Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0002 |
SCREW (6)
|
4931479948 |
3.00
|
|
|
0008 |
HOUSING (1)
|
4931494111 |
29.00
|
|
|
0019 |
HANDLE (1)
|
4931512140 |
17.00
|
|
|
0030 |
MOTOR (1)
|
4931494112 |
258.50
|
|
|
0035 |
SCREW (6)
|
4931494113 |
2.50
|
|
|
0038 |
SCREW (4)
|
4931494114 |
1.50
|
|
|
0044 |
MOTOR HOUSING (1)
|
4931496855 |
36.00
|
|
|
0045 |
WASHER (4)
|
4931480509 |
3.00
|
|
|
0046 |
SCREW (4)
|
4931494116 |
2.50
|
|
|
0056 |
MOWER BLADE 21IN/ 53 CM (1)
|
4932479818 |
31.00
|
|
|
0059 |
FLANGE NUT (1)
|
4931496385 |
1.00
|
|
|
0079 |
BRACKET (1)
|
4931494117 |
23.50
|
|
|
0108 |
BRACKET (1)
|
4931494118 |
34.50
|
|
|
0114 |
SCREW (2)
|
4931480478 |
3.50
|
|
|
0115 |
KNOB HANDLE (2)
|
4931480479 |
4.00
|
|
|
0118 |
HOLDING PLATE (2)
|
4931480480 |
2.50
|
|
|
0131 |
DIRECT.DUST CHUTE (1)
|
4931495374 |
22.00
|
|
|
0132 |
GUARD PLUG (1)
|
4931495375 |
12.50
|
|
|
0133 |
GRASS-CATCHING BAG (1)
|
4931495376 |
53.00
|
|
|
0134 |
FRAME (1)
|
4931495377 |
33.00
|
|
|
0148 |
RATING PLATE (1)
|
4931508917 |
1.00
|
|
|
0170 |
DRIVE WHEEL (2)
|
4931508918 |
73.00
|
|
|
0171 |
COVER ASSY (1)
|
4931508919 |
39.00
|
|
|
0174 |
HANDLE COMPL. (1)
|
4931508920 |
203.50
|
|
|
0175 |
DRIVE MOTOR (1)
|
4931508921 |
193.00
|
|
|
0176 |
HOUSING (1)
|
4931480488 |
63.00
|
|
|
0178 |
WHEEL (2)
|
4931480490 |
40.50
|
|
|
0179 |
AXLE (1)
|
4931480491 |
58.00
|
|
|
0180 |
DEFLECTOR (1)
|
4931480492 |
52.50
|
|
|
0181 |
CLAMPING SET (1)
|
4931480493 |
47.50
|
|
|
0182 |
GUARD CAP SET (1)
|
4931508922 |
36.00
|
|
|
0183 |
LED LIGHT (1)
|
4931480495 |
52.50
|
|
|
0184 |
SUPPORT BRACKET (1)
|
4931480496 |
47.50
|
|
|
0185 |
GUIDE RAIL (1)
|
4931480497 |
37.00
|
|
|
0186 |
HANDLE RIGHT (1)
|
4931508923 |
45.00
|
|
|
0187 |
ELECTRONIC (1)
|
4931508924 |
360.00
|
|
|
0188 |
BATTERY BOX (1)
|
4931495378 |
75.00
|
|
|
0189 |
HANDLE LEFT (1)
|
4931508925 |
44.00
|
|
