Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
FLANGE BOLT (1)
|
4931507076 |
1.00
|
|
|
0002 |
FLANGE (1)
|
43340485 |
3.50
|
|
|
0003 |
FLANGE WASHER (1)
|
4931507077 |
4.50
|
|
|
0005 |
SLEEVE (1)
|
4931507078 |
1.00
|
|
|
0025 |
SPRING (1)
|
4931507589 |
1.00
|
|
|
0026 |
SCREW (1)
|
4931465872 |
2.50
|
|
|
0027 |
DUST EXTRACTION (1)
|
4931507079 |
3.50
|
|
|
0029 |
SCREW (1)
|
4931507080 |
1.00
|
|
|
0030 |
WRENCH (1)
|
4931507082 |
4.00
|
|
|
0031 |
PROTECTING SHOE (1)
|
4931507081 |
69.50
|
|
|
0038 |
SCREW (4)
|
06956290 |
2.50
|
|
|
0039 |
SCREW (1)
|
Item discontinued
(06831600) |
|
|
|
0040 |
SCREW (8)
|
4931507083 |
1.00
|
|
|
0041 |
SLIDE (4)
|
4931494162 |
2.50
|
|
|
0058 |
RUBBER RING (1)
|
4931507084 |
1.00
|
|
|
0072 |
SCREW (2)
|
4931473907 |
2.50
|
|
|
0073 |
COVER (1)
|
4931507590 |
1.00
|
|
|
0074 |
SCREW (2)
|
4931465883 |
2.50
|
|
|
0080 |
SWITCH KIT (1)
|
4931507086 |
21.00
|
|
|
0083 |
SCREW (3)
|
4931507591 |
1.00
|
|
|
0084 |
CONTROL PANEL KIT (1)
|
4931507592 |
10.00
|
|
|
0085 |
BUTTON (1)
|
4931507593 |
1.00
|
|
|
0088 |
SCREW (3)
|
4931507085 |
1.00
|
|
|
0089 |
SCREW (1)
|
4931496888 |
1.00
|
|
|
0090 |
SCREW (2)
|
4931507087 |
1.00
|
|
|
0091 |
HANDLE (1)
|
4931507088 |
4.00
|
|
|
0092 |
SCREW (9)
|
4931506283 |
1.00
|
|
|
0097 |
SCREW (1)
|
4931507089 |
1.00
|
|
|
0102 |
SCREW (1)
|
06827475 |
2.50
|
|
|
0110 |
CUTTING GUARD (1)
|
4931507090 |
38.00
|
|
|
0111 |
OUTPUT SHAFT KIT (1)
|
4931507091 |
40.00
|
|
|
0112 |
SPINDLE LOCK (1)
|
4931507092 |
12.00
|
|
|
0113 |
CUTTING GUARD (1)
|
4931507093 |
72.50
|
|
|
0114 |
KNOB (1)
|
4931507095 |
12.00
|
|
|
0115 |
KNOB (1)
|
4931507096 |
11.00
|
|
|
0116 |
ADJUSTABLE SEGMENT (1)
|
4931507104 |
34.00
|
|
|
0117 |
ADJUSTABLE SEGMENT (1)
|
4931507094 |
36.00
|
|
|
0118 |
ROTOR (1)
|
4931507097 |
79.00
|
|
|
0119 |
HOOK (1)
|
4931507098 |
17.00
|
|
|
0120 |
HANDLE (1)
|
4931507594 |
33.00
|
|
|
0121 |
ELECTRONIC (1)
|
4931507595 |
246.00
|
|
|
0122 |
LOCK RELEASE KIT (1)
|
4931507101 |
11.00
|
|
|
0123 |
CLAMPING LEVER (1)
|
4931507102 |
22.00
|
|
|
0124 |
RATING PLATE (1)
|
4931507596 |
1.00
|
|
|
0125 |
PARALLEL GUIDE (1)
|
4931448018 |
9.00
|
|
|
0700 |
TOOL BOX (1)
|
4931507105 |
96.00
|
|
