 |
PULLEY (1)
|
4931507394 |
36.00
|
|
|
7521 |
FRAME (1)
|
4931507395 |
177.00
|
|
|
7522 |
GUARD (1)
|
4931507396 |
85.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
