Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (39)
|
4931473361 |
2.50
|
|
|
0002 |
SCREW (7)
|
4931447515 |
1.50
|
|
|
0006 |
SCREW (2)
|
4931435015 |
3.00
|
|
|
0007 |
ELECTRONIC (1)
|
4931508032 |
69.00
|
|
|
0008 |
DIAL-MODUL ASSEMBLY (1)
|
4931508033 |
3.00
|
|
|
0009 |
ROCKER SWITCH (1)
|
4931508034 |
10.00
|
|
|
0016 |
ADAPTOR (1)
|
4931508035 |
145.00
|
|
|
0018 |
SCREW (2)
|
4931496479 |
1.00
|
|
|
0020 |
SCREW (6)
|
4931465543 |
2.50
|
|
|
0021 |
SCREW (4)
|
4931466683 |
1.50
|
|
|
0028 |
STRAP (1)
|
4931508036 |
66.00
|
|
|
0029 |
SCREW (2)
|
4931472925 |
1.00
|
|
|
0030 |
DIAL-MODUL ASSEMBLY (1)
|
4931508037 |
2.50
|
|
|
0031 |
BALL (1)
|
4931508038 |
3.00
|
|
|
0032 |
SPRING (1)
|
4931508039 |
2.50
|
|
|
0033 |
GASKET (1)
|
4931508040 |
9.00
|
|
|
0054 |
O-RING (1)
|
4931508041 |
5.00
|
|
|
0060 |
RATING PLATE (1)
|
4931508042 |
2.50
|
|
|
0064 |
WASHER (4)
|
4931480315 |
2.50
|
|
|
0065 |
WIRE (1)
|
4931508043 |
21.00
|
|
|
0080 |
FRAME (1)
|
4931508044 |
72.00
|
|
|
0081 |
DOOR (1)
|
4931508045 |
35.00
|
|
|
0082 |
MOTOR HOUSING (1)
|
4931508046 |
42.00
|
|
|
0083 |
LATCH (2)
|
4931508047 |
18.00
|
|
