Gross prices without shipping costs or minimal invoicing following your retailer
Currencies: EUR
|
Position |
Description (Qty) |
Part number |
Price (€) |
|
|
0001 |
FIXTEC NUT P1 (1)
|
4932352473 |
|
|
|
0003 |
FLANGE (1)
|
4931435020 |
|
|
|
0004 |
SCREW (4)
|
4931435150 |
|
|
|
0005 |
PROTECTION WASHER (6)
|
680866003 |
|
|
|
0006 |
BALL BEARING (1)
|
4931446467 |
|
|
|
0007 |
O-RING (1)
|
570699002 |
|
|
|
0008 |
AUXILIARY HANDLE (1)
|
4931435002 |
|
|
|
0009 |
SCREW (4)
|
4931435023 |
|
|
|
0011 |
NUT (1)
|
671686001 |
|
|
|
0013 |
BEARING CAGE (1)
|
672569001 |
|
|
|
0014 |
SCREW (2)
|
660165015 |
|
|
|
0015 |
PLATE (1)
|
4931436010 |
|
|
|
0016 |
WASHER (1)
|
Item discontinued
(632876001) |
|
|
|
0017 |
ARMATURE (1)
|
Item discontinued
(4931436012) |
|
|
|
0018 |
BALL BEARING (1)
|
4931436014 |
|
|
|
0019 |
AIR DEFLECTOR RING (1)
|
4931436011 |
|
|
|
0022 |
COVER PLATE (1)
|
4931453199 |
|
|
|
0027 |
RATING PLATE (1)
|
4931461665 |
|
|
|
0028 |
SCREW (4)
|
660024030 |
|
|
|
0029 |
SCREW (1)
|
4931453227 |
|
|
|
0030 |
DUST GUARD CAP (1)
|
4931436016 |
|
|
|
0040 |
ELECTRONIC (1)
|
Item discontinued
(4931452761) |
|
|
|
0041 |
HOLDING RING (1)
|
4931435476 |
|
|
|
0042 |
BEVEL GEAR PAIR (1)
|
4931436007 |
|
|
|
0044 |
NEEDLE BEARING (1)
|
4931446185 |
|
|
|
0045 |
O-RING (1)
|
4931435006 |
|
|
|
0046 |
SPRING (1)
|
4931435005 |
|
|
|
0047 |
PUSH-BUTTON (1)
|
4931452762 |
|
|
|
0048 |
SPINDLE LOCK (1)
|
4931452763 |
|
|
|
0049 |
GEAR CASE (1)
|
4931461663 |
|
|
|
0050 |
PUSH-BUTTON (1)
|
4931452765 |
|
|
|
0051 |
HOUSING (1)
|
4931452766 |
|
|
|
0052 |
BALL BEARING (1)
|
681337001 |
|
|
|
0053 |
SPINDLE (1)
|
4931461664 |
|
|
|
0054 |
SCREW (5)
|
4931435015 |
|
|
|
0055 |
SPACER (1)
|
Item discontinued
(4931433694) |
|
|
|
0056 |
SPRING (3)
|
4931435012 |
|
|
|
0057 |
BALL (3)
|
4931453238 |
|
|
|
0058 |
SPRING (1)
|
4931435010 |
|
|
|
0059 |
LEVER (1)
|
Item discontinued
(4931452768) |
|
|
|
0060 |
GUARD CAP (1)
|
4931466633 |
|
|
|
0061 |
GUARD CAP (1)
|
4931452770 |
|
|
|
0070 |
GUARD CAP (1)
|
4931452115 |
|
|
|
0071 |
GUARD CAP (1)
|
4931452772 |
|
|
|
0080 |
ARMATURE (1)
|
4931466720 |
|
|
|
0701 |
HD Box 3 - 1pc (1)
|
4932453386 |
|
|
|
0702 |
HD Box Insert 17-1pc (1)
|
4932453860 |
|
|
