Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
MATRIX (1)
|
633196001 |
9.00
|
|
|
0005 |
INTERLOCK ELEMENT (1)
|
691261001 |
2.50
|
|
|
0008 |
CLAMPING RING (1)
|
31150511 |
4.00
|
|
|
0009 |
COVER (1)
|
4931511328 |
1.00
|
|
|
0010 |
FELT (1)
|
902393001 |
2.50
|
|
|
0012 |
RATING PLATE (1)
|
4931511306 |
1.00
|
|
|
0014 |
SCREW (8)
|
660031016 |
2.50
|
|
|
0015 |
SCREW (1)
|
661081001 |
2.50
|
|
|
0016 |
SCREW M3,5 Torx 10 (1)
|
660031023 |
2.50
|
|
|
0026 |
PRESSURE SPRING (1)
|
4931408243 |
4.00
|
|
|
0032 |
INDEXING SLEEVE (1)
|
633289001 |
4.00
|
|
|
0033 |
SPRING (1)
|
692505001 |
3.00
|
|
|
0034 |
GUIDE (1)
|
4931507070 |
1.00
|
|
|
0041 |
SCREW (1)
|
661113008 |
3.00
|
|
|
0044 |
WARNING PLATE (1)
|
940230187 |
2.50
|
|
|
0046 |
NOSEPIECE (1)
|
200783002 |
11.50
|
|
|
0047 |
GEAR BOX ASSY (1)
|
4931480462 |
29.00
|
|
|
0048 |
SWITCH KIT (1)
|
4931507071 |
40.00
|
|
|
0049 |
GEAR BOX ASSY (1)
|
4931480463 |
23.50
|
|
|
0050 |
MOTOR ASSEMBLY (1)
|
4931507072 |
40.00
|
|
|
0051 |
HOUSING (1)
|
4931511307 |
28.00
|
|
|
0052 |
SPINDLE KIT (1)
|
4931461469 |
34.00
|
|
|
0055 |
GASKET (1)
|
4931472354 |
3.50
|
|
To select the correct EU-Declaration of Conformity, please check the first 8 digits on your rating plate and match them with the corresponding EU-Declaration of Conformity document that has the same numbers in its title.
