Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
SCREW (2)
|
4931508928 |
1.00
|
|
|
0002 |
COVER (1)
|
4931508929 |
6.00
|
|
|
0005 |
SCREW (1)
|
4931435015 |
3.00
|
|
|
0006 |
LEVER (1)
|
4931508930 |
3.00
|
|
|
0007 |
SCREW (1)
|
4931508931 |
1.00
|
|
|
0008 |
FLANGE (1)
|
4931508932 |
3.00
|
|
|
0009 |
FLANGE (1)
|
4931508933 |
3.00
|
|
|
0010 |
RETAINING RING (1)
|
4931466786 |
1.00
|
|
|
0011 |
WASHER (1)
|
4931508934 |
1.00
|
|
|
0012 |
SCREW (1)
|
4931506290 |
1.00
|
|
|
0013 |
RUBBER BUMPER (1)
|
4931465876 |
2.50
|
|
|
0014 |
GUARD CAP (1)
|
4931508935 |
6.00
|
|
|
0015 |
SPRING (1)
|
4931508936 |
2.50
|
|
|
0016 |
SCREW (4)
|
4931465163 |
2.50
|
|
|
0017 |
SLEEVE (1)
|
4931508937 |
2.50
|
|
|
0023 |
SCREW (2)
|
4931508938 |
1.00
|
|
|
0035 |
BOLT (1)
|
4931506288 |
2.50
|
|
|
0036 |
SCALE (1)
|
4931508939 |
3.00
|
|
|
0037 |
SCREW (2)
|
4931508940 |
1.00
|
|
|
0038 |
PROTECTION WASHER (2)
|
4931466984 |
1.00
|
|
|
0039 |
NUT (1)
|
4931508941 |
3.00
|
|
|
0040 |
LEVER (1)
|
4931508942 |
3.00
|
|
|
0041 |
WASHER (2)
|
4931472005 |
1.00
|
|
|
0042 |
NUT (1)
|
4931506287 |
1.00
|
|
|
0043 |
GUIDE SHOE (1)
|
4931508943 |
49.00
|
|
|
0044 |
SCREW (2)
|
4931508944 |
1.00
|
|
|
0047 |
HANDLE (1)
|
4931508945 |
5.00
|
|
|
0048 |
SCREW (1)
|
06827276 |
2.50
|
|
|
0049 |
SCREW (11)
|
4931506283 |
1.00
|
|
|
0050 |
ALLEN KEY (1)
|
4931508946 |
3.00
|
|
|
0052 |
SCREW (3)
|
4931508947 |
1.00
|
|
|
0063 |
SCREW (2)
|
4931480405 |
2.50
|
|
|
0067 |
SWITCH KIT (1)
|
4931507086 |
21.00
|
|
|
0073 |
SCREW (4)
|
4931472710 |
1.00
|
|
|
0074 |
RUBBER (2)
|
4931508948 |
2.50
|
|
|
0076 |
LOCK (1)
|
4931508949 |
4.00
|
|
|
0079 |
SPRING (1)
|
4931506285 |
1.00
|
|
|
0080 |
LOCKING SCREW (2)
|
4931465672 |
2.50
|
|
|
0081 |
COVER (1)
|
4931494122 |
2.50
|
|
|
0085 |
HOLDING BRACKET (1)
|
4931508950 |
3.00
|
|
|
0086 |
O-RING (1)
|
4931436466 |
2.50
|
|
|
0089 |
SCREW (1)
|
4931506292 |
1.00
|
|
|
0090 |
SCREW (3)
|
4931508951 |
1.00
|
|
|
0092 |
O-RING (1)
|
4931508952 |
2.50
|
|
|
0093 |
BUSHING (1)
|
4931508953 |
2.50
|
|
|
0094 |
LEVER (1)
|
4931508954 |
6.00
|
|
|
0095 |
NUT (1)
|
4931508955 |
3.00
|
|
|
0097 |
WASHER (2)
|
4931508956 |
2.50
|
|
|
0098 |
SPRING (2)
|
4931508957 |
4.00
|
|
|
0099 |
SCREW (1)
|
4931508958 |
1.00
|
|
|
0120 |
GEAR BOX HOUSING (1)
|
4931508959 |
31.50
|
|
|
0121 |
COVER (1)
|
4931508960 |
11.00
|
|
|
0122 |
LOCKING PLATE (1)
|
4931508961 |
10.00
|
|
|
0123 |
HOUSING (1)
|
4931508962 |
32.00
|
|
|
0124 |
ROTOR (1)
|
4931508963 |
36.00
|
|
|
0125 |
ELECTRONIC (1)
|
4931508964 |
159.00
|
|
|
0126 |
SWITCH BUTTON (1)
|
4931508965 |
10.00
|
|
|
0127 |
LED LIGHT (1)
|
4931508966 |
17.00
|
|
|
0128 |
HOOK (1)
|
4931508967 |
16.00
|
|
|
0129 |
RATING PLATE (1)
|
4931508968 |
1.00
|
|
|
0130 |
LEVER (1)
|
4931508969 |
16.00
|
|
|
0131 |
LEVER (2)
|
4931508970 |
11.00
|
|
|
0132 |
SHAFT (1)
|
4931508971 |
30.00
|
|
|
0133 |
DRIVING SHAFT (1)
|
4931508972 |
27.00
|
|
|
0134 |
GUARD (1)
|
4931508973 |
27.00
|
|
|
0135 |
GA-165 GuideRail Adaptor f.Circular Saw (1)
|
4932500003 |
49.00
|
|
|
0136 |
FENCE (1)
|
4931508974 |
19.00
|
|
|
0700 |
CARRYING CASE (1)
|
4931508975 |
57.00
|
|
