Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0009 |
HOLDER (1)
|
4931507761 |
14.00
|
|
|
0010 |
PISTON (1)
|
4931507762 |
26.00
|
|
|
0013 |
PIN (1)
|
4931507763 |
5.00
|
|
|
0014 |
AUXILIARY HANDLE (1)
|
4931435002 |
15.00
|
|
|
0015 |
SCREW (3)
|
4931507764 |
2.50
|
|
|
0016 |
COVER (1)
|
4931507765 |
3.00
|
|
|
0018 |
SCREW (4)
|
4931465325 |
3.00
|
|
|
0029 |
RETAINING RING (1)
|
4931507766 |
3.00
|
|
|
0030 |
BALL BEARING (1)
|
4931507767 |
21.00
|
|
|
0031 |
GEAR (1)
|
4931507768 |
15.00
|
|
|
0032 |
RETAINING RING (1)
|
4931465452 |
2.50
|
|
|
0035 |
PROTECTION WASHER (2)
|
680866003 |
3.00
|
|
|
0036 |
SCREW (2)
|
4931473732 |
1.50
|
|
|
0041 |
WASHER (1)
|
4931507769 |
3.00
|
|
|
0047 |
HOUSING COVER (1)
|
4931506780 |
1.50
|
|
|
0050 |
SCREW (5)
|
4931496890 |
1.50
|
|
|
0051 |
SCREW (1)
|
4931496283 |
1.50
|
|
|
0057 |
SCREW (2)
|
4931496273 |
1.50
|
|
|
0059 |
COIN CELL PCBA (1)
|
4931507770 |
13.00
|
|
|
0060 |
HOOK (1)
|
4931436134 |
4.50
|
|
|
0061 |
SCREW (1)
|
4931465986 |
1.50
|
|
|
0068 |
BAG (1)
|
4931507771 |
33.00
|
|
|
0070 |
RATING PLATE (1)
|
4931507772 |
3.00
|
|
|
0080 |
SERVICE KIT (1)
|
4931507773 |
91.50
|
|
|
0081 |
HOLDER (1)
|
4931507774 |
177.00
|
|
|
0082 |
ROD (1)
|
4931507775 |
28.50
|
|
|
0083 |
GEAR CASE (1)
|
4931507776 |
106.00
|
|
|
0084 |
SERVICE KIT (1)
|
4931507777 |
12.00
|
|
|
0085 |
ECCENTRIC SHAFT (1)
|
4931507778 |
39.00
|
|
|
0086 |
SHAFT (1)
|
4931507779 |
21.00
|
|
|
0087 |
END COVER CAP (1)
|
4931507780 |
40.00
|
|
|
0088 |
END COVER CAP (1)
|
4931507781 |
59.00
|
|
|
0089 |
ELECTRONIC (1)
|
4931507782 |
155.00
|
|
|
0090 |
HANDLE (1)
|
4931507783 |
29.00
|
|
|
0091 |
TRIGGER (1)
|
4931507784 |
7.00
|
|
|
0701 |
HDBOX2FUEL HD BOX 2 FUEL XXX (1)
|
4932498753 |
49.90
|
|
|
0702 |
INSERT (1)
|
4931507785 |
27.00
|
|
|
1200 |
GREASE (1)
|
49084220 |
75.00
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
