Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0004 |
CONNECTION CABLE (1)
|
4931487854 |
21.00
|
|
|
0005 |
PROTECTING COVER (1)
|
4931393422 |
3.50
|
|
|
0008 |
SAW TABLE (1)
|
4931381659 |
3.00
|
|
|
0009 |
RATING LABEL (1)
|
4931487851 |
1.00
|
|
|
0100 |
MOTOR HOUSING (1)
|
4931381333 |
5.50
|
|
|
0103 |
SCREW (4)
|
4931618253 |
2.50
|
|
|
0105 |
ELECTRIC FIELD (1)
|
4931442712 |
18.00
|
|
|
0106 |
ARMATURE (1)
|
4931442641 |
43.50
|
|
|
0116 |
AIR DEFLECTOR RING (1)
|
4931368649 |
3.00
|
|
|
0118 |
BRUSH HOLDER (2)
|
4931368633 |
4.00
|
|
|
0120 |
PAIR HANDLE SHELLS (1)
|
4931381227 |
10.50
|
|
|
0121 |
SCREW (4)
|
4931623048 |
2.50
|
|
|
0123 |
RUBBER SLEEVE (1)
|
4931368374 |
2.50
|
|
|
0124 |
SCREW (2)
|
4931624538 |
2.50
|
|
|
0125 |
CABLE COLLAR (1)
|
4931256500 |
3.50
|
|
|
0128 |
PISTONRING (3)
|
4931487499 |
1.00
|
|
|
0130 |
CHOKING COIL (2)
|
4931369504 |
3.50
|
|
|
0131 |
CARBON BRUSH SET (1)
|
4931381666 |
14.50
|
|
|
0133 |
PRINTED CIRC. BOARD (1)
|
4931381628 |
14.50
|
|
|
0135 |
SWITCH (1)
|
4931487784 |
60.00
|
|
|
0136 |
SCREW (2)
|
4931621772 |
1.00
|
|
|
0140 |
ELECTRIC ELEMENT (1)
|
4931487782 |
81.00
|
|
|
0200 |
GEAR BOX (1)
|
4931412831 |
50.00
|
|
|
0203 |
PIN D 6325 4 M6X32 (1)
|
4931621942 |
4.50
|
|
|
0205 |
SUPPORT ROLL HOLDER (1)
|
4931468106 |
8.50
|
|
|
0206 |
INDEXING BOLT (1)
|
4931381103 |
4.50
|
|
|
0207 |
SWITCH (1)
|
4931381156 |
3.50
|
|
|
0208 |
SWITCH HANDLE (1)
|
4931378812 |
4.00
|
|
|
0209 |
BALL BEARING (1)
|
4931901253 |
6.50
|
|
|
0210 |
GEAR (1)
|
4931357515 |
15.50
|
|
|
0211 |
SEALING WASHER 21,8X15,8X0,2 (1)
|
4931803914 |
2.50
|
|
|
0212 |
LOCKING RING D 472 22X1 (1)
|
4931613683 |
3.50
|
|
|
0213 |
NEEDLE BEARING (2)
|
4931219422 |
2.50
|
|
|
0214 |
LOCKING RING D 471 7X0,8 (1)
|
4931621828 |
3.50
|
|
|
0216 |
DISC (1)
|
4931622131 |
3.50
|
|
|
0217 |
SCREW D 7981 3,9X32 (4)
|
4931621515 |
1.00
|
|
|
0219 |
TENSION LEVER (1)
|
4931381609 |
4.00
|
|
|
0220 |
SCREW (4)
|
4931623020 |
2.50
|
|
|
0221 |
SEAL (1)
|
4931381656 |
3.50
|
|
|
0222 |
BALANCE WEIGHT (1)
|
4931381109 |
5.50
|
|
|
0224 |
SHIM (1)
|
4931357577 |
3.50
|
|
|
0225 |
NEEDLE BUSH (1)
|
4931361376 |
3.50
|
|
|
0226 |
DISC N874237 6,1X12X0,5 (1)
|
4931621830 |
3.50
|
|
|
0227 |
RING D471 6X0,7 (1)
|
4931605092 |
3.50
|
|
|
0228 |
WIRE STRAP (1)
|
4931357982 |
4.50
|
|
|
0229 |
ROCKER BAR (1)
|
4931357522 |
3.50
|
|
|
0230 |
CYLINDER PIN (1)
|
4931381112 |
3.50
|
|
|
0238 |
SCREW (1)
|
4931300699 |
2.50
|
|
|
0240 |
GEAR BOX COVER (1)
|
4931426460 |
26.00
|
|
|
0241 |
GROUND PLATE (1)
|
4931412827 |
14.50
|
|
|
0242 |
SCREW (4)
|
4931310396 |
2.50
|
|
|
0243 |
BEARING CAGE (1)
|
4931357986 |
3.50
|
|
|
0244 |
BEARING CAGE (1)
|
4931357985 |
3.50
|
|
|
0245 |
SCREW (2)
|
4931317532 |
2.50
|
|
|
0246 |
PRESSURE SPRING (2)
|
4931341759 |
3.50
|
|
|
0247 |
TENSION SPRING (1)
|
4931330453 |
3.50
|
|
|
0248 |
SWITCH LEVER (1)
|
4931381159 |
3.50
|
|
|
0250 |
INDEXING SLEEVE (1)
|
4931381158 |
4.50
|
|
|
0251 |
SCREW (1)
|
4931624172 |
2.50
|
|
|
0260 |
GROUND PLATE (1)
|
4931412827 |
14.50
|
|
|
0261 |
PRESSURE ELEMENT (1)
|
4931357588 |
3.50
|
|
|
0262 |
SCREW (1)
|
4931381124 |
2.50
|
|
|
0263 |
COVER (1)
|
4931381638 |
3.00
|
|
|
0265 |
HOLDER (1)
|
4931381603 |
13.00
|
|
|
0266 |
WIRE (1)
|
4931253598 |
3.50
|
|
|
0267 |
WIRE (1)
|
4931624445 |
3.00
|
|
|
0270 |
RAM (1)
|
4931357693 |
26.50
|
|
|
0271 |
TORSION SPRING (1)
|
4931330424 |
3.50
|
|
|
0272 |
COLLET (1)
|
4931330494 |
7.50
|
|
|
0273 |
SCREW (1)
|
4931623102 |
2.50
|
|
|
0274 |
PRESSURE SPRING (1)
|
Item discontinued
(4931357686) |
|
|
|
0275 |
CENTERING JAW (2)
|
4931330303 |
3.50
|
|
|
0276 |
SEAL RING (1)
|
4931623091 |
3.50
|
|
|
0600 |
DUST CAP (1)
|
4931357987 |
3.50
|
|
|
0601 |
SUCTION SLEEVE (1)
|
4931357983 |
4.00
|
|
|
0700 |
CARRYING CASE (1)
|
4931415345 |
35.00
|
|
|
0701 |
ANT-CHIPPING DEVICE (1)
|
4931449321 |
7.00
|
|
|
0703 |
JSPE90X GUIDE SHOE JS SHOE - 1PC (1)
|
4932430356 |
12.40
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
